Owner's Manual & Assembly Instructions
B01
Model No.
709321207
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
8' x 6'
97 1/2" x 68 3/4"
2,4m x 1,7m 248cm x 175cm
EN86-A
MN86-A
NW86PC
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
43
230
4,0m
2
6,5m
3
253cm
HM86-A
NP86
SA86-A
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
Height
99 3/4"
71 1/4"
67 7/8"
181cm
172cm
HM86M
NW86-A
VN86-A
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Width
Depth
Height Width Height
94 3/4"
66"
241cm
168cm
169cm
Door
Opening
66 5/8" 43 1/2"
58"
110cm 147cm
Advertisement
Related Manuals for Arrow EN86-A
Summary of Contents for Arrow EN86-A
- Page 1 Owner's Manual & Assembly Instructions Model No. EN86-A HM86-A HM86M MN86-A NP86 NW86-A NW86PC SA86-A VN86-A CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES 709321207 TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
- Page 2 Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct a foundation and anchoring system of your choice.
-
Page 3: Tools And Materials
PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building. - Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
- Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
- Page 6 For buildings ATTIC KIT / WORKBENCH KIT larger than 10'x9', use 2 kits. Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They Model No. AK100 install quickly and easily to help New concrete anchor system permits...
- Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 9 OPTION 1: ARROW FLOOR FRAME KIT: (Order No. FB106-A or 68381-A) Arrow has the best base for your building in this simple kit. It keeps stored items above the ground. This kit should be used with one of the following: A.
- Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
- Page 11 (Packed with Screws) 65109 67468 66646 #8-32 Acorn Nut (6) Peak Cap (2) 66045 Washer (275) (Packed with Screws) (Arrow Logo) Handle (2) (8 sheets of 40) 66183 7916 66382 Roof Trim Cap 66769 Roof Beam Bracket (4) Lower Door Guide (4) (2 right &...
-
Page 12: Parts List
Parts List Assembly Part Part Quantity Check Key No. Number Description in Carton List 6615 Rear Wall Angle 6617 Door Track Splice 10498 Horizontal Door Brace 6658 Gable Brace 7875 Roof Panel 7906 Right Gable 7907 Left Gable 8461 Ridge Cap 8466 Right Roof Panel 8467... - Page 13 Assembly by Key No.
- Page 14 ● ● ● ● ● 8941 Ramp (1) ● Parts Needed For ● Step 1 ● ● ● ● ● 9379 Front Floor Frame (2) Floor Frame Assemblies ● ● ● ● ● 9377 Rear Floor Frame (2) The front floor frame is made up of three pieces.
-
Page 15: Frame Assemblies
● Parts Needed For ● ● ● ● ● ● 6615 Rear Wall Angle (2) Step 2 ● ● ● ● ● 9924 Rear Wall Channel (2) Frame Assemblies The main frame pieces reinforce the Rear Wall Channel walls. These pieces will later be in- 94 5/8"... - Page 16 ● Parts Needed For ● ● ● ● ● ● 8474 Roof Beam (1) Step 3 ● ● ● ● ● 8476 Side Wall Angle (1) Roof Beam Assembly The roof beams join the two gables and support the roof panels. The main roof beam is made up of two pieces fastened together.
- Page 17 ● Parts Needed For ● ● ● ● ● ● 6617 Door Track Splice (1) Step 4 ● ● ● ● ● 9378 Door Track (2) Door Track Assembly NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall.
- Page 18 ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● Step 5 ● ● ● ● ● 8946 Side Floor Frame (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) RIGHT REAR 8946 STEP 8946 9377...
- Page 19 ● Parts Needed For ● ● ● ● ● ● 9380 Front Corner Panel (2) Step 6 ● ● ● ● ● 9384 Rear Corner Panel (2) Corners NOTE Wide The remainder of the building assembly Side requires many hours and more than one 9384 person.
- Page 20 ● ● ● ● ● Door Track Assembly (1) ● Parts Needed For ● ● ● ● ● ● Rear Wall Angle Assembly (1) Step 7 ● ● ● ● ● 8476 Side Wall Angle (2) Frames ● ● ● ● ● Rear Wall Channel Assembly (1) ●...
- Page 21 ● Parts Needed For ● ● ● ● ● ● 8995 Wall Panel (4) Step 8 ● ● ● ● ● 9363 Wall Panel (2) Wall Panels The wall panels come in two widths. STEP Each wall panel has a crimped rib on 9363 9363 one side.
- Page 22 ● Parts Needed For ● Step 9 ● ● ● ● ● 9900 Door Jamb (2) Door Jamb INSIDE OF BUILDING TOP VIEW (3) bolts Door Track Acorn Nut 9900 Bolt The door jambs reinforce the door Cross-Section Top View opening and provide an attractive Plug TOP VIEW...
- Page 23 ● Parts Needed For ● ● ● ● ● ● 7906 Right Gable (2) Step 10 ● ● ● ● ● 7907 Left Gable (2) Gable Assemblies ● ● ● ● ● 7916 Roof Beam Bracket (4) The gables go on top of the front and rear walls to support the roof beams.
- Page 24 ● ● ● ● ● Left Gable Assembly (2) ● Parts Needed For ● Step 11 ● ● ● ● ● Right Gable Assembly (2) Gables/Braces ● ● ● ● ● 6658 Gable Brace (2) Lift and fasten a right and left gable, under angle at corner, to the rear wall angle with screws.
- Page 25 ● Parts Needed For ● ● ● ● ● ● Main Roof Beam (1) Step 12 ● ● ● ● ● 8474 Roof Beam (2) Roof Beams Fasten the main roof beam to the gable brace of the front gable. STEP Fasten the other end of the main roof beam to the gable brace of the...
- Page 26 ● Parts Needed For ● Step 13 ● ● ● ● ● 8466 Right Roof Panel (1) Right Roof Panel STEP Installing the roof panels is best done with a step ladder. Begin installing roof panels at the back right corner of 8466 8467 the building.
- Page 27 ● Parts Needed For ● ● ● ● ● ● 8467 Left Roof Panel (2) Step 14 ● ● ● ● ● 7875 Roof Panel (4) Roof Assembly ● ● ● ● ● 8466 Right Roof Panel (1) STEP STEP 8467 Left Roof Panel Weather Stripping Tape Roll...
- Page 28 ● Parts Needed For ● Step 15 ● ● ● ● ● 8461 Ridge Cap (1) Ridge Cap Install the ridge cap on the com- pleted roof section using bolts and nuts. Do not fasten the ends of the ridge cap at this time. Fasten the lower end of the panels to the side wall angles using screws and washers.
- Page 29 ● Parts Needed For ● Step 16 ● ● ● ● ● 8482 Side Roof Trim (2) Roof Trim Attach the side roof trim to the lower end of the roof panels on each side of the building using screws at each panel overlap.
-
Page 30: Door Assembly
● ● ● ● ● 10488 Right and Left Doors (2) ● Parts Needed For ● Step 17 ● ● ● ● ● 10498 Horizontal Door Brace (4) Door Assembly ● ● ● ● ● 9355 Vertical Door Brace (2) The steps on this page tell how to assemble the right door. - Page 31 ● Parts Needed For ● ● ● ● ● ● Right Door Assembly (1) Step 18 ● ● ● ● ● Left Door Assembly (1) Door Installation & Adjustment Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP...
- Page 32 EN86-A HM86-A HM86M MN86-A NP86 NW86-A NW86PC SA86-A VN86-A SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
