Owner's Manual & Assembly Instructions
R01
Model No. EH108-A
VL10862-A
709160106
BUILDING DIMENSIONS
*Approx.
Foundation
Size
Size
10' x 8'
121" x 92 3/4"
3,0m x 2,3m 307cm x 236cm
* Size rounded off to the nearest foot
Storage Area
Sq. Ft. Cu. Ft.
Width
74
413
123 1/4"
6,9m
2
11,7m
3
EH108S
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Exterior Dimensions
(Roof Edge to Roof Edge)
Depth
Height
95 1/4"
72 7/8"
313cm
242cm
185cm
697.68623
WL108-A
Interior Dimensions
(Wall to Wall)
Width
Depth
Height Width Height
118 1/4"
90"
71 5/8" 55 1/2"
300cm
229cm
182cm
Door
Opening
60"
141cm 152cm
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Arrow EH108S
Summary of Contents for Arrow EH108S
- Page 1 Owner's Manual & Assembly Instructions Model No. EH108-A EH108S 697.68623 VL10862-A WL108-A CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ 709160106 SAFETY INFORMATION PROVIDED IN THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
- Page 2 A foundation is also necessary as a base in order to construct a square and level building. Anchoring and foundation materials are not included with your building. We recommend the combined use of an Arrow Floor Foundation Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct the foundation and anchoring system of your choice.
-
Page 3: Tools And Materials
PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building. - Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
- Page 5 Keep roof clear of leaves and snow with long handled, soft-bristled broom. Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation.
- Page 6 ATTIC KIT / WORKBENCH KIT FLOOR FOUNDATION KITS Heavy-duty galvanized steel bars that fit all 10' wide Arrow buildings. They install quickly and easily to help organize space and create more useable space as an attic or workbench.
- Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
- Page 9 OPTION 1: ARROW FLOOR FRAME KIT: (Order No. FB109-A or 68385-A) Arrow has the best base for your building in this simple kit. It keeps stored items above the ground. This kit should be used with one of the following: A.
- Page 10 It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" Wood Screws. There are 1/4" (0,63cm) dia.
- Page 11 65109 67468 66646 #8-32 Acorn Nut (4) Peak Cap (2) 66045 Washer (377) Handle (2) (Packed with Screws) (Arrow Logo) (10 sheets of 40) 66183 66242 66382 Roof Trim Cap 6228 Door Slide (4) Lower Door Guide (4) (2 right & 2 left)
-
Page 12: Parts List
Parts List Assembly Part Part Quantity Check Key No. Number Description in Carton List 3719 Door Handle Brace 7332 Wall Panel (Side) 9373 Front Wall Panel 9365 Front Wall Channel 5986 Rear Wall Angle 6000 Right Gable 6001 Left Gable 6264 Horizontal Door Brace 6278... - Page 13 Assembly by Key No.
- Page 14 8934 Ramp (1) Parts Needed For 9367 Front Floor Frame (2) Step 1 8936 Rear Floor Frame (2) Floor Frame Assemblies 8937 Side Floor Frame (4) The front floor frame is made up of three pieces. The side floor frames 9367 and the rear floor frame are made up of two pieces.
-
Page 15: Frame Assemblies
5986 Rear Wall Angle (2) Parts Needed For 9917 Rear Wall Channel (2) Step 2 9922 Side Wall Channel (4) Frame Assemblies 8839 Side Wall Angle (4) The main frame pieces reinforce the walls. These pieces will later be in- Rear Wall Channel 9917 stalled in the center and at the top... - Page 16 Parts Needed For 8834 Right Roof Beam (4) Step 3 Roof Beam Assemblies 8835 Left Roof Beam (4) The roof beams join the two gables and support the roof panels. The main roof beam is made up of four pieces Left overlapped back to back at the cen- 8835...
-
Page 17: End View
Parts Needed For 6403 Door Track Splice (1) Step 4 Door Track Assembly 9366 Door Track (2) NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall. It is made up of three pieces. 6403 Using the door track splice, (painted), join the door track... - Page 18 Front Floor Assembly (1) Parts Needed For Step 5 Side Floor Assembly (2) Floor Frame Rear Floor Assembly (1) RIGHT REAR 8937 STEP Assemble the four corners of the 8936 floor frame using two screws at each corner as shown. At the front corners fasten bolts through...
