Page 3 Table of Contents...
Page 7 Introduction Ford’s Commitment to You At Ford Motor Company, excellence is the continuous commitment to achieve the best result possible. It is dedication to learning what you want, determination to develop the right concept, and execution of that concept with care, precision, and attention to detail.
Page 8 Things to Know About Using This Guide Congratulations on the purchase of your new vehicle. This guide has information about the equipment and the options for your new vehicle. You may not have bought all of the options available to you. If you do not know which information applies to your vehicle, talk to your dealer.
Page 9 Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. The Lincoln Commitment The Lincoln Commitment is more than the prestige of owning a superior luxury automobile, it is a comprehensive owner benefits package that is designed to provide you with services to support your every driving need.
Page 10: Ford Extended Service Plan
Ford Extended Service Plan More Protection for Your Vehicle You can get more protection for your new car or light truck by purchasing a Ford Extended Service Plan (Ford ESP). Ford ESP is the only extended service program with the Ford name on it and the only service contract backed by Ford Motor Company.
Page 11 Breaking Your Vehicle In Your new vehicle goes through an adjustment or break-in period during the first 1,000 miles (1,600 km) that you drive it. During the break-in period, you need to pay careful attention to how you drive your vehicle. Avoid sudden stops.
Page 12 Instrumentation The instrument panel (dashboard) on your vehicle is divided into several different sections. The illustrations on the following pages show the major parts of the instrument panel that are described in this chapter. Some items shown may not be on all vehicles.
Page 13 The Electronic Cluster The electronic cluster works only when your ignition is in the ON position. Each time you start your vehicle, the displays go through a self-test by flashing on and off once before the actual readings are displayed. (Neither the turn signals nor the high beam indicator light will flash like the other indicators do for the self-test.) Some of the warning lights will flash on and remain on (will not...
Page 15: Engine Coolant Temperature Gauge
Engine Coolant Temperature Gauge This gauge indicates the engine coolant temperature not the coolant level. If the coolant is not at its proper level or mixture, the gauge indication will not be accurate. It is identified by a thermometer symbol, an “H” (hot), and a “C” (cold). The “NORMAL”...
Page 16 4. Check the coolant level following the instructions on checking and adding coolant to your engine, see Engine Coolant in the Index. If you do not follow these instructions, you or others could be injured. If the coolant continues to overheat, have the coolant system serviced.
Page 17 WARNING If the anti-lock brake system warning light remains on or comes on while driving, have the braking system checked by a qualified service technician as soon as possible. Brake System Light The warning light for the brakes can show two things —...
Page 18 WARNING The BRAKE light indicates that the brakes may not be working properly. Have the brakes checked immediately. Safety Belt Warning Light and Chime This warning light and chime remind you to fasten your safety belt. The following conditions will take place: If the driver’s safety belt is not buckled when the ignition is turned to the ON position, the...
Page 19: Check Engine Warning Light
NOTE: Regularly scheduled maintenance of the air bag system is not required. If the light fails to illuminate, continues to flash, remains on, or you hear a beeping sound, have the system serviced at your Ford or Lincoln-Mercury dealer immediately.
Page 20: Charging System Warning Light
Charging System Warning Light This light comes on when you turn your ignition key from OFF to ON (engine off). The light should go out when the engine starts and the alternator begins to charge. If this light stays on or comes on while your engine is running, this tells you that your battery is not being charged and that you need to have the electrical system checked as soon as possible.
Page 21: Turn Signal Indicator Lights
If you lose engine oil pressure: 1. Pull off the road as soon as safely possible. 2. Shut off the engine immediately. If you do not stop the engine as soon as safely possible, severe engine damage could result. 3. Check the engine’s oil level, following the instructions on checking and adding engine oil, see Engine Oil in the Index.
Page 22: Fuel Gauge
If one or both of your turn indicators do not flash or stay on continuously, have them serviced as soon as possible. In the meantime, be sure to use the accepted hand signals. Speed Control Indicator Light This light comes on when the speed control system is actively maintaining the set speed.
Page 23 The fuel gauge symbols indicate the remaining fuel: “F” means full, “1/2” means half-full and “E” means empty. Low fuel alert When the fuel level drops to approximately 1/8 of a tank, a flashing fuel pump symbol is displayed. If you want to calculate fuel economy, use the message center buttons instead of the fuel gauge bar graph indicator.
Page 24 Compass Display (If Equipped) The Compass can display direction indicated by N, S, E, W, NE, NW, SE and SW. The sensor for the compass display is located on the back side of the rear view mirror. The Compass can be set to one of 15 geographic zones.
Page 25 Zone map Factors Affecting Compass Accuracy The compass reading can be affected when you drive near a number of things — such as large buildings, bridges, power lines, and powerful antennas. Your compass can also be affected by magnetic or metallic objects placed in or on the compass sensor (the sensor is loacated on the inside rearview mirror bracket).
Page 26 Odometer The odometer tells you the total number of miles or kilometers your vehicle has been driven. If the cluster is replaced, and the accumulated mileage on the odometer is unknown, the replacement cluster will have the circled “S” illuminated with zero miles on the odometer.
Page 27 All of the message center functions are controlled by the three switches located just below the radio controls in the center of the instrument panel. E/M — Changes the electronic instrument cluster and the electronic temperature control display to read in either English or Metric units. Reset —...
Page 28 How to use the message center To reset any function: 1. Push either the right or left side of the SELECT button to choose the function you would like to set. 2. Push the RESET button and the selected message center function will be reset to zero. (The only functions which can be reset to zero are: AVG ECON, TRIP A or TRIP B, and AVG SPEED.)
Page 29 This function estimates how many miles or kilometers you can drive with the fuel remaining in your tank under standard driving conditions. Remember to turn off the ignition when filling up with fuel. Otherwise, the display will not show the addition of fuel for a few miles.
Page 30 If “CO” or “CS” is displayed, this means that there is a problem with the fuel indication system and you should contact your dealer for service as soon as possible. FUEL REMAIN — Fuel Remaining This function shows you how many gallons (liters) of fuel you have left in the fuel tank.
Page 31 FUEL ECON — Fuel Economy Functions The FUEL ECON selection indicates two functions, Average Fuel Economy and Instantaneous Fuel Economy. Average Economy is entered by pressing the SELECT> button from the DISTANCE TO EMPTY display. This function is indicated by the AVG indicator being illuminated to the left of the Message Center digital display.
Page 32 AVG ECON — Average Fuel Economy Select this function to display your average fuel economy in miles per gallon or liters per 100 kilometers. Your message center computes this figure using the distance traveled and fuel used information. If you want to reset this function, press the RESET button while the average fuel economy feature is displayed.
Page 33 INST ECON — Instantaneous Fuel Economy Select this function to calculate your instantaneous fuel economy. Your instantaneous fuel economy is the fuel economy you get at any particular moment. For example, you can see what your fuel economy is in heavy traffic or on an open highway. Your vehicle must be moving to calculate fuel economy.
Page 34 AVG SPEED — Average Speed Function To use the Average Speed function, select AVG SPEED and press the RESET button. Your average speed from that point until you RESET again will be displayed. TRIP A and TRIP B — Elapsed Distance Traveled These two functions of the message center allow you to see how far you have traveled since you last...
Page 35 The Trip Remaining distance is set by first selecting the TRIP REMAIN indicator then pressing the RESET button at which point the HUNDREDS (100’s) digit will be flashing. To set the 100’s digit, press the <SELECT button until the desired value is reached then press SELECT>...
Page 36: Overdrive Off Indicator
Overdrive Off Indicator This light tells you that the Transmission Control Switch (TCS) has been pushed. When the light is on, the transmission will not shift into overdrive. Depressing the button will return the vehicle to “overdrive on” mode. The transmission will be in the “overdrive on”...
Page 37 Trunk Ajar Light If the trunk is not completely closed, this light comes on when you turn the ignition to ON. With the ignition ON this light will flash five (5) times and sound a tone for one (1) second, and then the light will remain on.
Page 38: Electronic Sound Systems
Electronic Sound Systems Luxury Audio System (Analog)
Page 39 Luxury Audio System (Digital)
Page 40 Luxury Audio System Using the Controls on Your New Radio How to turn the radio on and off Press the “VOL/PUSH ON” knob to turn the radio on. Press again to turn it off. How to adjust the volume Turn the “VOL/PUSH ON” knob clockwise to increase the volume and counter-clockwise to decrease the volume.
Page 41 How to tune radio stations There are four ways for you to tune in a particular station. You can use the “TUNE”, “SEEK”, “SCAN” or memory buttons. Using the “TUNE” function You can change the frequency up or down one increment at a time by pressing and releasing either the left b or right a side of the “TUNE”...
