Back view

1
2
No. Item
1 Card reader slot
2 Micro USB port (Slave)
3 DC-in jack
4 HDMI port (MHL)
5 VGA port
6 Audio in jack
7 Ethernet (RJ-45) port
8 USB hub port
9,10 USB ports (Master)
11 3.5 mm headphone jack
8
3 4 5 67 8
Description
Insert a memory card.
Connects to your PC for ADB and MTP function.
Connects to the DC power supply.
Supports high-definition digital video connections.
Connect the VGA video cable to the computer.
Connect the audio cable to the computer.
Connects to an Ethernet network.
Connects to your PC to enumerate all devices on
the USB ports (see 9 and 10).
Connects with external USB devices, such as a
keyboard, mouse or storage device.
Connects to stereo headphones.
11
10
9
