Owner's Manual & Assembly Instructions
BS1
Model No.
707740904
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
4' x 10'
50 1/2" x 116 3/4"
1,2m x 2,9m 128cm x 297cm
YS410-A
697.68602
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
38
227
3,5m
2
6,4m
3
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
Height
49"
116"
82"
124cm
295cm
208cm
EV410-A
Interior Dimensions
(Wall to Wall)
Width
Depth
Height Width Height
47 3/4"
114"
81 1/4" 38 1/2" 60 1/4"
121cm
290cm
206cm
Door
Opening
98cm
153cm
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Arrow EV410-A
Summary of Contents for Arrow EV410-A
- Page 1 Owner's Manual & Assembly Instructions Model No. YS410-A EV410-A 697.68602 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 707740904 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
- Page 2 A foundation is also necessary as a base in order to construct a square and level building. Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Foundation Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct the foundation and anchoring system of your choice.
-
Page 3: Tools And Materials
PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building. - Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
- Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
- Page 6 ATTIC KIT / WORKBENCH KIT FLOOR FOUNDATION KITS Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They install quickly and easily to help organize space and create more useable space as an attic or workbench.
- Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 9 OPTION 1: ARROW FLOOR FOUNDATION KIT: (Order No. FB47410) Arrow has the best base for your building in this simple kit. It keeps stored items above the ground. This foundation should be used with one of the following: A. To support a plywood deck B. To be filled with sand. We recommend the combined use of 1.
- Page 10 Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia. holes provided in the frames for proper anchoring. Anchoring into Concrete: Arrow Anchoring Kit: (Model No. AK100 or 68383) 1. For poured concrete slab or footing or patio blocks: Recommended for use with the concrete foundation.
- Page 11 Hardware BS11 65941 65103 #6-32 Hex Nut (22) 65004 65923 #8-32 Hex Nut (68) (Packed with Screws) #8Ax5/16" Screw (306) #8-32x3/8" Bolt (68) 66714 66646 66645 66022 #6-32x7/16" Flat Hd Bolt (16) Washer (276) #6-32x3/4" Flat Hd Bolt (6) Gray Foam Tape (2) (Packed with Screws) (8 sheets of 40) (Packed with Screws)
-
Page 12: Parts List
Parts List... - Page 13 Assembly by Key No.
-
Page 14: Door Assembly
9794 Horizontal Door Brace (4) Parts Needed For 9788 Right Door (1) Step 1 9787 Left Door (1) Door Assembly 67729 Foam Board (2) - Page 15 9796 Ramp (1) Parts Needed For Step 2 9795 Floor Frame (2) Floor Frame Assembly 8976 Side Floor Frame (4) BS15 Overlap the side floor frames as 8976 shown. The holes in these pieces will STEP align when the pieces are positioned with correct amount of overlap.
- Page 16 Parts Needed For 9793 Corner Post (2) Step 3 Corner Posts/Rear Siding 8075 Rear Siding (1)
- Page 17 6481 Gusset (4) Parts Needed For 9793 Corner Post (2) Step 4 8433 Siding Stud (1) Corner Posts/Studs/Siding 8434 Siding Stud (1) 8431 Side Siding (4)
- Page 18 9791 Front Header (1) Parts Needed For 8437 Side Eave Frame (2) Step 5 8062 Rear Header (1) Headers/Frames/Jambs 9789 Left Door Jamb (1) 9790 Right Door Jamb (1)
- Page 19 8431 Side Siding (4) Parts Needed For 8075 Rear Siding (1) Step 6 Side/Rear Siding/Studs 8067 Siding Stud (5) 8068 Siding Stud (4)
- Page 20 8061 Left Gable (1) Parts Needed For 8060 Right Gable (1) Step 7 8438 Side Peak Frame (2) Gables/Peak/Roof Frames 8066 Roof Frame (4) 8435 Roof Frame (1) NOTE The gables are packed nested together and might be mistaken as one piece.
- Page 21 Parts Needed For Step 8 8431 Side Siding (4) Side Siding/Foam Tape...
- Page 22 8432 Top Siding (2) Parts Needed For 8439 Peak Trim (2) Step 9 8442 Rear Siding Trim (1) Top Siding/Trim 8078 Right Wall Trim (1) 8079 Left Wall Trim (1) 8076 Right Roof Trim (1) 8077 Left Roof Trim (1) 8440 Bottom Siding Trim (1) 8441 Top Siding Trim (1)
- Page 23 8082 Drip Cap (1) Parts Needed For Right Door Assembly (1) Step 10 Drip Cap/Door Stop Left Door Assembly (1) 9792 Door Stop (1)
- Page 24 YS410-A EV410-A 697.68602 BS24 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
