Accessories (Option)
Bracket
Flat bracket assembly (including 2 mounting screws)
P39800022
L-bracket assembly (including 2 mounting screws)
P39800023
Tightening torque when assembling is 0.3 N·m.
Compact Electro-Pneumatic Regulator
Specifications
Model
Min. supply pressure
Max. supply pressure
Set pressure range
Voltage
Power supply
Current
consumption
Voltage type
Input signal
Current type
Voltage type
Input impedance
Current type
*
2
Output signal Analog output
Linearity
Hysteresis
Repeatability
Sensitivity
Temperature characteristics
Operating temperature range
Enclosure
Connection type
For single unit
Connection size
Manifold
*
Weight 1
*1 Indicates the weight of a single unit
For IITV00-n
Total weight (g) ≤ Stations (n) x 100 + 130 (Weight of end block A, B assembly) + Weight (g)
of DIN rail
*2 When measuring ITV analog output from 1 to 5 VDC, if the load impedance is less than 100
kW, the analog output monitor accuracy of ±6% F.S. or less may not be available.
The product with an accuracy of within ±6% is supplied upon your request.
Output pressure remains unaffected.
*3 When using under the conditions equivalent to IP65, connect the fitting or tube to the
breathing hole before use. (For details, refer to "Specific Product Precautions 1" on page 53.)
* When there is a downstream flow consumption, pressure may become unstable depending on
piping conditions.
* When the input signal is at 0%, the exhaust solenoid valve is controlled to reduce the outlet
pressure to zero. For this reason, a noise may be generated. This noise is normal and does
not indicate a fault.
Cable connector
Straight type
M8-4DSX3MG4
Right angle type
P398000-501-2
ITV0000
ITV001m ITV003m
Set pressure + 0.1 MPa
0.2 MPa
0.001 to 0.1 MPa 0.001 to 0.5 MPa
24 VDC ±10%, 12 to 15 VDC
Power supply voltage 24 VDC type: 0.12 A or less
Power supply voltage 12 to 15 VDC type: 0.18 A or less
0 to 5 VDC, 0 to 10 VDC
4 to 20 mADC, 0 to 20 mADC (Sink type)
Approx. 10 kW
Approx. 250 W
1 to 5 VDC (Output impedance: Approx. 1 kW)
Output accuracy: ±6% F.S. or less
±1% F.S. or less
0.5% F.S. or less
±0.5% F.S. or less
0.2% F.S. or less
±0.12% F.S./°C or less
0 to 50°C (No condensation)
Equivalent to IP65
Built-in One-touch fittings
Metric size
z, x, c:
Inch size
z, x, c:
Metric size
z, c:
Inch size ø
z, c:
100 g or less (Without options)
Series
ITV005m
1.0 MPa
0.001 to 0.9 MPa
*
3
ø 4
ø 5/32"
ø ø
6, x: 4
ø
1/4", x: 5/32"
6
