Arrow EZ8772HVCR Owner's Manual And Assembly Manual

8’ x 7, ezee shed
Hide thumbs
Table of Contents

Advertisement

Quick Links

722660317
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
Customer Service:
1-800-851-1085
assist@arrowsheds.com
BUILDING DIMENSIONS
†
Approx.
Storage
Size
8' x 7'
49 Sq. Ft. 329 Cu. Ft.
2,4 m x 2,1 m
4,5 m
* See Inside for Detailed Safety Information.
Model No.
EZ8772HVCRCC
EZ8772HVCCCR
or
†
Size rounded off to the nearest foot
Exterior Dimensions
(Roof Edge to Roof Edge)
Area
Width
93 3/4"
2
9,3 m 3
238,1 cm
218,4 cm
EZ8772HVCR
EZ8772HVCC
Depth
Height
Width
86"
91"
90"
231,1 cm
228,6 cm
www.arrowsheds.com
EZ8772HVCREU
EZ8772HVCRCCEU
EZ8772HVCCEU
EZ8772HVCCCREU
8' x 7'
EZEE SHED
Base
92 1/2" x 80 1/2"
Size
235 cm x 204,4 cm
For proper base construction see page 14
Interior Dimensions
(Wall to Wall)
Depth
Height
78"
90"
198,1 cm
228,6 cm
01CG
Nominal Size
TM
Door
Opening
Width
Height
51 1/2"
69 3/4"
130,8 cm
177,2 cm

Advertisement

Table of Contents
loading

Related Manuals for Arrow EZ8772HVCR

Summary of Contents for Arrow EZ8772HVCR

  • Page 1 01CG 722660317 Owner’s Manual & Assembly Guide Model No. www.arrowsheds.com EZ8772HVCR EZ8772HVCREU EZ8772HVCRCC EZ8772HVCRCCEU Gloves must be worn at all times to reduce EZ8772HVCC EZ8772HVCCEU risk of injury! EZ8772HVCCCR EZ8772HVCCCREU 8’ x 7’ Nominal Size EZEE SHED Customer Service: 1-800-851-1085 Base 92 1/2”...
  • Page 2 GB: Assembly manual in additional languages available online. Scan QR code below to access. FR: Manuel de montage disponible en ligne dans d’autres langues. Pour y accéder, scannez le code QR ci-dessous. SP: Manual de montaje en idiomas adicionales disponible online. Escanee el código QR a continuación para acceder.
  • Page 3 SAFETY PRECAUTIONS... 02CG Safety precautions MUST be followed at all times throughout the construction of your building! Practice caution with the tools being used in the Care must be taken when handling various pieces assembly of this building. Be especially familiar with of your building since many contain sharp edges.

  • Page 4: What You Need

    ASSEMBLY TIPS & TOOLS Watch the Weather Closely: Be sure the day you choose to install your building is dry and calm. Do NOT attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Use Teamwork: Two or more people are required to assemble your building.

  • Page 5: Frequently Asked Questions

    FREQUENTLY ASKED QUESTIONS How long will it take to assemble the building? Assembly time depends on a variety of factors, including roof design, tools available, DIY skill and the pace at which you work. Guidelines for each shed assembly are approximate AFTER completion of the base, and assume two or more people working on the assembly.
  • Page 6 Arrow provides a base kit accessory that is an option for most building sizes. If you are building a wood deck/fl oor, an Arrow fl oor frame kit on top of your deck/fl oor assembles in minutes and provides a fl oor frame suitable for a 5/8”...
  • Page 7 What if the rear wall angle and channels are too large to fi t inside of the rear wall panels? Check the dimensions of wall assemblies. They should be slightly smaller than the fl oor frames. Lay the assemblies on top of the rear fl oor frame and pull them up to the top of the wall panels causing the corner panels to stand erect and not lean inward.
  • Page 8 Keep the roof clear of leaves and snow. Heavy amounts of snow on the roof can damage the building making it unsafe to enter. In snow country, Roof Strenghtening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
  • Page 9 HARDWARE LIST... 08CG Hardware Views by Key No. Key Part Part Qty. Description List #2 Phillips 11/32 Hex. 65923 Bolt (#8-32 x 3/8) (10 mm) 65103 Hex Nut (#8-32) 65004 Screw (#8AB x 5/16) (8 mm) 66646 Washer Sheet 66715 Door Handle #2 Phillips 66718...
  • Page 10 PARTS LIST... 09CG Key Part Part Qty. Selected End Views by Key No. Description List 10340 Floor Channel (unpainted) 1,3,4,5,8 2 & 9 10292 Ramp (unpainted) 10301 Door Brace Horizontal (painted) 11017 Door Brace Vertical (painted) 11027 Door Brace Vertical (painted) 10,11,15 11024 Door Jamb...
  • Page 11 ASSEMBLY BY KEY NO. 10CG Walls Floor...
  • Page 12 ASSEMBLY BY KEY NO. 11CG Roof Doors...

