Kontron eBP-6A4B1 Quick Reference

eBP-6A4B1 eBP-6A4B1
eBP-6A4B1
6-Slot ePCI Passive Backplane
Board Rev. 0
QUICK REFERENCE
Version 1.2

First Level Debugging

1. If ATX +12V power supply is used on SHB, make sure that the +12V power cable (J19) is connected in SHB and +12V power
supply cable mated in J17.
2 . Remove all peripheral boards and SBCs.
3 . Remove all cables from backplane.
4 . Make sure that all the Power Good LEDs are on.
6.150
11.360
J1 PS/2 Keyboard
J2 SBC KCI Monitor
J3 PS/2 Mouse
J4 Multifunction
J5 3.3V PCI 64-BIT
J6-9 5V PCI 64-BIT
J10-12 FANS
J13 ATX Power-Supply
J16 AUX Power-Supply
J17-J19 +12V ATX Power-Supply
J20 Fast Connector I/O
FAN1 FAN3
1
1 1 1 1
J1 J3 J10 J11
13
J13
A1
A2
SLOT 0
J5
PCI-X 133MHz/64-bit
B1
B2
2 6
W1
1 5 P1
BUS A
A1
A2
ePCI-X
B1
B2
J4
2 6 A1
W2
1 5 A2
J6 SLOT 0
B1
B2
W6
W5
1 1
A1
A2
J7 SLOT 1
B1
B2
A1
PCI-X 66MHz
A2
J8
SLOT 2
/64-bit
B1
B2
A1
A2
J9 SLOT 3
B1
B2
J2
2 20
FAN6 - J31
FAN2 - J12
1 2 3
1 1 19

Connectors

Connectors
J20A Power Connector
J21 External Event I/O
J22,23,31 Fans
J24 Speaker
J25 Power LED
J26 Chassis Intrusion Sw
J27 Power-ON Switch
J28 Hard Drive LED
J29 RESET Button
J30 PS/2 Keyboard
12 6 1
1
24
J16
J17
A93
A94 D 0
B93
B94
P2
BUS A BUS B
A93
A94 D 0
B93
B94
A93
A94
C 1
B93
B94
A93
A94
B 2
B93
B94
A93
A94
A 3
B93
B94
VIEW FROM TOP SIDE

JUMPER SETTINGS

JUMPER SETTINGS
(* : Default Setting) (* : Default Setting)
*
W1 - PCI BUS B Maximum Speed ( none)
*
W2 - PCI BUS A Maximum Speed ( 5-6)
Bus Speed Mode Jumper
33MHz or Less PCI 1-2, 3-4
33 to 66MHz PCI 3-4
5-6
50 to 66MHz PCI-X
None
100 to 133MHz PCI-X
W4 - Power Supply Mode
*
ATX Mode PS-ON from SBC
2-4, 5-6
Power Supply always ON 3-4
Rocker Switch Mode 4-6
W5, W6 Bus A, Slot 0 Config W5
* Standard mode On
When using with ePCI-200 Off
1 14 1
2
1 J20 13
2 6
J20A
1 5
W4
Fan 4
31 A
BUS B
1
Fan 5
1
P3
BUS B
1
-
Speaker
+
31 A
-
PWRGD
+
1
-
1
CI +
-
30 B
PWRBT
+
1
-
HDDACT
+
1
-
RST
+ 1
12
-12V
29 C
+12V
Speaker
+5V
NC
KBDAT
KBCLK
-5V
GND
RESET
GND
28 D
+3.3V 1
J21
2 10
1 9
W6
Off
On
J19
J22
J23
A61
A62
B61
B62
J24
J25
J26
J27
J28
J29
J30
