Owner's Manual & Assembly Instructions
PN01
Model No.
711251207
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
10' x 6'
121" x 68 3/4"
3,0m x 1,7m 307cm x 175cm
ED106
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
Width
54
345
123 1/4"
5,0m
2
9,8m
3
313cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Exterior Dimensions
(Roof Edge to Roof Edge)
Depth
Height
71 1/4"
82 1/8"
181cm
209cm
GD106-B
GDF106-A
Interior Dimensions
(Wall to Wall)
Width
Depth
Height Width Height
118 1/4"
66"
80 7/8" 55 1/2" 69 1/4"
300cm
168cm
205cm
Door
Opening
141cm 176cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ED106 and is the answer not in the manual?

Questions and answers

Jane Britton
April 10, 2025

where can I buy replacement door handles for ED106 in the UK?

1

Subscribe to Our Youtube Channel

Related Manuals for Arrow ED106

Summary of Contents for Arrow ED106

  • Page 1 Owner's Manual & Assembly Instructions PN01 Model No. ED106 GD106-B GDF106-A CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 711251207 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
  • Page 2 Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct a foundation and anchoring system of your choice.
  • Page 3 PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
  • Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
  • Page 6 For buildings ATTIC KIT / WORKBENCH KIT larger than 10'x9', use 2 kits. Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They Model No. AK100 install quickly and easily to help New concrete anchor system permits...
  • Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 9 OPTION 1: ARROW FLOOR FRAME KIT: (Order No. FB106-A or 68381-A) Arrow has the best base for your building in this simple kit. It keeps stored items above the ground. This kit should be used with one of the following: A.
  • Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
  • Page 11 Handle (2) (5 sheets of 40) Roof Beam Bracket (4) Track Support (2) 66183 67468 66769 66382 Roof Trim Cap Peak Cap (1) Door Slide (4) Lower Door Guide (4) (2 right & 2 left) Arrow Logo 67293 Weather Stripping (1)

  • Page 12: Table Of Contents

    Parts List PN12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 8934 Ramp 9367 Front Floor Frame 8936 Rear Floor Frame 9338 Right Rear Wall Angle 9366 Door Track 6403 Door Track Splice 9339 Left Rear Wall Angle 6001 Left Gable 6000...

  • Page 13: Key No

    Assembly by Key No. PN13...

  • Page 14: 8934 Ramp

    ● ● ● ● ● 8934 Ramp (1) ● Parts Needed For ● Step 1 ● ● ● ● ● 9367 Front Floor Frame (2) Floor Frame Assemblies ● ● ● ● ● 8936 Rear Floor Frame (2) The front floor frame is made up of three pieces.

  • Page 15: 9338 Right Rear Wall Angle

    ● Parts Needed For ● ● ● ● ● ● 9338 Right Rear Wall Angle (1) Step 2 ● ● ● ● ● 9339 Left Rear Wall Angle (1) Frame Assembly The main frame pieces reinforce the walls. This piece will later be installed at the top edge of the rear wall.
  • Page 16 ● Parts Needed For ● ● ● ● ● ● 8474 Roof Beam (1) Step 3 ● ● ● ● ● 8476 Side Wall Angle (1) Roof Beam Assembly The roof beams join the two gables and support the roof panels. The main roof beam is made up of two pieces fastened together.

  • Page 17: 9366 Door Track

    ● Parts Needed For ● ● ● ● ● ● 6403 Door Track Splice (1) Step 4 ● ● ● ● ● 9366 Door Track (2) Door Track Assembly NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall.
  • Page 18 ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● Step 5 ● ● ● ● ● 8946 Side Floor Frame (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) RIGHT REAR 8946 STEP Assemble the four corners of the floor frame using two screws at each...

  • Page 19: 5288 Corner Post

    ● ● ● ● ● 5288 Corner Post (4) ● Parts Needed For ● ● ● ● ● ● Door Track Assembly (1) Step 6 ● ● ● ● ● Rear Wall Angle Assembly (1) Posts/Top Frames ● ● ● ● ● 9342 Side Wall Angle (2) NOTE The remainder of the building assembly requires many hours and more than one...