  • Page 13: Assembly Overview

    ASSEMBLY OVERVIEW 12CG Build Side Wall Assemblies Build Rear Wall Assembly Build Front Wall Assembly Assemble Walls Install Gables and Roof Beam Build Roof Assemblies...
  • Page 14 ASSEMBLY OVERVIEW 13CG Install Roof Panels Install Trim Install the Door and you now have a fi nished shed...
  • Page 15 CONSTRUCTING A BASE... 14CG OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.). Allow 1 - 2 hours for construction. OPTION 2: Wood Platform If you decide to build your own base, be sure to select the appropriate materials. These are the recommended materials for your base: •...

  • Page 16: Step 1: Side Walls

    Be cautious when maneuvering and placing Panels. Once Panels begin to go up it is important to be able to fi nish in a timely manner to reduce ARROW TO TOP the possibility of wind damage to your building. 11000...
  • Page 17 Step 1: Continued 16CG MUST USE FLAT SOLID SURFACE. DO NOT SNAP ON GROUND OR GRASS Top Panel ALWAYS COVER THE ARROW Raise Panel at Angle. Top Panel Bottom Panel Overlap Panels maintaining and Align Ends. pressure Always cover Bottom Panel the Arrow.
  • Page 18 Step 1: Continued 17CG You will need for this page: ARROW TO TOP (QTY: 8) Install Corner Panel. Cover Arrow on Corner CORNER PANEL Panel. 11000 10999 Use edge of surface, like your carton, to allow Corner Panel to hang down.
  • Page 19 Step 1: Continued 18CG You will need for this page: 11019 10305 10297 (QTY: 4) (QTY: 4) Channel Wall Channel Floor Channel Splice Make two (2) Wall Channel Assemblies (Painted). 10305 11019 10305 10305 11019 10305 Make two (2) Floor Channel Assemblies (Unpainted).
  • Page 20 WALL CHANNEL ASSEMBLY Align Wall Channel Assembly (Painted) to Panel Ribs and pop into place at Corner. ARROW TO TOP ELEVATED PLATFORM C o n t i n u e a l i g n i n g Channel Assembly and popping into place.
  • Page 21 Step 1: Continued 20CG You will need for this page: IMPORTANT 10280 START ASSEMBLY AT CORNER PANEL CORNER MUST BE AGAINST Floor Channel 45 DEGREE CUT ON CHANNEL Corner Clip Assembly Attach Floor Channel Assembly (Unpainted). ELEVATE PANELS TO MAKE INSTALLING WALL CHANNEL Channel ASSEMBLY EASIER...

  • Page 22: Step 2: Rear Wall

    Panel Wall Corner Panel Make one (1) Be cautious when maneuvering and placing ARROW TO TOP Rear Wall Section. Panels. Once Panels begin to go up it is important to be able to fi nish in a timely manner to reduce the possibility of wind damage to your building.
  • Page 23 Step 2: Continued 22CG You will need for this page: 11019 10341 10340 Channel (QTY: 2) (QTY: 2) Wall Channel Floor Channel Splice Make one (1) Wall Channel Assembly (Painted). 10341 11019 10341 Make one (1) Floor Channel Assembly (Unpainted). 10340 11019 10340...
  • Page 24 Align Wall Channel Assembly to Panel Ribs and pop into place at Corner. WALL CHANNEL ASSEMBLY (Painted) ARROW TO TOP ELEVATED PLATFORM C o n t i n u e a l i g n i n g Channel Assembly and popping into place.
  • Page 25 Step 2: Continued 24CG You will need for this page: IMPORTANT 10280 START ASSEMBLY AT CORNER PANEL CORNER MUST BE AGAINST Floor Channel Corner Clip Assembly 45 DEGREE CUT ON CHANNEL Attach Floor Channel Assembly (Unpainted). ELEVATE PANELS TO MAKE INSTALLING WALL CHANNEL Channel ASSEMBLY EASIER...

