Section 2: Product Description

The Tube Spinning Nozzle is assembled from three components: the
nozzle body, the sleeve, and the front nozzle (multiple types available).
The sleeve spins at an ultra-high rpm to provide streak-free cleaning and
polishing in a single pass. The front nozzle blasts free large deposits and
provides propulsion. The nozzle is self-propelling and can be used on
both rigid and flexible tube cleaning lances. Optional thrusters are
available for NPT connection tube spinning nozzles to provide additional
thrust for pulling through tubes. Depending on the connection type, the
Tube Spinning Nozzle is rated to 15,000 psi (NPT, M7, and BSPP),
20,000 psi (5/16-24 x ¼ MP), or 22,000 psi (MP LH/RH).
Product Specifications
Model Name
Maximum Operating Pressure (psi)
Minimum Operating Pressure (psi)
Maximum Flow (gpm)
Maximum Operating Pressure (bar)
Minimum Operating Pressure (bar)
Maximum Flow (l/min)
Inlet Connection
Cap Nozzles Accepted
NOTE: See Appendix B for list of PNs and accessories.
14
Tube Spinning Nozzle
15K / 20K / 22K
3000
35
1000 / 1400 / 1500
200
132
BSPP, M7, MP, NPT, 5/16-24
FB, FM, FP, HPEL, HPER,
HPFR, HPFL