Page 42 1. Select a band, then select a frequency. 2. Press one of the memory buttons and hold until the sound returns and the lamp above the memory button lights up. That memory button is now set. 3. Follow the above steps for each memory preset button.
Page 43 Adjusting the tone balance of your radio Increasing or decreasing bass and treble response Push the “BASS/TREB” popout knob to gain access to the bass and treble controls. Bass control allows you to adjust the lower, bass frequencies to your preference.
Page 44 Using the Digital Signal Processing (DSP) Feature Push the “( a DSP b )” button to activate the feature. The display will indicate which signal mode is in effect. To change the signal mode press either the left ( b ) or right ( a ) side of the selector button (located under the “( a DSP b )”...
Page 45 Your Antenna Antennas for both AM and FM reception are hidden in the back glass of your vehicle. There is an internal antenna module that will switch between AM and FM, when bands are changed, for maximum reception performance. NOTE: Do not attempt to adapt any other type of antenna system to your audio system.
Page 46 Rewinding the tape To rewind the tape, press the “REW” button. The radio will automatically begin playing while the tape is rewinding. The light above the “REW” button will blink while in the rewind mode. Press “REW” again or press the “TAPE” button to stop rewinding.
Page 47: How To Eject The Tape
How to eject the tape To stop the tape and eject the cassette, press the “EJECT” button. The tape will eject only when in the tape mode. The cassette cannot be ejected when the radio is playing an “AM” or “FM” station.
Page 48 Tips on Caring for the Cassette Player and Tapes In order to keep your cassette tape player performing the way it was meant to, read and follow these simple precautions: Using a Ford Cassette Cleaning Cartridge or equivalent to clean the tape player head after 10-12 hours of play will help maintain the best playback sound and proper tape operation.
Page 49 Ford 10-CD Changer (If Equipped) Introduction The 10-CD Changer Unit is mounted in the trunk (10-disc capacity) and is remotely controlled through the controls of your Luxury Audio System. Be sure to read all of the information provided on the following pages to get the most out of this system.
Page 50 2. Push EJECT button to eject the disc “magazine” (which holds 10 discs) (Figure 2). Figure 2 3. Load discs into disc magazine slots (numbered 1 through 10) one at a time with labeled surfaces upward, starting with bottom slot number 1 (Figure 3).
Page 51 4. Insert loaded disc magazine into chamber unit with the arrow on top of the disc magazine pointing toward the changer (Figure 4). Make sure magazine is fully inserted into changer. Figure 4 NOTE: To remove one or more compact disc(s) from the disc magazine, push the corresponding lever(s) (numbered 1 to 10 on the side of the disc magazine) to the left.
Page 52 How to begin CD Changer play NOTE: Radio power must be on to operate the Compact Disc Changer. Push the “CD” button to begin CD play. The 10-CD Changer will automatically begin playing the first track (selection) of the first disc loaded in the unit.
Page 53 Operating the CD Compression feature The compression feature will bring soft and loud passages closer together for a more consistent listening level. To turn the compression on, press the light above the “ k COMP” button. When on, the “k COMP”...
Page 54 How to stop CD play While in the CD Changer mode, press either the “AM” or “FM1/FM2” button to stop CD play and resume radio play. Also, loading a cassette into the cassette deck or pressing the “TAPE” button with tape already loaded will stop CD play and begin cassette play.
Page 55 CD Error Messages Your system is equipped to diagnose certain problems you may experience. The error codes are: — CD E1 — Mechanism error. — CD E2 — Focus error. — BAD CD — Disc unreadable. — TOO HOT — Mechanism over 167˚ Farenheit (75˚C), allow to cool before playing.
Page 56 If play does not begin after the CD button is pushed: The radio is not on. The unit is in the stop mode. Moisture may have condensed on the lenses within the unit. If this occurs, remove the disc and wait approximately an hour until the moisture evaporates.
Page 57 When the radio waves are reflected off objects or structures, the reflected signal cancels the normal signal, causing the antenna to pick up noise and distortion. Cancellation effects are most prominent in metropolitan areas, but also can become quite severe in hilly terrain and depressed roadways. To minimize these conditions, a stereo/mono blend circuit has been incorporated into this system.
Page 58 Not all frequencies will be assigned to a given area. This radio will tune to each of these frequencies using manual tune and no fine tuning is necessary as radio stations may not use other frequencies. Some FM radio stations advertise a “rounded-off” frequency which is not the frequency they actually broadcast on.
Page 59: Controls And Features
Controls and Features The Climate Control System Electronic Automatic Temperature Control System The Electronic Automatic Temperature Control (EATC) module is located at the center of the instrument panel and operates only when the key is in the ON position. The EATC feature maintains the temperature you select and automatically controls the airflow for your comfort.
Page 60 The controls for the automatic electronic climate control To turn your EATC on, push the AUTOMATIC button or any of the six override buttons along the bottom of the control. To turn your EATC off, press the OFF button. When the system is off, the display window will be blank (dark) except when OUTSIDE TEMP has been selected.
Page 61 If you want continuous maximum cooling, push the BLUE button until 60˚F (16˚C) is shown in the display window. Your EATC will cool at maximum and disregard the 60˚F (16˚C) setting until you select a warmer temperature with the RED button. If you want continuous maximum heating, push the RED button until 90˚F (32˚C) is shown in the display window.
Page 62 When in AUTOMATIC and weather conditions require heat, air will be sent to the floor. But, a feature is included in your EATC to prevent blowing cold air to the floor if the engine coolant is not warm enough to allow heating. For a short time the fan will be at low speed and air directed to the windshield.
Page 63 Temperature display The selected temperature displayed in the window can be set for either ˚F or ˚C. Your car may have an English/Metric (E/M) Button to change your speedometer from miles to kilometers. When pressed, this button also changes the temperature display.
Page 64 To change the temperature display to ˚F or ˚C, press and hold the MAX A/C and DEF Buttons at the same time for 3/4 second. The display will change. If you continue to press the two buttons, the display will continuously switch between ˚F and ˚C.
Page 65 When you move the thumbwheel, the fan speed will go to manual control. The display window will show the H symbol in the upper left corner along with the selected temperature and operating function. You can override the fan speed at any time. If you use the thumbwheel to override the fan speed, the EATC will continue to control the temperature but you control the fan speed.
Page 66 MAX A/C, etc.), automatic fan control will continue unless you rotate the fan thumbwheel. To return to automatic fan control, press the AUTOMATIC button. The EATC will return to Automatic operation. If you want to return to any override function, press the button for that function. The fan speed will continue to be automatically controlled.
Page 67 VENT button Push this button to select outside air through the instrument panel registers. The display window will show the set temperature and VENT to the lower right of the temperature. Your EATC will heat the air if the temperature you have selected is warmer than the outside air coming into the vehicle.
Page 68 OUTSIDE TEMP button By pressing this button the temperature of the air outside of the vehicle will show in the display. The outside temperature will continue to be displayed until the OUTSIDE TEMP button is pressed again to cancel. If the selected temperature setting is changed while the outside temperature is displayed, the new selected temperature will be displayed for 4 seconds after it is changed.
Page 69 NOTE: The outside temperature reading is most accurate when the vehicle is moving. Higher readings may be obtained when the vehicle is not moving. The readings that you get may not agree with temperatures given on the radio due to differences in vehicle and station locations.
Page 70 Rear Window Defroster and Heated Sideview Mirrors The rear window and heated outside mirrors defroster switch activates the defroster for the rear window to clear frost, fog, or thin ice from both the inside and outside of the rear window and activates the heated outside rearview mirrors.
Page 71 After approximately 10 minutes, the defroster will turn off. If the window or mirrors are still not clear, turn the defroster on again. The defroster will turn off when the ignition key is turned to the OFF or START position. The heating elements are bonded to the inside of the rear window.
Page 72: The Interior And Exterior Lights
The Interior and Exterior Lights Daytime Running Light System (Canadian vehicles only) The Daytime Running Light (DRL) system is designed to turn the high beam headlamps on, with a reduced light output and without illuminating the high beam indicator lamp in the instrument panel. The DRL system operates when all of the following conditions are met: The headlamp system is in the OFF position,...
Page 73 Turning On the Exterior Lights To turn on your headlamps, parking lamps, side markers, license plate lamps and tail lamps, use the control knob that is to the left of the steering wheel. The knob that operates the headlamps and parking lamps...
Page 74 To turn on the parking lamps, tail lamps, side markers, and license plate lamps, turn the knob clockwise to the first position. For more information about how the high beams work, see the high beam section later in this chapter. Setting the Autolamp On/Off Delay System By using the autolamp, you can set the headlamps...