  • Page 20: 5287 Splice Post

    ● Parts Needed For ● ● ● ● ● ● 5287 Splice Post (1) Step 7 ● ● ● ● ● 7311 Door Jamb (2) Splice Post/Door Jamb STEP The door jambs reinforce the door opening and provide an attractive 5287 trim.

  • Page 21: 9344 Siding Stud

    ● Parts Needed For ● ● ● ● ● ● 9344 Siding Stud (6) Step 8 ● ● ● ● ● 9365 Front Wall Channel (2) Studs/Front Channel The studs provide a surface for at- taching the siding panels. Following dimensions, measuring from the ends of angles, place a stud between each corner and splice post at the rear of building and 2 studs...

  • Page 22: Side Siding

    ● Parts Needed For ● Step 9 ● ● ● ● ● 8719 Side Siding (6) Side Siding Each screw in the wall requires a washer. Slide side siding into channels of corner posts, flat edge upward, bottom edge down resting on floor frame.

  • Page 23: 8737 Front Siding

    ● Parts Needed For ● Step 10 ● ● ● ● ● 8736 Rear Siding (6) Rear/Front Siding ● ● ● ● ● 8737 Front Siding (6) STEP STEP Slide rear siding into channel of corner and splice posts fastening to Fasten Top Center of rear frame as shown in previous step Last Siding to Stud...

  • Page 24: Roof Beam

    ● Parts Needed For ● ● ● ● ● ● 6000 Right Gable (2) Step 11 ● ● ● ● ● 6001 Left Gable (2) Gable Assemblies ● ● ● ● ● 5971 Roof Beam Bracket (4) AG24 The gables go on top of the front and rear walls to support the roof beams.
  • Page 25 ● ● ● ● ● Left Gable Assemblies (2) ● Parts Needed For ● Step 12 ● ● ● ● ● Right Gable Assemblies (2) Gables/Braces ● ● ● ● ● 6635 Gable Brace (2) Lift and fasten a right and left gable, under angle at corner, to the rear wall angle with screws.
  • Page 26 ● Parts Needed For ● Step 13 ● ● ● ● ● Main Roof Beam (1) Roof Beams ● ● ● ● ● 8474 Roof Beam (2) Fasten the main roof beam to the STEP gable brace of the front gable. Fasten the other end of the main 8474 Roof Beam roof beam to the gable brace of the...
  • Page 27 ● Parts Needed For ● Step 14 ● ● ● ● ● 8468 Right Roof Panel (1) Right Roof Panel STEP Installing the roof panels is best done with a step ladder. Begin installing 8468 8469 roof panels at the back right corner of the building.
  • Page 28 ● ● ● ● ● 8468 Right Roof Panel (1) ● Parts Needed For ● Step 15 ● ● ● ● ● 8469 Left Roof Panel (2) Roof Assembly ● ● ● ● ● 6529 Roof Panel (4) 8469 Left Roof Panel STEP Weather Stripping STEP...
  • Page 29 ● Parts Needed For ● ● ● ● ● ● 8461 Ridge Cap (1) Step 16 ● ● ● ● ● 8482 Side Roof Trim (2) Ridge Cap/Roof Trim Install the ridge cap on the com- pleted roof section using bolts. Do STEP not fasten the ends of the ridge cap 8461...
  • Page 30 ● ● ● ● ● 3719 Door Handle Brace (2) ● Parts Needed For ● Step 17 ● ● ● ● ● 10472 Right and Left Doors (2) Door Assembly ● ● ● ● ● 10497 Horizontal Door Brace (4) ●...
  • Page 31 ● Parts Needed For ● ● ● ● ● ● Right Door Assembly (1) Step 18 ● ● ● ● ● Left Door Assembly (1) Door Installation & Adjustment Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the building) behind door jamb into the...
  • Page 32 ED106 GD106-B GDF106-A PN32 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
