Owner's Manual & Assembly Instructions
BB01
Model No.
708521207
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
10' x 8'
121" x 92 3/4"
3,0m x 2,3m 307cm x 236cm
ED108
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
Width
74
470
123 1/4"
6,9m
13,3m
313cm
2
3
GD108-B
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Exterior Dimensions
(Roof Edge to Roof Edge)
Depth
Height
95 1/4"
82 1/8"
242cm
209cm
Interior Dimensions
(Wall to Wall)
Width
Depth
Height Width Height
118 1/4"
90"
80 7/8" 55 1/2" 69 1/4"
300cm
229cm
205cm
Door
Opening
141cm 176cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ED108 and is the answer not in the manual?

Questions and answers

Related Manuals for Arrow ED108

Summary of Contents for Arrow ED108

  • Page 1 Owner's Manual & Assembly Instructions BB01 Model No. ED108 GD108-B CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 708521207 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
  • Page 2 Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct a foundation and anchoring system of your choice.

  • Page 3: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
  • Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
  • Page 6 ATTIC KIT / WORKBENCH KIT augers into the ground. For buildings larger than 10'x9', use 2 kits. Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They Model No. AK100 install quickly and easily to help New concrete anchor system permits...
  • Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 9 OPTION 1: ARROW FLOOR FRAME KIT: (Order No. FB109-A or 68385-A) Arrow has the best base for your building in this simple kit. It keeps stored items above the ground. This kit should be used with one of the following: A.
  • Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
  • Page 11 Roof Beam Bracket (4) Handle (2) Weather Stripping (1) (6 sheets of 40) 66183 66769 66382 Roof Trim Cap 67468 (Arrow Logo) Lower Door Guide (4) (2 right & 2 left) Door Slide (4) Peak Cap (2) 6228 Track Support (2)

  • Page 12: Parts List

    Parts List BB12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 8934 Ramp 9367 Front Floor Frame 8936 Rear Floor Frame 9338 Right Rear Wall Angle 9366 Door Track 5287 Splice Post 9339 Left Rear Wall Angle 6001 Left Gable 6000...
  • Page 13 Assembly by Key No. BB13 22 22...
  • Page 14 ● ● ● ● ● 8934 Ramp (1) ● Parts Needed For ● Step 1 ● ● ● ● ● 9367 Front Floor Frame (2) Floor Frame Assemblies ● ● ● ● ● 8936 Rear Floor Frame (2) ● ● ● ● ● 9203 Side Floor Frame (4) The front floor frame is made up of three pieces.

  • Page 15: Frame Assemblies

    ● ● ● ● ● 9338 Right Rear Wall Angle (1) ● Parts Needed For ● Step 2 ● ● ● ● ● 9339 Left Rear Wall Angle (1) Frame Assemblies ● ● ● ● ● 9340 Right Side Wall Angle (2) ●...
  • Page 16 ● Parts Needed For ● Step 3 ● ● ● ● ● 10470 Roof Beam (8) Roof Beam Assemblies The roof beams join the two gables and support the roof panels. The main roof beam is made up of four pieces 10470 overlapped back to back at the cen- ter.

  • Page 17: End View

    ● Parts Needed For ● Step 4 ● ● ● ● ● 6403 Door Track Splice (1) Door Track Assembly ● ● ● ● ● 9366 Door Track (2) NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall.
  • Page 18 Step 5 ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● ● ● ● ● ● Side Floor Assembly (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) RIGHT REAR 9203 STEP Assemble the four corners of the 8936 floor frame using two screws at each...

  • Page 19: Top View

    ● ● ● ● ● 5288 Corner Post (4) ● Parts Needed For ● Step 6 ● ● ● ● ● Door Track Assembly (1) Posts/Top Frames ● ● ● ● ● Rear Wall Angle Assembly (1) ● ● ● ● ● Side Wall Angle Assembly (2) NOTE The remainder of the building assembly requires many hours and more than one...
  • Page 20 Step 7 ● Parts Needed For ● ● ● ● ● ● 5287 Splice Post (3) Splice Post/Door Jamb ● ● ● ● ● 7311 Door Jamb (2) STEP The door jambs reinforce the door opening and provide an attractive ANGLED END OF SPLICE POST MUST trim.
  • Page 21 Step 8 ● Parts Needed For ● ● ● ● ● ● 9344 Siding Stud (6) Studs/Front Channel ● ● ● ● ● 9365 Front Wall Channel (2) The studs provide a surface for at- taching the siding panels. Following dimensions, measuring from the ends of angles, place a stud between each corner and splice post.

  • Page 22: Side Siding

    Step 9 ● Parts Needed For ● ● ● ● ● ● 8584 Side Siding (12) Side Siding Each screw in the wall requires a washer. Slide side siding into channels of corner and splice posts, flat edge upward, bottom edge down resting on floor frame.
  • Page 23 Step 10 ● Parts Needed For ● ● ● ● ● ● 8736 Rear Siding (6) Rear/Front Siding ● ● ● ● ● 8737 Front Siding (6) STEP STEP Slide rear siding into channel of corner and splice posts fastening to Fasten Top Center of rear frame as shown in previous Last Siding to Stud...
  • Page 24 ● Parts Needed For ● Step 11 ● ● ● ● ● 6000 Right Gable (2) ● ● ● ● ● 6001 Left Gable (2) Gable Assemblies ● ● ● ● ● 5971 Roof Beam Bracket (4) The gables go on top of the front and rear walls to support the roof beams.
  • Page 25 ● ● ● ● ● Left Gable Assemblies (2) ● Parts Needed For ● Step 12 ● ● ● ● ● Right Gable Assemblies (2) Gables/Braces ● ● ● ● ● 6635 Gable Brace (2) Lift and fasten a right and left gable, under angle at corner, to the rear wall angle with screws.
  • Page 26 Step 13 ● Parts Needed For ● ● ● ● ● ● Main Roof Beam (1) Roof Beams ● ● ● ● ● Single Roof Beam (2) Spread the two halves of the main STEP roof beam and fasten the roof beam to the gable brace of the front gable.
  • Page 27 ● Parts Needed For ● Step 14 ● ● ● ● ● 8468 Right Roof Panel (1) Right Roof Panel STEP Installing the roof panels is best done with a step ladder. Begin installing 8469 8468 roof panels at the back right corner of the building.

  • Page 28: Roof Assembly

    ● ● ● ● ● 8468 Right Roof Panel (1) ● ● ● ● ● 8469 Left Roof Panel (2) ● Parts Needed For ● Step 15 ● ● ● ● ● 7483 Roof Panel (2) Roof Assembly ● ● ● ● ● 6529 Roof Panel (2) ●...
  • Page 29 ● ● ● ● ● 8486 Ridge Cap (1) ● ● ● ● ● 7483 Roof Panel (2) ● Parts Needed For ● Step 16 ● ● ● ● ● 8486 Ridge Cap (1) Panels/Ridge Cap/Trim ● ● ● ● ● 8485 Left Side Roof Trim (2) ●...

  • Page 30: Door Assembly

    ● ● ● ● ● 3719 Door Handle Brace (2) ● Parts Needed For ● Step 17 ● ● ● ● ● 10472 Right and Left Doors (2) Door Assembly ● ● ● ● ● 10497 Horizontal Door Brace (4) ●...
  • Page 31 ● Parts Needed For ● Step 18 ● ● ● ● ● Right Door Assembly (1) Door Installation & Adjustment ● ● ● ● ● Left Door Assembly (1) Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the building) behind door jamb into the...
  • Page 32 ED108 GD108-B BB32 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