Page 75: Instrument Panel Illumination
3. Rotate the headlamp switch counterclockwise from the OFF position. 4. The autolamp will automatically turn the lamps on and off for you. Do not put any articles on top of the photocell that is located in the top left corner of the instrument panel.
Page 76 The switch that controls the light on the instrument panel illumination Clock The digital clock 1. To set the hour, press and hold the hour button. When the desired hour appears, release the button. 2. To set the minutes, press and hold the minute button.
Page 77 Ashtray and Cupholder Your vehicle has an ashtray/cupholder mounted to the lower center of the instrument panel. To open the ashtray, pull out the bottom edge of the drawer until it stops. To close, remove cup(s) and push drawer forward until closed.
Page 78 NOTE: Your vehicle is also equipped with an accessory timer. This allows some of your accessories to remain on for up to 10 minutes after the ignition is turned to the OFF position. The accessory timer is cancelled if any door is opened, the dimmer switch is used, or the ignition is turned to the ON position.
Page 79 Removing the Key From the Ignition 1. Put the gearshift in P (Park). 2. Set the parking brake fully. 3. Turn the ignition key to LOCK. 4. Remove the key. If the key is stuck in the LOCK position, move the steering wheel left or right until the key turns freely.
Page 80: High Beams
Turn Signals Move the lever up to signal a right turn. Move it down to signal a left turn. The corresponding indicator light in the instrument cluster will flash. For lane changes, move the lever far enough to signal but not to latch. The lever will return to the off position when you release it.
Page 81: Windshield Wipers And Washer
Windshield Wipers and Washer To turn on the windshield wipers, the ignition key must be turned to the ON or ACC position. Rotate the knob towards “S” to activate the wipers. The first seven detents are interval wipe positions, the eighth detent is the LO position and the ninth detent is the HI position.
Page 82: Windshield Washer
If the washer does not work, check the washer fluid level and fill it if it is low. See the Maintenance and Care chapter. If there is enough fluid, consult your nearest Ford or Lincoln-Mercury dealer. Do not try to clean the windshield when the...
Page 83 The control switch for the hazard flashers Horn To sound the horn, push the center pad area of the steering wheel. The horn on the steering wheel — Executive series...
Page 84: Tilt Steering
The horn on the steering wheel — Signature and Cartier series Tilt Steering WARNING Never adjust the steering wheel when the vehicle is moving.
Page 85: Speed Control
To change the position of the steering wheel, pull the release lever on the column toward you. Tip the steering wheel to the desired position. Release the lever to lock the steering wheel in place. Speed Control The speed of the vehicle cannot be automatically controlled until the vehicle speed is at or above 30 mph (48 km/h).
Page 86 The speed control switches on the steering wheel — Executive series The speed control switches on the steering wheel — Signature and Cartier series...
Page 87 To Turn Speed Control Off Press OFF, OR Turn off the vehicle ignition. Once speed control is switched off, the previously programmed set speed will be erased. To Turn Speed Control On Press ON To Set a Speed Press SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 30 mph (48 km/h).
Page 88 Accelerate with your accelerator pedal, then press SET ACCEL. You may accelerate with the accelerator pedal at any time during speed control usage. Releasing the accelerator pedal will return your vehicle speed to the previously programmed set speed. To Set a Lower Set Speed Press and hold COAST.
Page 89: Remote Control Buttons
Remote Control Buttons (If equipped) Your vehicle may be equipped with remote control buttons, located on the steering wheel, which allow you to control some radio and climate control features. The remote control buttons on the steering wheel Radio Control Features With the remote radio control features you are able Select a preset station from memory by pressing the “MEM”...
Page 90 Turning On the Lamps Front and Rear Courtesy/Reading Lamps Your vehicle is equipped with two courtesy/reading lamps located at the front-center and rear-center of the headliner (roof). The right lamps are for the right side passengers and the left lamps are for the driver and rear left side passenger.
Page 91 Moon Roof (If equipped) You can move the moon roof back to open the glass panel, or you can tilt it up to ventilate the vehicle. The rocker type switch is used to open and close the moon roof. You must press and hold the switch until the desired position is reached.
Page 92 To close from vent position, press and hold the rear portion of the switch. Occasionally wiping the outside guide rail covers of the moon roof with a clean cloth will help keep the moon roof working properly. The moon roof WARNING Do not let children play with the moon roof.
Page 93 Mirrors Automatic Dimming Inside Rearview Mirror (If equipped) The electronic day/night mirror will change from the normal state to the non-glare state when bright lights (glare) reach the mirror. This mirror functions at night, and has a limited function at dusk or dawn.
Page 94: Sun Visors
There are two light sensors (photocells) in this mirror. The sensor that detects rear glare is located inside a window in the center of the mirror. The second light sensor which determines outside light level is located on the backside of the mirror case. The driver’s side mirror is activated by these sensors to prevent glare when traffic is behind or around the vehicle.
Page 95: Homelink Universal Transmitter
Illuminated Visor Mirror (If equipped) To turn on the visor mirror, lift the mirror cover. The mirror on the sun visor HomeLink Universal Transmitter (If equipped) The HomeLink Universal Transmitter provides a convenient way to replace up to three hand-held transmitters with a single built-in device.
Page 96 Do not use this HomeLink Transmitter with any garage door opener that lacks safety “stop” and “reverse” features as required by federal safety standards, (this includes any garage door opener model manufactured before April 1, 1982). A garage door opener which cannot “detect” an object in the path of a closing door and then automatically “stop”...
Page 97 4. Using both hands, push the hand-held transmitter button and the desired button on the HomeLink Transmitter. Continue to press both buttons through step 5. 5. Hold down both buttons until you see the red light on the HomeLink Transmitter flash, first slowly and then rapidly.
Page 98 Operating the HomeLink Universal Transmitter Once it is programmed, the HomeLink Universal Transmitter can be used in place of your hand-held transmitter(s). To operate, simply press the appropriate button on the HomeLink Transmitter. The red light comes on while the signal is being transmitted.
Page 99 Remove the cover panel from your garage door opener receiver. (The receiver should be located by the garage door opener motor.) Locate the training button on the garage door opener receiver. The exact location and color of the button may vary by garage door opener brand.
Page 100 NOTE: When selling your vehicle, be sure to erase all channels on the HomeLink Transmitter that you programmed. Accessories Accessories for your HomeLink Universal Transmitter are available from the manufacturer of the device. If you would like additional information or would like to purchase other accessories such as home lighting or security products that can be operated by the HomeLink Universal Transmitter, please call toll-free: 1-800-355-3515.
Page 101 To set the childproof lock on each rear door, open the rear door. Find the lever at the black label with the word LOCKED in white letters. Move the lever up. To release the childproof lock, open the rear door from the outside and move the lever down.
Page 102 Using the Power Windows Each door has a power control that opens and closes the window on that door. The driver’s door has a master control panel that operates all four windows. Power windows can only be opened or closed when the ignition is in the ON or ACC position or during the ten minute delayed accessory period after the ignition is turned off.
Page 103 To operate, briefly press the driver’s window switch to the down position. The window will then open automatically. To stop automatic operation, briefly press the switch again to either the up or down position. More than a quick press of the switch provides conventional power window operation.
Page 104 3. Press “1” button within five (5) seconds. You now have set in memory the first position. Set the second position by adjusting the seat and mirrors, pressing the SET button and pushing the “2” button within five (5) seconds. A third position can be set in the same manner as above by pushing “1”...
Page 105 For information about the cellular phone in your vehicle, refer to the Cellular Phone User’s Manual provided with your phone. For further questions about your Lincoln cellular phone, contact the Ford Cellular System at 1-800-367-3013(U.S.). In Canada, please contact your dealer.
Page 106 To open the lid, push in on the latch release bar at the front and raise. The features on the armrest...
Page 107: Floor Mat
Positive Retention Driver’s Side Floor Mat Installing the Floor Mat Position the floor mat in foot well. Place mat eyelet over pointed end of retention post from the rear and rotate forward to install. Adjust floor mat position to allow proper operation of accelerator pedal and brake pedal.
Page 108 Removing the Floor Mat Lift floor mat just forward of retention post and rotate rearward to disengage from retention post. Trunk Opening the Trunk Manually To open and close the trunk from the outside: The trunk lock cylinder 1. Insert the key into the lock on the trunk. 2.
Page 109: Keyless Entry System
4. Shut the trunk lid by pushing on the top of the lid with enough pressure to allow the latch to engage. 5. The power mechanism will automatically pull down and securely latch the trunk lid shut. A slight whirring sound will be heard. WARNING Do not attempt to stop the automatic pulldown or clear objects from the...
