vary from this illustration.
Component
Kensington lock
slot (optional)
Voltage switch
Power connector
PS/2 keyboard
port
Monitor (VGA)
port
USB ports
Microphone jack
(pink plug)
Headphone/analo
g speakers jack
(green plug)
-OR-
Front speakers
jack
PS/2 mouse port
Ethernet
(network) jack
4
Chapter 1: Checking Out Your Computer
Important
Your computer's hardware options and port locations may
Icon
Description
Connects to a Kensington-compatible
computer security lock.
The switch is preset at the factory.
Make sure that this is set to the
correct voltage for your area.
Plug the power cord into this
connector.
Plug a PS/2 keyboard into this port.
Plug a VGA (blue connector) monitor
cable into this port.
Plug USB (Universal Serial Bus) devices
(such as a USB Iomega™ Zip™ drive,
printer, scanner, camera, keyboard, or
mouse) into these ports.
Plug a microphone into this jack.
This jack is user configurable for one
of the following:
Headphone: Plug headphones or
amplified speakers into this jack
(Default).
Stereo out: Plug your front left and
right speakers into this jack.
Plug a PS/2 mouse into this port.
Plug an Ethernet network cable or a
device (such as a DSL or cable modem
for a broadband Internet connection)
into this jack.
