722750117
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
Customer Service:
1-800-851-1085
assist@arrowsheds.com
BUILDING DIMENSIONS
†
Approx.
Storage
Size
10' x 8'
71 Sq. Ft. 502 Cu. Ft.
3,0 m x 2,4 m
6,6 m
* See Inside for Detailed Safety Information.
Model No.
EZ10872HVCR
EZ10872HVCRCC
EZ10872HVCC
EZ10872HVCCCR
or
†
Size rounded off to the nearest foot
Exterior Dimensions
(Roof Edge to Roof Edge)
Area
Width
117 3/4"
2
14,2 m 3
299 cm
249 cm
Depth
Height
Width
98"
98"
114"
249 cm
289,6 cm
www.arrowsheds.com
EZ10872HVCREU
EZ10872HVCRCCEU
EZ10872HVCCEU
EZ10872HVCCCREU
10' x 8'
EZEE SHED
Base
116 1/2" x 92 1/2"
Size
296 cm x 235 cm
For proper base construction see page 14
Interior Dimensions
(Wall to Wall)
Depth
Height
90"
97"
228,6 cm
246,4 cm
01CH
Nominal Size
TM
Door
Opening
Width
Height
63 1/2"
69 3/4"
161,3 cm
177,2 cm
