SC10 Shutter Controller
3.3.

Front Panel Keys and Indicators


SELECT: Selects the window or function to be operated on. The Main
LCD display screen contains four display windows, each is located in a
quadrant of the display. The windows are TIME OPEN, TIME CLOSED,
MODE, and TRIGGER. The SELECT key is used to move between the
four windows (quadrants) of the display. The active quadrant is
indicated by the "_" (underscore) in the quadrant. When the underscore
"_" is present in the quadrant the contents of the selected mode may be
modified using the arrow keys.

ENABLE: Enables operation the controller as per the programmed
parameters. When the unit is enabled the "ENABLED" indicator will
illuminate. Pressing the ENABLE key while the unit is enabled will
disable the unit.

▲ Increments either numerically (digits) or steps up through the options
in the active window.

▼ Decrements either numerically (digits) or steps down through the
options in the active window.

◄ Moves the curser left in the active display.

► Moves the curser right in the active display.

SHUTTER ENABLED: Illuminates when the unit is active or waiting for
a trigger event to executing the programmed parameters.

SHUTTER OPEN: Illuminates when the shutter is open or the output
pulse is "active high".