  • Page 26: Step 3: Front Wall

    11000 10999 (QTY: 6) (QTY: 2) Corner Panel Door Jamb Panel Wall Make one (1) MUST USE FLAT SOLID ARROW TO TOP SURFACE. DO NOT SNAP ON Front Wall Section. GROUND OR GRASS. DOOR JAMB 11024 DOOR JAMB 11024 10999...
  • Page 27 Step 3: Continued 26CG You will need for this page: 11019 10341 10340 10291 10292 Channel (QTY: 4) (QTY: 2) Wall Channel Floor Channel Header Trim Splice Ramp Make one (1) Wall Channel 10341 Assembly (Painted). 11019 10341 Make one (1) Floor Channel 10340 Assembly (Unpainted).
  • Page 28 Step 3: Continued 27CG IMPORTANT You will need for this page: 10280 START ASSEMBLY AT CORNER PANEL CORNER MUST BE AGAINST Floor Channel Wall Channel 45 DEGREE CUT ON CHANNEL Corner Clip Assembly Assembly Channel Attach Wall Channel Assembly (Painted). WALL CHANNEL ASSEMBLY (Painted) CORNER CLIP...
  • Page 29 Step 3: Continued 28CG You will need for this page: (QTY: 4) (QTY: 4) Secure Wall Channel Secure Header Trim to Assembly (Painted) Wall Channel Assembly using two (2) washers (Painted) using two (2) and screws. washers and screws. Secure Ramp to Floor Channel Secure Floor Channel Assembly Assembly (Unpainted) using two (Unpainted) using two (2) screws.

  • Page 30: Step 4: Wall Assembly

    Step 4: Wall Assembly 29CG You will need for this page: Side Wall Rear Wall Assembly Assembly (QTY: 4) IT IS HIGHLY RECOMMENDED THAT AT LEAST 2 PEOPLE ARE PART OF ASSEMBLY. CORNER PANEL ON TOP Attach Side Wall and Rear Wall.
  • Page 31 Step 4: Continued 30CG You will need for this page: Side Wall Front Wall Assembly Assembly Install Corner Clip Upper IT IS HIGHLY RECOMMENDED THAT AT LEAST 2 PEOPLE ARE PART OF ASSEMBLY. Attach Side Wall and Front Wall. Make Sure CORNER PANEL ON TOP Engaged OF WALL PANEL...
  • Page 32 Step 4: Continued 31CG You will need for this page: (QTY: 12) Attach remaining Walls using four (4) washers and screws at each corner.
  • Page 33 32CG Step 5: Gable & Beam Assy You will need for this page: 7905 80115 11049 10994 11043 Gable Left Gable Right (QTY: 12) Roof Beam (QTY: 8) Header Angle Gable Brace Brace Install (REAR) Gable Right Snap Gables onto and Gable Left using three Gable (QTY: 4)
  • Page 34 33CG Step 5: Continued You will need for this page: 11020 (QTY: 18) Roof Beam Assemble Roof Beams using two (2) nuts and bolts. 11020 11020 11020 Overlap Length 11020 7” (17,8 cm) A t t a c h R o o f B e a m Assemblies together 80 3/4”...
  • Page 35 Step 6: Roof pre-assy 34CG You will need for this page: 11019 10334 10335 Channel (QTY: 8) Roof Channel Roof Channel Splice Make four (4) Roof Channel Assemblies (Painted). 10335 11019 10334 10335 11019 10334 10335 11019 10334 10335 11019 10334 Use rubber mallet and gently tap Channel Splice...
  • Page 36 Step 6: Continued 35CG You will need for this page: 11020 (QTY: 16) Roof Beam 11020 Make two (2) Roof Beam Assemblies using (8) nuts and bolts for each. 11020 11020 11020 Overlap Length 7” (17,8 cm) 80 3/4” (205,1 cm) Finished Length...
  • Page 37 (QTY: 8) Roof Panel Fascia Trim Right Left Assembly MUST USE FLAT SOLID Make two (2) ARROW TO TOP SURFACE. DO NOT SNAP Roof Sections. ON GROUND OR GRASS Overlap Panels and Align Ends. Snap panel ribs together. HOLES Always cover the Arrows.

  • Page 38: Side View

    11023 Roof Beam Assembly (QTY: 16) Ridge Cap Ridge Cap Attach Roof Beam Assembly (from ARROW TO TOP page. 35) to Roof Section using seven (7) washers and screws. 11013 80119 NOTE: LARGE HOLES IN ROOF BEAM ASSEMBLY FACE DOWN.