Page 110 The keyless entry buttons When you bought your vehicle, you were given a computer code that operates the system for your vehicle. For your convenience, we have duplicated this code in three places. The code is: on your owner’s wallet card found in the glove compartment taped to the trunk lid’s right hinge support bar taped to the computer module in your driver’s...
Page 111 Unlocking the Doors with the Keyless Entry System You must unlock the driver’s door before you unlock any of the other doors or trunk. If you let more than five (5) seconds pass before pressing numbers, the system shuts down, and you have to enter the code again.
Page 112 Autolock The Autolock feature will automatically lock all the doors when: the vehicle’s doors are fully closed the ignition key is turned to the ON position someone is sitting in the driver’s seat or a heavy object is placed on it the vehicle is in any forward or reverse gear.
Page 113 Programming Your Own Entry Code You can program up to four (4) personal codes to unlock your vehicle. This code does not replace the permanent code that the dealership gave you. Use your personal code in the same manner as you would your original code.
Page 114: Remote Entry System
To erase all of the personal entry codes and remote entry transmitters programmed to a vehicle: 1. Enter the original permanent code. 2. Press 1/2 within five seconds of Step 1. 3. Press and hold 1/2 for two (2) seconds. All of the vehicle doors will lock and then unlock to confirm erasure.
Page 115 The remote entry features only operate with the transmission in the P (Park) or N (Neutral) position. Remote entry transmitter Unlocking the doors and opening the trunk To unlock the driver’s door, press the UNLOCK control. To unlock the other doors, press the UNLOCK button a second time within five (5) seconds of unlocking the driver’s door.
Page 116 The door lock Horn Chirp is a programmable feature. To deactivate the Horn Chirp feature: 1. Enter your permanent five-digit code (not the user code you may have set). 2. Within five seconds, press and hold the 7/8 button. 3. Within five more seconds, press and release the 1/2 button.
Page 117 Memory Seat and Mirror Feature Remote Entry Pressing the UNLOCK button on the remote entry key fob unlocks the driver’s door and recalls all of the Memory settings. Two key fobs are delivered with the vehicle. One is programmed to always recall Memory 1 and the other will always recall Memory 2.
Page 118: Replacing The Batteries
Replacement batteries can be purchased at most pharmacies, watch stores or at your Ford or Lincoln-Mercury dealer. NOTE: The operating range of the remote entry system can also be affected by weather conditions...
Page 119: Battery Saver
3. Press one button on each of the transmitters to be programmed. Each transmitter button must be pressed within seven (7) seconds of the prior one. Each time a transmitter is successfully programmed, all of the vehicle doors will lock and then unlock to verify programming.
Page 120: Arming The System
Anti-theft System When armed, this system helps protect your vehicle against break-ins or theft by monitoring all doors, the hood, and the trunk lock cylinder. When an unauthorized entry occurs, the system triggers and will: flash the headlamps, parking lamps, interior lamps, and alarm indicator light honk the horn prevent the engine from starting...
Page 121 3. Lock the doors by using the power door lock switch, pressing the remote entry transmitter LOCK button or pressing the last two buttons (7/8, 9/0) of the keyless entry keypad. The alarm indicator will now glow steadily. 4. Close all doors. The alarm indicator light will then remain on steadily for approximately 30 more seconds and then go out.
Page 122 Disarming an Untriggered Anti-Theft System You can disarm the system by: unlocking a front door with the key (turn the key all the way to the end of travel or the system will not disarm). using the keyless entry unlock code. using the UNLOCK button of the remote entry transmitter.
Page 123: Seating And Safety Restraints
Seating and Safety Restraints Seats Head Restraints If you use them properly, head restraints will help protect your head and neck in a collision. Adjusting the head restraint A head restraint should be placed as high as possible behind your head without interfering with your vision.
Page 124 The four-way head restraint Adjusting the Seats WARNING Never adjust the driver’s seat or seatback when the vehicle is moving. WARNING Always drive and ride with your seatback upright and the lap belt snug and low across the hips. WARNING Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop.
Page 125 4. Release the handle to lock the seat in its new position. The seatback recliner handle Using the Power Seats The controls to operate the power seats are located on the front door armrests. The power seat adjustment controls...
Page 126 Power Recliner (If equipped) To recline the front seatback, push the switch located on the side of the seat down. Push the switch up to raise the seatback. The seat controls for the power recliner adjustment on the driver’s seat Power Lumbar Support (If equipped) With this feature, you can inflate a lumbar support pad in the seatback.
Page 127 Heated Seats (If equipped) Each Heated Seat is controlled by the Heated Seat Switch in the Driver’s and Front Passenger’s door just rear of the door handle. The Heated Seat System will only operate with the ignition key in the “ON” position and will maintain a temperature automatically once it is selected.
Page 128 2. Rotate the thumbwheel from “0” to “1” (the lowest heat level). Allow five minutes for the heat level to stabilize. 3. If the heat level is not high enough for comfort, select increased heat levels “2” through “5” (the maximum level). Allow at least two minutes for the heat level to stabilize at any new level selected.
Page 129 WARNING It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 130: Combination Lap And Shoulder Belts
WARNING Ford recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 131 Fastening the combination lap and shoulder belt Fastening the rear seat lap and shoulder belt NOTE: Be sure to read and understand Important Safety Belt Information in this chapter. To adjust the lap part of the belt, pull up on the shoulder belt until the lap belt fits snugly and as low as possible around your hips.
Page 132: Shoulder Belt Height Adjustment
While the belt retracts, guide the tongue to its original position to prevent it from striking you or the vehicle. Unfastening the lap/shoulder belts Shoulder Belt Height Adjustment Driver and right front passenger You can adjust the shoulder belt height to one of five (5) positions.
Page 133 Figure 2 — The shoulder belt height adjuster Figure 1 — The shoulder belt height adjuster...
Page 134 WARNING Position the shoulder belt height adjuster so that the belt rests across the middle of your shoulder. Be sure the shoulder belt is properly positioned on your shoulder each time you use the belt. If the shoulder belt is off your shoulder, on your upper arm or neck, there is a greater risk of severe injury in a collision.
Page 135 WARNING Rear-facing child seats or infant carriers should never be placed in the front seats. This mode must be used when installing a child seat on the front pasenger seat and rear window seats where dual locking retractors are provided. To switch the retractor from the emergency locking mode to the automatic locking mode, perform the following steps:...
Page 136 combination seat belt is latched into the buckle, the cinch tongue will allow the lap portion to become shorter, but locks the webbing in place to restrict it from becoming longer. Before you can reach and latch a combination lap and shoulder belt having a cinch tongue into the buckle, you may have to lengthen the lap belt portion of it.
Page 137 To fasten a cinch tongue, pull the combination lap and shoulder belt from the retractor so that the shoulder belt portion of the safety belt crosses your shoulder and chest. Be sure the belt is not twisted. If the belt is twisted remove the twist. Insert the belt tongue into the proper buckle for your seating position until you hear a snap and feel it latch.
Page 138: Lap Belts
Lap Belts The lap belts in the center of the front and rear seats do not adjust automatically. You must adjust them to fit snugly and as low as possible around your hips. Do not wear them around your waist. Unfastening center lap safety belts NOTE: Be sure to read and understand Important Safety Belt Information in this chapter.
Page 139: Safety Belt Maintenance
Use only extensions manufactured by the same supplier as the safety belt. Manufacturer identification is located at the end of the webbing on the label. Also, use the safety belt extension only if the safety belt is too short for you when fully extended.
Page 140 Failure to follow these instructions may increase the risk of personal injury in the event of a collision. WARNING Do not attempt to service, repair, or modify the air bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer.
Page 141 WARNING If you are close to an inflating air bag, it could seriously injure you. Position your seat such that it is as far back from the steering wheel as possible but still allows you to properly control the vehicle. Children and Air Bags NOTE: For additional important safety information on the proper use of seat belts, child seats, and...
Page 142 the burnt propellant. This is normal. The residue may consist of cornstarch or talcum powder (which is used to lubricate the air bag) or sodium compounds, such as sodium carbonates (e.g. baking soda) that result from the combustion process that inflates the air bag.
Page 143 If any of these things happen, even intermittently, have the Air Bag Supplemental Restraint System serviced at your Ford or Lincoln-Mercury dealer immediately. Unless serviced, the system may not function properly in the event of a collision.
Page 144: Safety Restraints For Children
Disposal of Air Bags and Air Bag Equipped Vehicles For disposal of air bags or air bag equipped vehicles, see your local Ford or Lincoln-Mercury dealer. Air bags MUST BE disposed of by qualified personnel. Safety Restraints for Children In the U.S. and Canada, you are required by law to use safety restraints for children.