-
Page 19: Top View
Parts Needed For 6515 Wall Panel (2) Step 6 9373 Front Wall Panel (2) Corners 8470 Corner Panel (4) NOTE Narrow The remainder of the building assembly Side 8470 requires many hours and more than one person. Do not continue beyond this point Wide Side if you do not have enough time to com- REAR... - Page 20 Door Track Assembly (1) Parts Needed For Rear Wall Angle Assembly (1) Step 7 Side Wall Angle Assemblies (2) Frames Rear Wall Channel Assembly (1) Side Wall Channel Assemblies (2) 5986 The main frame pieces give rigidity to the side walls and provide a surface Wall Angles for attaching the gables which sup- Must Face...
- Page 21 Parts Needed For Step 8 7332 Wall Panel (4) Wall Panels 6515 Wall Panel (4) The wall panels come in two widths. STEP Each wall panel has a crimped rib on 6515 6515 one side. The crimped rib should go under the rib of the panel that follows 7332 6515...
- Page 22 Parts Needed For Step 9 9369 Door Jamb (2) Front Channel/Door Jamb 9365 Front Wall Channel (2) The door jambs reinforce the door opening and provide an attractive 9365 trim. Follow these steps for both door jambs. Fasten the front wall channels STEP in their positions between the end of the side wall channel and the cor-...
- Page 23 Parts Needed For 6000 Right Gable (2) Step 10 6001 Left Gable (2) Gable Assemblies 5971 Roof Beam Bracket (4) The gables go on top of the front and rear walls to support the roof beams. NOTE The gables are packed nested together and might be mistaken as one piece.
- Page 24 Left Gable Assemblies (2) Parts Needed For Step 11 Right Gable Assemblies (2) Gables/Braces 6635 Gable Brace (2) Lift and fasten a right and left gable, under angle at corner, to the door track and rear wall angle with screws. Hint: On the rear gable, use a bolt and nut at the overlapping rear wall angle.
- Page 25 Parts Needed For Main Roof Beam (1) Step 12 Roof Beams Single Roof Beam (2) Spread the two halves of the main STEP roof beam and fasten the roof beam to the gable brace of the front gable. Single Roof Beam Assembly Fasten the other end of the main roof beam to the gable brace of the rear gable.
- Page 26 Parts Needed For Step 13 8468 Right Roof Panel (1) Right Roof Panel STEP Installing the roof panels is best done with a step ladder. Begin installing 8468 8469 roof panels at the back right corner of the building. Each screw and bolt in the roof requires a washer.
- Page 27 8468 Right Roof Panel (1) Parts Needed For Step 14 8469 Left Roof Panel (2) 7483 Roof Panel (2) Roof Assembly 6529 Roof Panel (2) STEP Install a left roof panel at the left STEP 8469 Left Roof Panel rear and right front corner of the roof. 7483 Roof Panel Install a right roof panel at the left Weather Stripping...
- Page 28 8840 Ridge Cap (1) Parts Needed For Step 15 7483 Roof Panel (2) Ridge Caps & Panels 8486 Ridge Cap (1) Install the first ridge cap on the completed roof section using bolts and nuts. Fasten roof panel overlaps not used for ridge cap. Cover the 8840 STEP head of bolt with the 2"...
- Page 29 Parts Needed For 8485 Left Side Roof Trim (2) Step 16 8836 Right Side Roof Trim (2) Roof Trim Attach the right and left side roof trim to the lower end of the roof pan- els on each side of the building using screws at each panel overlap.
-
Page 30: Door Assembly
3719 Door Handle Brace (2) Parts Needed For 8538 Right Door (1) Step 17 8539 Left Door (1) Door Assembly 6264 Horizontal Door Brace (4) 6278 Vertical Door Brace (2) The steps on this page tell how to assemble the right door. You will perform exactly the same procedures for the left door. - Page 31 Parts Needed For Right Door Assembly (1) Step 18 Door Installation & Adjustment Left Door Assembly (1) Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP STEP building) behind door jamb into the...
- Page 32 EH108-A EH108S 697.68623 VL10862-A WL108-A SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
