CanyCom MASAO CMX 2502 Operator's Manual page 22

Controls and Components
1 Main Switch . . . . . . . . . . . . . Main switch is used to start or stop engine.
2 Choke Knob . . . . . . . . . . . . . Choke Knob is used to help start engine by closing choke
3 Throttle Lever . . . . . . . . . . . Throttle lever is used to control engine speed.
4 Drive Pedal . . . . . . . . . . . . . . Drive pedal is used to control the traveling direction and
5 Drive Lever . . . . . . . . . . . . . . Drive lever is used to control the traveling direction and
6 Brake Pedal. . . . . . . . . . . . . . Brake pedal is used to stop machine. When brake pedal
7 Parking Brake Lock . . . . . . . Parking brake lock lever is used when parking machine
Lever
8 Auxiliary Transmission . . . . Auxiliary transmission shift lever is used to shift auxiliary
Shift Lever
9 2WD/AWD Shift Lever . . . . . 2WD/AWD shift lever is used to switch between 2WD
valve.
speed of the machine. Machine moves forward when the
front of drive pedal is depressed and backward when
the rear of drive pedal is depressed. Angle of drive pedal
determines the speed.
speed of machine. Machine moves forward when lever is
tilted forward and backward when lever is tilted backward.
Angle of drive lever determines the speed. (On the right
lever model, this lever is on the right -hand side. See
illustration.)
is depressed, drive lever returns to neutral position and
brake is engaged. (On the right lever model, this lever is
on the right -hand side. See illustration.)
securely. Pulling parking lock lever while brake pedal is
depressed locks brake pedal. (On the right lever model,
this lever is on the right -hand side. See illustration.)
transmission to change the speed of the machine.
(rear-wheel drive) and AWD (all-wheel drive) modes.