Page 145 WARNING Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision. WARNING Safety belts and seats can become hot in a vehicle that has been closed up in...
Page 146 WARNING Rear-facing child seats or infant carriers should never be placed in the front seats. WARNING When using forward-facing child seats move the passenger seat as far back from the instrument panel as possible. Never secure rear-facing child seats or infant carriers in the front seat.
Page 147 WARNING Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision. Installing Safety Seats in the Front Outboard Passenger Seating Position If you choose to install a forward-facing child safety...
Page 148 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. See Figure 2. Be sure that the belt webbing is not twisted.
Page 149 4. Insert the belt tongue into the proper buckle for that seating position until you hear and feel the latch engage. See Figure 3. Make sure tongue is latched securely to buckle by pulling on tongue. Routing the lap/shoulder belt...
Page 150 Buckling the belt. 5. Grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. At this time, the retractor is in the automatic locking mode (child restraint mode). See Figure 4. NOTE: The dual locking mode retractor must be in the automatic locking mode to properly restrain a child seat.
Page 151 Setting the retractor to automatic locking mode 6. Allow the belt to retract. A clicking sound will be heard as the belt retracts. This indicates the retractor is in the automatic locking mode. Pull on the lap belt portion across the child seat towards the buckle and continue to pull up on the shoulder belt portion while pushing down on the child seat allowing the shoulder belt to...
Page 153 7. Before placing the child in the child seat, forcibly tilt the seat from side to side and in forward directions to make sure that the seat is securely held in place. See Figure 7. Checking that the seat is secure...
Page 154 8. Double check that the retractor is in the automatic locking mode. Try to pull more belt out of the retractor. If you cannot, the belt is in the automatic locking mode. See Figure 8. Checking the retractor...
Page 155 9. Check to make sure that the child seat is properly secured prior to each use. If the retractor is not locked, repeat steps 6 through NOTE: To remove the retractor from automatic lock mode, allow seat belt to retract fully to its stowed position and the retractor will automatically switch back to the vehicle sensitive locking mode for normal adult usage.
Page 156 NOTE: The belt webbing below the tongue is the lap belt portion of the combination lap/shoulder belt, and the belt webbing above the tongue is the shoulder belt portion of the combination lap/shoulder belt. 2. With your other hand, grasp the tip (metal portion) of the tongue (not the cover) and slide the tongue up the webbing as far as it will go.
Page 157 5. Insert the belt tongue into the proper buckle for that seating position until you hear a snap and feel it latch. Make sure the tongue is securely latched to the buckle by pulling on the tongue. See Figure 3.
Page 158 6. Push down on the child seat and pull up on the shoulder belt portion to tighten the lap belt portion of the combination lap and shoulder belt. See Figure 4.
Page 159 7. Grasp belt close to child seat and pull on the shoulder belt portion of the combination lap/shoulder belt, then allow the belt to retract and remove all slack to securely tighten the child safety seat in the vehicle. See Figure 5.
Page 160 8. Before placing the child into the child seat, forcibly tilt the child seat from side-to-side and in forward directions to make sure that the seat is held securely in place. See Figures 6 and 7. If the child seat moves excessively, repeat steps 6 through 8, or properly install the child seat in a different seating position.
Page 162: Safety Belts For Children
Tether anchor hardware kits (part number 613D74), including instructions, may be obtained at no charge from any Ford or Lincoln-Mercury dealer. All vehicles built for sale in Canada include a tether anchor hardware kit. Safety Belts for Children Children who are too large for child safety seats should always wear safety belts.
Page 163 to the seat belt buckle may help provide a good shoulder belt fit. To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all Federal motor vehicle safety standards.
Page 164: Starting Your Vehicle
Starting Fuel-Injected Engines When starting a fuel-injected engine, the most important thing to remember is to avoid pressing down on the accelerator before or during starting. Only use the accelerator when you have problems getting your vehicle started. See Starting Your Engine in this chapter for details about when to use the accelerator while you start your vehicle.
Page 165 3. Make sure that the gearshift is in P (Park) and the parking brake is set before you turn the key. Before you start your vehicle, you should test the warning lights on the instrument panel to make sure that they work. Refer to the Instrumentation chapter.
Page 166 For a warm engine: Do not hold the key in the START position for more than five (5) seconds at a time. If the engine does not start within five (5) seconds on the first try, turn the key to the OFF position. Wait a few seconds after the starter stops, then try again.
Page 167 A computer system controls the engine’s idle speed. When you start your vehicle, the engine’s idle speed normally runs higher than when it is warmed up. These faster engine speeds will make your vehicle move slightly faster than its normal idle speed. It should, however, slow down after a short time.
Page 168 WARNING To prevent electrical shock, do not use your heater with ungrounded electrical systems or two-pronged (cheater) adapters. For best results, plug the heater in at least three hours before you start your vehicle. Using the heater for longer than three hours will not damage the engine, so you can plug it in at night to start your vehicle the following morning.
Page 169 Have the exhaust and body ventilation systems checked whenever: your vehicle is raised for service the sound of the exhaust system changes your vehicle has been damaged in a collision Improve your ventilation by keeping all air inlet vents clear of snow, leaves, and other debris. If the engine is idling while you are stopped in an open area for long periods of time, open the windows at least one inch (2.5 cm).
Page 170 Driving Brakes Applying the Brakes Your vehicle has anti-lock disc brakes on all four wheels. They adjust automatically as the brake pads wear down. When you press down hard on the brake pedal, the wheels will not lock and slide. The Anti-lock Brake System (ABS) automatically starts releasing and reapplying the front brakes independently and the rear brakes together whenever your wheels start to...
Page 171: Parking Brake
light comes on at any time other than right after you turn the key to the ON position or during a sudden stop, have your mobile radio dealer inspect the installation. Parking Brake The parking brake should be used whenever you park your vehicle.
Page 172 WARNING If the parking brake is fully released, but the Brake System light remains on, have the brakes checked immediately. They may not be working properly. WARNING To prevent personal injury, do not release the parking brake while outside the vehicle. Your vehicle has an automatic parking brake release.
Page 173 Traction Assist (If equipped) Your vehicle may be equipped with the optional Traction Assist system. This system helps prevent wheel spin in order to improve tire traction and is an especially useful feature when you drive in hilly areas or on slippery, icy or snowy roads. Traction Assist works automatically by rapidly applying and releasing the brakes to prevent one or...
Page 174 A shutoff switch is located in the trunk on the right hand vertical trim panel. If this switch is in the OFF position, the automatic leveling system will not operate. The switch should be OFF whenever hoisting, towing or jacking up the vehicle. “CHECK AIR SUSPENSION”...
Page 175 The Steering Assist Switch (if equipped), located on the instrument panel, allows the driver to select how the steering effort changes with vehicle speed. In the standard position, the steering effort increases at about the same rates as the vehicle speed increases.
Page 176: Steering Your Vehicle
Steering Your Vehicle Your vehicle comes with power steering. Power steering uses energy from the engine to help steer your vehicle. The steering system in your vehicle is speed sensitive. This means that the steering effort is light for parking and heavier for highway driving. However, if you have to swerve around an object or another vehicle, your steering will have full power assist.
Page 177 transmission out of the P (Park) position without the brake pedal being depressed if the key is in the ON position. To operate: 1. Start the engine. 2. Depress and hold the brake pedal. Your vehicle is equipped with a Brake Shift Interlock safety feature.
Page 178 R (Reverse) With the gearshift in the R (Reverse) position, the vehicle will move backward. You should always come to a complete stop before shifting into or out of R (Reverse). N (Neutral) With the gearshift in the N (Neutral) position, the vehicle can be started and is free to roll.
Page 179 Overdrive is the usual driving position for an automatic overdrive transmission. It works the same way Drive works, automatically upshifting or downshifting as the vehicle speeds or slows. However, Overdrive also shifts into a fourth gear — an overdrive gear — when your vehicle cruises at an appropriate consistent speed for any length of time.
Page 180 WARNING Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn off the ignition whenever you leave your vehicle. WARNING Never leave your vehicle unattended while it is running. You can tell a column-mounted gearshift is securely latched in P (Park) if the lever is adjacent to the P (Park) and you cannot move it without pulling it toward you and rotating it downward.
Page 181 Limiting Your Vehicle’s Load The load that you add to your vehicle must not exceed the maximum load stated on the Safety Compliance Certification Decal attached to the left front door pillar. To figure the weight of your vehicle’s load, add the weights of: the driver and passengers luggage and any other items that you put in...
