116 | E5600 Controller-Drive Tray and Related Drive Trays Installation Guide
Table 29: LEDs on the left bezel
Location
1
2
3
4
5
• LEDs on the ESM canister
Table 30: LEDs on the ESM canister
Location
1
2
LED Color
Drive Tray Green
Power
Drive Tray Green
Standby Power
Drive Tray White
Locate
Drive Tray Amber
Over-
Temperature
Drive Tray Amber
Service Action
Required
LED Color
Host Link 1 Amber
Fault
Host Link 1 Green
Active
On
Power is present.
The drive tray is in
Standby Power mode.
Identifies a drive tray
that you are trying to
find.
The temperature of the
drive tray has reached
an unsafe level.
A component within
the drive tray needs
attention.
On
At least one PHY of the
four connectors is
working, but another
PHY cannot establish
the same link to the
device connected to the
Host IN port connector.
At least one of the four
PHYs in the In port is
working, and a link
exists to the device
connected to the Host In
connector.
Off
Power is not present.
The drive tray is not in
Standby Power mode.
Normal status.
Normal status.
Normal status.
Off
No link error has
occurred.
A link error has
occurred.
