JETStream PI-123 Product Instructions page 33

NOZZLES SHOWN AS
ACTUAL SIZE
HPFR1
PART NO.
HPF BLANK PART NO. 64259
1/4˝ MP Tube RH
INLET CONNECTION
Female
OVERALL LENGTH .71 in |
OUTSIDE DIAMETER
PATTERN 1
FLEX OR RIGID LANCES
PATTERN 2
FLEX OR RIGID LANCES
PATTERN 3
FLEX OR RIGID LANCES
PATTERN 4
FLEX OR RIGID LANCES
PATTERN 5
FLEX OR RIGID LANCES
PATTERN 6
FLEX OR RIGID LANCES
May 2017
HPFR/HPFL TUBE CLEANING NOZZLES
HPFL1
54242
1/4˝ MP Tube LH
Female
18.0 mm .71 in | 18.0 mm
.375 in | 9.5 mm
PATTERNS - NUMBER OF JETS BY LOCATION
1 Front
6 Back
Min Flow #3
1 Front
8 Back
Min Flow #4
1 Front
3 Forward
6 Back
Min Flow #4
1 Front
3 Forward
8 Back
Min Flow #5
3 Forward
3 Radial
6 Back
Min Flow #5
1 Front
3 Radial
6 Back
Min Flow #4
HPFR2 HPFL2
64260 54243
3/8˝ MP Tube RH 3/8˝ MP Tube LH
Female Female
.87 in | 22.1 mm .87 in |
.50 in | 12.7 mm
1 Front
6 Back
Min Flow #3
1 Front
8 Back
Min Flow #4
1 Front
3 Forward
6 Back
Min Flow #4
1 Front
3 Forward
8 Back
Min Flow #5
4 Forward
4 Radial
6 Back
Min Flow #5
1 Front
4 Radial
6 Back
Min Flow #5
PI-123
HPFR3
64261
9/16˝ MP Tube RH
Female
22.1 mm 1.15 in | 29.2 mm
.75 in |
1 Front
8 Back
Min Flow #4
1 Front
12 Back
Min Flow #5
1 Front
3 Forward
8 Back
Min Flow #5
1 Front
3 Forward
12 Back
Min Flow #6
4 Forward
4 Radial
8 Back
Min Flow #6
1 Front
4 Radial
8 Back
Min Flow #5
HPFL3
54244
9/16˝ MP Tube LH
Female
1.15in | 29.2 mm
19.1 mm
33
