Chapter 1 Warning Symbol Definitions; Chapter 2 Safety - THORLABS SC10 User Manual

SC10 Shutter Controller

Chapter 1 Warning Symbol Definitions

Below is a list of warning symbols you may encounter in this manual or on your
device.
Symbol Description
Direct Current
Alternating Current
Both Direct and Alternating
Current
Earth Ground Terminal
Protective Conductor
Terminal
Frame or Chassis Terminal
Equipotentiality
On (Supply)
Off (Supply)

Chapter 2 Safety

All statements regarding safety of operation and technical data in this instruction
manual will only apply when the unit is operated correctly.
!
There are no serviceable parts inside of the SC10 controller. All service
should be performed by a factory-authorized technician. Contact Thorlabs if
The AC input of this unit is 100 to 240 VAC, 50 – 60 Hz @ 110 mA.
!
This unit is supplied with a 115 VAC parallel blade line cord for North
American use only. For all other applications, use an IEC 320 compatible line
cord fitted with a plug appropriate for your particular AC wall socket.
8654-D02
Symbol
CAUTION
service is required.
CAUTION
Chapter 1: Warning Symbol Definitions
Description
In Position of a Bi-Stable
Push Control
Out Position of a Bi-Stable
Push Control
Caution: Risk of Electric
Shock
Caution: Hot Surface
Caution: Risk of Danger
Warning: Laser Radiation
Caution: Spinning Blades May
Cause Harm
Caution: Product is ESD
Sensitive
!
!
Page 1