Page 182: Trailer Towing
Trailer Towing Your vehicle is not equipped to tow. No towing packages are available through Ford or Lincoln/Mercury dealers.
Page 183: Roadside Emergencies
Roadside Emergencies The flashers work whether your vehicle is running or not. The flashers work for up to two hours when the battery is fully charged and in good condition without draining the battery excessively. If the flashers run for longer than two hours or if the battery is not fully charged, the battery can be drained.
Page 184 Fuel pump shut-off switch WARNING If you see or smell fuel, do not reset the switch or try to start your vehicle. Have all the passengers get out of the vehicle and call the local fire department or a towing service. If your engine cranks but does not start after a collision or substantial jolt: 1.
Page 185: Fuses And Circuit Breakers
5. Check under the vehicle again for leaking fuel. If you see or smell fuel, do not start your vehicle again. If you do not see or smell fuel, you can try to start your vehicle again. Fuses and Circuit Breakers Fuses (conventional and high current) and circuit breakers protect your vehicle’s wiring system from overloading.
Page 186 The instrument panel fuse panel location The instrument panel fuse panel...
Page 187 The Instrument Panel Fuses, Circuit Breakers and Relays...
Page 189 These, like fuses, open when the circuit load exceeds their amperage rating. High current fuses may be purchased from your Ford or Lincoln-Mercury dealer. The high current fuse panel is located in the engine compartment on the left-hand fender apron.
Page 190 The high current fuse panel location The high current fuses...
Page 191 The high current fuses...
Page 192 Checking and Replacing Fuses If you need to check a fuse, follow these steps: 1. Find the fuse panel to the left of the steering column in the instrument panel. 2. Find the fuse you want to check (fuses are numbered on the fuse panel) and remove it with the fuse pulling tool that is provided.
Page 193: Circuit Breakers
4. Replace the fuse with one that has the right amperage rating. (See the following charts.) ARNING Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire.
Page 194: Changing A Tire
However, you should know that the circuit breakers will reset themselves and allow the electrical parts to work again once the overload on the circuit is removed. If the circuit breakers continue to cut off electricity, have your car’s electical system checked. If you replace a circuit breaker, use one with the same amperage rating.
Page 195: Spare Tire Location
When you drive with the temporary spare tire, DO NOT: exceed 50 mph (80 km/h) under any circumstances. load your vehicle so that it is heavier than the maximum vehicle load rating listed on the tire decal. tow a trailer. use tire chains on this tire.
Page 196 The spare tire location To remove the spare tire: 1. Remove the spare tire cover. 2. Unscrew the wing-nut holding down the spare tire. 3. Lift out the spare tire and jack kit. Preparing to Change the Tire 1. Make sure that your vehicle will not move or roll.
Page 197 WARNING On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle. The air suspension switch — located in the trunk WARNING If the vehicle slips off the jack, you or someone else could be seriously injured.
Page 198 4. Loosen each wheel lug nut one-half turn counterclockwise, but do not remove them until the tire is raised off the ground. You should pull up on the handle rather than push to develop maximum force to loosen wheel lug nuts.
Page 199 NOTE: Never use the differential housing as a lift point. NOTE: Apply jack to the jack notch in the vertical flange only. Do not apply to the plastic rocker panel which has indicating notches and is outboard of the flange. Jacking locations The improper lift point...
Page 200 Locating the notch for the jack — rear wheels Locating the notch for the jack — front wheels 2. Turn the jack handle clockwise until the wheel clears the ground. Remove the wheel lug nuts. 3. If you are replacing the front tire (with aluminum wheels) with the temporary spare tire, you need to remove the black dust shield.
Page 201 6. Lower the vehicle by turning the jack handle counterclockwise. 7. Remove the jack and fully tighten the lug nuts in the order shown in the following illustration. As soon as possible, have your dealer or a qualified service technician check the lug nuts for proper torque specifications.
Page 202 Aluminum wheel Lacy spoke aluminum wheel Remove the center ornament from the wheel with the tapered end of the wheel nut wrench by inserting the end under one of two raised notches, and rotate the handle while prying against the wheel.
Page 203 Y-spoke aluminum wheel Y-spoke aluminum wheel Remove the center ornament from the wheel with the tapered end of the wheel nut wrench by inserting the end into the notch and, rotate the handle while prying against the wheel. Install the center ornament on the wheel and be sure it is snapped into place all the way around using the palm of the hand or a rubber mallet.
Page 204 Steel wheel with full wheelcover Steel wheel with full wheelcover Remove the wheelcover from the wheel using the flanged end of the wheel nut wrench by inserting the handle and then prying against the inner wheelcover flange. Install the wheelcover on the wheel with the valve stem in the wheel matching the hole in the wheelcover.
Page 205 (not the dealer) to get a replacement key. NOTE: If entire lug wrench/lug nut key assembly is lost, see your nearest Ford or Lincoln-Mercury dealer who has access to a master set of keys. NOTE: DO NOT USE A POWER IMPACT WRENCH ON THE LUG NUT KEY.
Page 206: Jump-Starting Your Vehicle
Reinstalling the anti-theft lug nut Insert the key over the locking lug nut. Place the lug nut wrench over the lug nut key and, while applying pressure on the key, install the lug nut. Jump-Starting Your Vehicle Your vehicle’s battery may die if you leave the lights on or any electrical equipment on after you turn the engine off.
Page 207: Preparing Your Vehicle
If the acid touches someone’s skin, eyes, or clothing, immediately flush the area with water for at least 15 minutes. If someone swallows the acid, have him or her drink lots of milk or water first, then Milk of Magnesia, a beaten egg, or vegetable oil.
Page 208 Connecting the jumper cables 1. Connect one end of the first jumper cable to the positive (+) terminal of the discharged battery. (You can connect either jumper cable to the positive (+) terminal, as long as you use the same cable for both positive terminals.) Most jumper cables have a red cable and a black cable.
Page 209 The 4.6L SFI engine...
Page 210 Jump-Starting 1. Make sure that the jumper cables are not in the way of moving engine parts, then start the booster vehicle. Run the engine at a moderate speed. 2. Let the discharged battery charge for a few minutes and then start the disabled vehicle. It may take a couple of tries before the vehicle starts.
Page 211: Towing Your Vehicle
Towing Your Vehicle If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. Typical towing options include wheel lift towing or flat bed towing. Front towing Before your vehicle can be towed, the air suspension switch in the luggage compartment needs to be turned to the OFF position.
Page 212 Rear towing When calling for a tow truck, tell the operator what kind of vehicle you have. A towing manual is available from Ford Motor Company for all authorized tow truck operators. Have your tow truck driver refer to this manual for the proper hook-up and towing procedures for your vehicle.
Page 213: Maintenance And Care
Maintenance and Care Service Made Easy Ford has two goals for servicing your vehicle. 1. When we can, we design parts that do not need to be serviced. 2. We want to make servicing your vehicle as easy as possible. To help you: We highlight do-it-yourself items in yellow in the engine compartment so that you can find them easily.
Page 214 Use only recommended fuels, lubricants, fluids, and service parts conforming to Ford specifications. Motorcraft parts are designed and built to provide the best performance in your vehicle. Using these parts for replacement is your assurance that Ford-built quality stays in your vehicle. NOTE: Always dispose of used automotive fluids in a responsible manner.
Page 215 Precautions When Servicing Your Vehicle Be especially careful when inspecting or servicing your vehicle. Here are some general precautions for your safety: Do not work on a hot engine. The engine cooling fan may come on unexpectedly. Always turn the engine off and let it cool. If you must work with the engine running, avoid wearing loose clothing or jewelry that could get caught in moving parts.
Page 216 Working with the engine on: 1. Set the parking brake fully and make sure that the gearshift is securely latched in P (Park). 2. Block the wheels. This will prevent your vehicle from moving unexpectedly. WARNING Do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 217: Opening The Hood
Opening the Hood 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. The hood release under the instrument panel 2. Go to the front of the vehicle and release the auxiliary latch that is located under the hood at the center of the vehicle.
Page 218: Engine Compartment
3. Lift the hood until the lift cylinders hold it open. Whenever you close the hood, latch it securely. NOTE: Apply lubricant to the hood latch at six-month intervals to maintain smooth and trouble-free operation. NOTE: Read and understand Precautions When Servicing Your Vehicle at the beginning of this chapter before opening the hood.
Page 219 A 4.6 liter SFI engine...
Page 220 Engine Oil Recommendations We recommend using Motorcraft oil or an equivalent oil meeting Ford Specification WSS-M2C153-F and displaying the American Petroleum Institute CERTIFICATION MARK on the front of the container. The API Certification Mark Never use: “Non-Detergent” oils Oils labeled API SA, SB, SC, SD, SE, SF or SG Additional engine oil additives, oil treatments or engine treatments Engine oils with an SAE 5W-30 viscosity are...
