20 | E5600 Controller-Drive Tray and Related Drive Trays Installation Guide
1
Host Interface Card QSFP Channel 1
2
Host Interface Card Logical Link 1 Active LED
3
Host Interface Card Physical Link 1 Active LED
4
Mini USB port
5
Host Interface Card Logical Link 2 Active LED
6
Host Interface Card Physical Link 2 Active LED
7
Host Interface Card QSFP Channel 2
•
Right-rear subplate with a 16-Gb Fibre Channel or a 10-Gb iSCSI HIC
1 SFP+ Host Interface Card Channel 1
2 Host Interface Card Link 1 Fault LED
3 Host Interface Card Link 1 Active LED
4 SFP+ Host Interface Card Channel 2
5 Host Interface Card Link 2 Fault LED
8
Host Interface Card Link 3 Fault LED
9
Host Interface Card Link 3 Active LED
10
Mini USB port
11
Host Interface Card Link 4 Fault LED
12
Host Interface Card Link 4 Active LED