  • Page 39: Step 7: Roof Assembly

    Step 7: Roof Assembly 38CG You will need for this page: (QTY: 12) Attach Roof Sections using twelve (12) screws through Roof Beam- Center into Roof Channels. INSIDE OF BUILDING...
  • Page 40 Step 7: Continued 39CG You will need for this page: 66860 66847 (QTY: 22) (QTY: 12) Peak Cap Corner Cap Vent Attach Roof Sections to building using nine (9) washers and screws each. Place Peak Caps between Ridge Cap and Roof Sections 66860 secure using two (2) washers and screws each.
  • Page 41 Step 7: Continued 40CG You will need for this page: (QTY: 8) Attach Roof Beam Assembly to Roof Beam Brace using two (2) nuts and bolts each . TYPICAL (4) PLACES INSIDE OF BUILDING...
  • Page 42 Step 7: Continued 41CG You will need for this page: 9204 Roof Beam (QTY: 4 Brace Attach Roof Beam Brace to Gable Brace and Roof Beam-Center using two (2) nuts and bolts each . NOTE: FLANGE ON ROOF BEAM BRACE LOCATED BETWEEN ROOF GABLE BRACE BEAM-CENTER AT FOURTH (4) HOLE FROM END.

  • Page 43: Step 8: Right Door Assy

    Step 8: Right Door Assy 42CG You will need for this page: 11017 11026 11025 66715 66721 (QTY: 2) U-Nut (QTY: 6) Vertical Door Vertical Door Door Astragal Door Handle (Door Clip) Brace Brace Attach U-Nuts onto Vertical Door Brace. U-NUT (2X) TYPICAL (3) PLACES U-NUT (2X)
  • Page 44 Vertical Door Horizontal (QTY: 4) Door Panel Door Panel Brace Assy Door Brace ARROW TO TOP Overlap Door Panels, align ends and snap Panel Ribs together. MUST USE FLAT SOLID SURFACE. DO NOT SNAP ON GROUND OR GRASS. 11011 11010...
  • Page 45 Step 8: Continue 44CG You will need for this page: 10295 Diagonal (QTY: 3) (QTY: 8) Door Brace Turn Door over. Attach Diagonal Door Braces to Door Panels using three (3) screws. 10295 10295 Install four (4) washers and screws for Horizontal Door Braces.
  • Page 46 Step 9: Left Door Assy 45CG You will need for this page: 11017 11027 66721 66716 U-Nut Padlock (QTY: 2) Vertical Door Vertical Door (Door Clip) Eyelet Brace Brace Attach U-Nuts onto Vertical Door Brace. U-NUT (2X) TYPICAL (3) PLACES U-NUT (2X) 11017 U-NUT (2X)
  • Page 47 Vertical Door Horizontal (QTY: 4) Door Panel Door Panel Brace Assy Door Brace ARROW TO TOP Overlap Door Panels, align ends and snap Panel Ribs together. MUST USE FLAT SOLID SURFACE. DO NOT SNAP ON GROUND OR GRASS 11011 11010...
  • Page 48 Step 9: Continue 47CG You will need for this page: 10295 66719 66713 Diagonal Spring Pin Spring Pin (QTY: 7) (QTY: 8) Door Brace Upper Lower Turn Door over. Attach Diagonal Door Braces to Door Panels using three (3) screws. SPRING PIN UPPER Install four (4) washers and screws for Horizontal Door Braces.

  • Page 49: Step 10: Door Assembly

    Step 10: Door Assembly 48CG You will need for this page: 66718 Right Door Left Door Assembly Assembly (QTY: 14) (QTY: 12 Hinge Attach Right Door Assembly and Left Door Assembly to Hinges using two (2) screws in each hinge. Attach three (3) Hinges to each Door Jamb using two Secure Ramp to Floor Channel...

  • Page 50: How To Order

    Arrow is offering them to you on a direct basis. Purchase Online at www.arrowsheds.com Purchase over the phone by calling 1-800-851-1085...
  • Page 51 It is important that building be anchored after construction. these are recommended ways of anchoring. Anchor into Wood or Concrete Arrow Anchoring Kit: (Model No. AK100 or 68383) For wood platform. Use Decking Screws. Recommended for use with the concrete base.

  • Page 52: Assembly Notes

    ASSEMBLY NOTES...