Page 221 Checking and Adding Engine Oil Since the proper amount of engine oil is important for safe engine operation, check the oil using the dipstick each time you put fuel in your vehicle. Remember the engine must be off, the oil must be warm and the vehicle must be parked on level ground.
Page 222 It may be necessary to add some oil between oil changes. Make sure you use a CERTIFIED engine oil of the preferred viscosity. Your vehicle’s warranty coverage may not apply if engine damage is caused by the use of improper engine oil. Add engine oil through the oil filler cap highlighted in yellow.
Page 223: Brake Fluid
Brake Fluid Under normal circumstances, your vehicle should not use up brake fluid rapidly. However, expect the level of the brake fluid to slowly fall as you put more mileage on your vehicle and the brake lining wears. You should check the brake fluid at every scheduled engine oil change, but be sure to check it at least once a year.
Page 224: Windshield Washer Fluid
WARNING Do not let the reservoir for the master cylinder run dry. This may cause the brakes to fail. The anti-lock brake system fluid reservoir Windshield Washer Fluid Washer Fluid Check the level of the windshield washer fluid periodically, or when the warning light indicates low fluid.
Page 225 The reservoir for the windshield washer fluid WARNING Do not put windshield washer fluid in the container for the engine coolant. Use specially formulated windshield washer fluid rather than plain water, because specially formulated washer fluids contain additives that dissolve road grime. For safety reasons, washer fluids containing an appropriate antifreeze such as methanol should be used in freezing weather (temperatures below 32˚F [0˚C]).
Page 226: Engine Coolant
Engine Coolant Checking the Engine Coolant NOTE: Be sure to read and understand Precautions When Servicing Your Vehicle at the beginning of this chapter. WARNING The cooling fan is automatic and may come on at any time. Always disconnect the negative terminal of the battery before working near the fan.
Page 227: Adding Engine Coolant
Your vehicle’s coolant protects your engine from overheating in the summer and from freezing in the winter. Check the level of the coolant at least once a month. Simply look at the engine coolant reservoir located in the engine compartment. To locate the reservoir, see the diagram of your vehicle’s engine under Engine Type, in this chapter.
Page 228 Recycled engine coolant Ford Motor Company recommends that Ford and Lincoln-Mercury dealers use recycled engine coolant produced by Ford-approved processes. Not all coolant recycling processes produce coolant which meets Ford specification ESE-M97B44-A, and use of such coolant may harm engine and cooling system components.
Page 229 Always dispose of used automotive fluids in a responsible manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to the Capacities and Specifications chapter.
Page 230 With the engine OFF and cool, remove the pressure cap, located on the coolant reservoir. Remove the heater hose and clamp, located on the rear of the intake manifold. Add a 50/50 mixture of specified coolant and water to the coolant reservoir. Refer to Refill Capacities later in this chapter for the correct amount.
Page 231: Power Steering Fluid
Power Steering Fluid Check the level of the power steering fluid at least twice a year (i.e., every Spring and Fall). Checking and Adding Power Steering Fluid 1. Start the engine and let it run until the power steering fluid reaches normal operating temperature.
Page 232: Automatic Transmission Fluid
If the power steering fluid is low, do not drive your vehicle for a long period of time before adding fluid. This can damage the power steering pump. Automatic Transmission Fluid Under normal circumstances, you do not need to check the fluid level of the transmission, since your vehicle does not use up transmission fluid.
Page 233 Pull the dipstick out and read the fluid level. When checking fluid at normal operating temperatures 150˚F-170˚F (66˚C-77˚C), the fluid level should be within the crosshatched area on the dipstick. When the vehicle has not been driven, and outside temperatures are above 68˚F (20˚C), the fluid levels should be between the holes on the dipstick.
Page 234 Battery Your vehicle may have a Motorcraft maintenance-free battery. When the original equipment battery is replaced under warranty it may be replaced by a low-maintenance battery. See Motorcraft Parts at the end of this chapter for the proper replacement battery. The low-maintenance battery has removable vent caps for checking the electrolyte level and adding water.
Page 235: Wiper Blades
vehicle. Let the engine idle for at least one minute. (Engine must be warm in order to “learn.”) Also, allow approximately 10 miles (16 km) of stop and go traffic for your vehicle’s engine to completely “relearn” its idle. If you do not let the engine relearn its idle, the idle quality of your vehicle may be adversely affected until the idle is relearned.
Page 236: Tire Rotation
Tires Use an accurate tire pressure gauge. Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 3 miles (5 km). Adjust tire pressure to recommended specifications found on the Safety Compliance Certification Label.
Page 237 Rotating the tires NOTE: Use the five tire rotation only when the conventional spare wheel is the same as road wheels. (Do not mix the steel wheel with aluminum wheels in tire rotation sequence). WARNING Do not use the temporary spare tire in the tire rotation.
Page 238 Because your vehicle’s tires may wear unevenly, you may need to replace them before a wear band appears across the entire tread. WARNING When replacing full size tires, never mix radial, bias-belted, or bias-type tires. Use only the tire sizes that are listed on the tire pressure decal.
Page 239: Temperature A B C
Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 240 WARNING The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. WARNING Driving too fast for conditions creates the possibility of loss of vehicle control.
Page 241: Filling The Fuel Tank
The tires on your vehicle have all-weather treads that provide traction in rain or snow. However, during the winter months in some climates, you may need to use snow tires. WARNING Snow tires must be the same size and grade as the tires you currently have on your vehicle.
Page 242 The remote fuel filler door override handle 1. After opening the fuel filler door, remove the cap carefully and slowly by turning it counterclockwise 1/2 to 3/4 turn. If a hissing sound is heard, wait until it stops, then continue turning until the cap is free. WARNING The fuel system may be under pressure.
Page 243 3. Replace the fuel cap completely when you are finished. Turn it clockwise 1/4 turn until it is tight. It will click when it is fully tightened. 4. Push the fuel door closed. WARNING If you do not use the proper fuel cap, the pressure in the fuel tank can damage the fuel system or cause it to work improperly in a collision.
Page 244 Typical octane rating label Do not be concerned if your vehicle sometimes knocks lightly. However, if it knocks heavily under most driving conditions on the recommended octane fuel, see your dealer or a qualified service technician to prevent any engine damage. Fuel quality If you are experiencing starting, rough idle or hesitation problems try a different brand of fuel.
Page 245 Safety Information Relating to Automotive Fuels WARNING Automotive fuels can cause serious injury or death if misused or mishandled. Turn vehicle off when refueling. Do not smoke when refueling. Fuels are extremely flammable. Do not siphon any fuel by mouth. WARNING Gasoline or gasoline blended with methanol can cause blindness and...
Page 246 Running Out of Fuel NOTE: Avoid running out of fuel because this situation may have an adverse effect on modern powertrain components. You may need to crank the engine several times before the fuel system starts to pump fuel from the tank to the engine.
Page 247 English: MPG = (total miles)/(gallons used). Metric: L/100K = (liters used) x 100/(total kilometers) Comparisons With Environmental Protection Agency (EPA) and Transport Canada (TC) Fuel Economy Estimates EPA fuel economy figures are obtained from laboratory tests under simulated road conditions and may not reflect the actual conditions you experience or your style of driving.
Page 248: Emission Control System
Check windshield washer fluid Check tires for excessive wear or worn edges Check the tire pressure at least monthly Emission Control System Your vehicle is equipped with a catalytic converter which enables your vehicle to comply with applicable exhaust emission requirements. WARNING Exhaust leaks may result in the entry of harmful and potentially lethal fumes...
Page 249 Ford strongly recommends the use of genuine Ford replacement parts. If other than Ford or Motorcraft parts or Ford authorized remanufactured parts are used for maintenance replacements or for the service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 250 Information about your vehicle’s emission control system is on the Vehicle Emission Control Information decal located on or near the engine. This decal identifies engine displacement and gives some tune-up specifications. How to Prepare Your Vehicle for Inspection/Maintenance (I/M) Testing In some localities it may become a legal requirement to pass an Inspection/Maintenance (I/M) test of the On-Board Diagnostic (OBD) II...
Page 251 turn signals side markers license plate lamps The alignment of your headlamps should be checked if: oncoming motorists frequently signal you to turn off your vehicle’s high beams when you do not have the high beams on the headlamps do not seem to give you enough light to see clearly at night the headlamp beams are pointed substantially away from a position slightly down and to the...
