JETStream PI-123 Product Instructions page 29

PART NO.
INLET CONNECTION*
OUTSIDE DIAMETER
OVERALL LENGTH
PATTERN 1
FLEX OR RIGID LANCES
PATTERN 2
FLEX OR RIGID LANCES
PATTERN 3
FLEX OR RIGID LANCES
PATTERN 4
FLEX OR RIGID LANCES
PATTERN 5
FLEX OR RIGID LANCES
PATTERN 6
RIGID LANCE ONLY
PATTERN 7
RIGID LANCE ONLY
* Copper crush washer required for flat seal connections. See table below.
SIZE
M7
1/8" BSPP
1/4" BSPP
May 2017
FM / FB SERIES TUBE CLEANING NOZZLES
F M 7
M7 FLAT SEAL
3 . 5 7 | 9 5 . m m
8 . ˝ 5 | 1 2 6 . m m
PATTERNS - NUMBER OF JETS BY LOCATION
1 Front
6 Back 30°
7 Jets Total
Min Flow #2
1 Front
12 Back 30°
13 Jets Total
Min Flow #5
1 Front
3 Forward 45°
6 Back 30°
10 Jets Total
Min Flow #4
1 Front
3 Forward 45°
8 Back 30°
12 Jets Total
Min Flow #5
1 Front
3 Forward 45°
6 Radial
6 Back 30°
16 Jets Total
Min Flow #6
1 Front
6 Radial
7 Jets Total
Min Flow #2
1 Front
12 Radial
13 Jets Total
Min Flow #5
PART NO.
59932
59933
59934
PI-123
F 2 B
1/8˝ BSPP FLAT SEAL
5 . 0 0 | 2 1 7 . m m
8 . ˝ 8 | 2 2 4 . m m
1 Front
6 Back 30°
7 Jets Total
Min Flow #2
1 Front
12 Back 30°
13 Jets Total
Min Flow #5
1 Front
3 Forward 45°
6 Back 30°
10 Jets Total
Min Flow #4
1 Front
3 Forward 45°
8 Back 30°
12 Jets Total
Min Flow #5
1 Front
3 Forward 45°
6 Radial
6 Back 30°
16 Jets Total
Min Flow #6
1 Front
6 Radial
7 Jets Total
Min Flow #2
1 Front
12 Radial
13 Jets Total
Min Flow #5
B F 4
1/4˝ BSPP FLAT SEAL
6 . 5 6 | 6 1 9 . m m
1 1 . ˝ 6 | 9 2 5 . m m
1 Front
8 Back 30°
9 Jets Total
Min Flow #4
1 Front
16 Back 30°
17 Jets Total
Min Flow #6
1 Front
3 Forward 45°
8 Back 30°
12 Jets Total
Min Flow #5
1 Front
3 Forward 45°
12 Back 30°
16 Jets Total
Min Flow #6
1 Front
3 Forward 45°
8 Radial
8 Back 30°
20 Jets Total
Min Flow #7
1 Front
8 Radial
9 Jets Total
Min Flow #4
1 Front
16 Radial
17 Jets Total
Min Flow #6