Page 252 Parts of a headlamp Removing the headlamp bulb 1. Make sure that the headlamp switch is in the OFF position. 2. Lift the hood, open access panel above headlamp and find the bulb in the headlamp socket. 3. Remove the electrical connector from the bulb by grasping the wire with a quick pull rearward.
Page 253 Installing the headlamp bulb 1. With the flat side of the bulb’s plastic base facing upward, insert the glass end of the bulb into the socket. You may need to turn the bulb left or right to line up the grooves in the plastic base with the tabs in the socket.
Page 255: Cleaning Your Vehicle
Cleaning Your Vehicle Washing and Polishing Your Vehicle Wash the outside of your vehicle, including the underside, with a mild detergent. DO NOT: Wash your vehicle with hot water Wash your vehicle while it sits in direct sunlight Wash your vehicle while the body is hot Pollen, bird droppings and tree sap can damage the paint, especially in hot weather.
Page 256 Cleaning Plastic Parts Some of your vehicle’s exterior trim parts are plastic. Clean with a tar and road oil remover if necessary. Use a vinyl cleaner for routine cleaning. Do not clean plastic parts with thinners, solvents or petroleum-based cleaners. If you have your vehicle rustproofed, remove oversprayed rustproofing with a tar and road oil remover.
Page 257 Cleaning the Seats Leather For routine cleaning, wipe the surface with a soft, damp cloth. For more thorough cleaning, wipe the surface with a leather and vinyl cleaner or a mild soap. Wipe the surface with a damp, soft cloth, then dry and buff with a dry, soft cloth.
Page 258: Capacities And Specifications
Capacities and Specifications Refill Capacities, Motorcraft Parts, and Lubricant Specifications Motorcraft Parts...
Page 259 Fluid Specifications and Capacities NOTE: Rear axle lube quantities must be replaced every 100,000 miles (160,000 km) or if the axle has been submerged in water. Otherwise, the lube should not be checked or changed unless a leak is suspected or repair required.
Page 260 Lubricant Specifications...
Page 261: Vehicle Storage
NOTE: Rear axle lube quantities must be replaced every 100,000 miles (160,000 km) or if the axle has been submerged in water. Otherwise, the lube should not be checked or changed unless a leak is suspected or repair required. Vehicle Storage Maintenance Tips If you plan on storing your vehicle for an extended period of time (60 days or more), refer to the...
Page 262 Engine Start engine every 15 days. Run at fast idle until it reaches normal operating temperature. With your foot on the brake, shift through all the gears while the engine is running. Fuel system Fill fuel tank with high-quality, premium unleaded fuel until the first automatic shutoff of the fuel pump nozzle.
Page 263 Brakes Make sure brakes and parking brake are fully released. Tires Maintain recommended air pressures. Miscellaneous Make sure all linkages, cables, levers and clevis pins under vehicle are covered with grease to prevent rust. Move vehicles at least 25 feet (8 m) every 15 days to lubricate working parts and prevent corrosion.
Page 264: Reporting Safety Defects
Reporting Safety Defects (U.S. Only) Reporting Safety Defects (U.S. Only) If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company.
Page 265: Customer Assistance
Ford recommends taking your vehicle to your selling dealer who wants to ensure your continued satisfaction. You may, however, take your vehicle to any authorized Ford or Lincoln-Mercury dealer. In most cases, your dealer will be able to resolve your concern.
Page 266: The Dispute Settlement Board
If you have any questions or concerns that the dealership cannot answer, contact the Customer Assistance Center. If you still have a complaint involving a warranty dispute, you may wish to contact the Dispute Settlement Board (U.S. only) or the Canadian Motor Vehicle Arbitration Plan (CAMVAP) in Canada.
Page 267 What Kind of Cases Does the Board Review? The Board reviews all warranty performance complaints on Ford, Mercury and Lincoln cars and Ford and Mercury light trucks under the new vehicle limited warranty that have not been resolved by either a dealer or Ford Motor Company,...
Page 268 How does the Board Work? The Board consists of: three consumer representatives a Ford or Lincoln/Mercury dealer Consumer candidates for Board membership are recruited and trained by an independent consulting firm. Dealers are chosen because of their business leadership qualities.
Page 269 a brief description of your unresolved concern a brief summary of the action taken with the dealer and Ford Motor Company the names (if known) of all the people you contacted at the dealership a description of the action you expect to resolve your concern Should your case NOT qualify for review, a letter of explanation will be mailed to you.
Page 270 If you live in Canada and have any questions or concerns that the dealership cannot answer, contact the Lincoln Centre. Please have the following information available when contacting the Lincoln Centre: your telephone number (both business and home) the name of the dealer and the city where the...
Page 271: Canada Only
Vehicle Identification Number (VIN/Serial Number) Mediation/Arbitration Program (Canada Only) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 272 Getting Help Outside the U.S. and Canada Before you export your vehicle to a foreign country, contact the appropriate foreign embassy or consulate to make sure local regulations do not prevent you from registering your vehicle. Officials at the embassy can also help you decide whether you should import your vehicle to that country.
Page 273 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write to: If you are in other foreign countries, contact the nearest Ford dealership.
Page 274 Accessories Ford Accessories for Your Vehicle A wide selection of accessories is available through your local authorized dealer. These fine accessories have been engineered specifically to fulfill your automotive needs. They are custom designed to complement the style and aerodynamic appearance of your Ford-built vehicle.
Page 275 NOTE: When adding accessories, equipment, passengers, and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR, GAWR as shown on the Safety Compliance Certification Label). Consult your dealer for specific weight information. NOTE: The Federal Communications Commission (FCC) or the Canadian Radio Telecommunications Commission (CRTC) regulates the use of mobile...
Page 276 NOTE: Mobile communications systems may harm the operation of your vehicle, particularly if they are not properly designed for automotive use or are not properly installed. For example, when operated, such systems may cause the engine to stumble or stall. In addition, such systems may themselves be damaged or their operation affected by operating your vehicle.
Page 286 Index ABS warning light (see Anti-lock brake system) ... . Accessory position on the ignition ..Accessory power source, power point outlet ... . . Accident damage .
Page 287 Anti-theft system arming the system ..116 description ... . . 116 disarming an untriggered system ..118 disarming a triggered system.
Page 288 Brake fluid brake warning light..checking and adding ..221 description ... . . 221 specifications .
Page 289 Charging system warning light ..Childproof locks ... . Child safety restraints ..140 child safety belts ... 158 child safety seats .
Page 290 Climate control system air conditioning ... electronic automatic temperature control ....heating ....Clock .
Page 291 Driving under special conditions heavy load ... . . 177 towing a trailer ... 179 Electrical system circuit breakers ... 191 fuses .
Page 292 Engine coolant checking and adding ..224 disposal ....212 preparing for storage ..261 proper solution .
Page 293 Fuel calculating fuel economy ..244 capacity....258 choosing the right fuel ..240 comparisons with EPA fuel economy estimates .
Page 294 odometer ....speedometer... . . GAWR (Gross Axle Weight Rating) calculating ... . . 178 definition .
Page 295 High beams (continued) operation ....Hood ....215 latch location ... . 215 lubrication specifications .
Page 296 Lamps autolamp delay system ..checking ....248 daytime running light system ..flashing the lamps ..hazard flashers.
Page 297 Maintenance schedule and record (see separate Maintenance Schedule and Record booklet) ... Maintenance (see Servicing) ..211 Master cylinder, brakes ..221 Memory seat (programmable memory seat) .
Page 298 PCV valve, specifications ..257 Phone, cellular ... . . 101 Power features mirrors ....moon roof.
Page 299 Restraints, safety (see Safety restraints) adult ....124 child ....140 head .
Page 300 in rear outboard ..in rear seat ... . . 141 tether anchorage hardware ..158 Seat belts (see Safety restraints) ..124 Seats adjusting the seats, power .
Page 301 Steering, power ... . 173 Steering wheel horn ....locking ....tilting .
Page 302 Transmission automatic operation ..173 fluid, checking and adding (automatic) . 230 fluid, refill capacities ..258 lubricant specifications ..259 Transmission control switch .
Page 303 Warm engine, starting..163 Warning chimes headlamps on ... . key in ignition ... . safety belt.
Page 304 Windshield washer fluid and wipers checking and adding fluid ..222 checking and replacing wiper blades . . 233 low washer fluid light ..operation ....reservoir .
Page 305 Service Station Information...

This manual is also suitable for:

2009 town car

Lincoln 1997 Town Car Owner's Manual

Quick Links

Related Manuals for Lincoln 1997 Town Car

Summary of Contents for Lincoln 1997 Town Car

This manual is also suitable for:

Table of Contents
