Before driving Introduction Instrumentation Controls and features Seating and safety restraints Starting and driving Starting Driving Roadside emergencies Servicing Maintenance and care Capacities and specifications Customer assistance Reporting safety defects Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.
Page 2: Introduction
Introduction ICONS Indicates a safety alert. Read the following section on Warnings. Indicates vehicle information related to recycling and other environmental concerns will follow. Correct vehicle usage and the authorized disposal of waste cleaning and lubrication materials are significant steps towards protecting the environment.
Page 3 Introduction WARNINGS Warnings provide information which may reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment. BREAKING-IN YOUR VEHICLE There are no particular breaking-in rules for your vehicle. During the first 1 600 km (1 000 miles) of driving, vary speeds frequently. This is necessary to give the moving parts a chance to break in.
Page 4: Instrumentation
Instrumentation Headlamp control (pg. 24) Turn signal and wiper/washer control (pg. 48) LIGHTS AUTO LAMP Instrument panel Auto lamp (pg. 25) dimmer switch (pg. 25) * If equipped Instrument cluster (pg. 6) – TURN ON HEAD LAMPS FILL ON RIGHT SERVICE ENGINE SOON...
Page 5: Message Center
Message Center Electronic sound system control* (pg. 49) 000000.0 Climate controls* (pg. 49) Clock (pg. 12) (pg. 32) SYSTEM DRIVER ID SELECT MENU VEHICLE HANDLING DISPLAY TRIP RESET DTE ECON PUSH ON TAPE SEEK TUNE MUTE SIDE 1 2 AUTO BACK BOTH HEATED...
Page 6 Instrumentation WARNING LIGHTS AND CHIMES TURN ON HEAD LAMPS FILL ON RIGHT SERVICE ENGINE SOON BRAKE Service engine soon Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD II).
Page 7 These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel and/or properly installing and securely tightening the gas cap. After three driving cycles without these or any other temporary malfunctions present, the Service Engine Soon light should turn off.
Page 8 Instrumentation Also illuminates when the parking brake is engaged. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately. Anti-lock brake system (ABS) Momentarily illuminates when the ignition is turned to the ON position and the engine is off.
Page 9 Instrumentation Charging system Illuminates when the ignition is turned to the ON position and the engine is off. The light also illuminates when the battery is not charging properly, requiring electrical system service. Engine oil pressure Momentarily illuminates when the ignition is turned to the ON position and the engine is off.
Page 10: Fuel Gauge
Instrumentation Headlamps on warning chime Sounds when the headlamps or parking lamps are on, the ignition is off (and the key is not in the ignition) and the driver’s door is opened. Turn signal chime Sounds when the turn signal lever has been activated to signal a turn and the vehicle is driven more than 0.8 km (1/2 mile).
Page 11 Speedometer Indicates the current vehicle speed. Odometer The odometer is located in the message center. It registers the total kilometers (miles) of the vehicle. Pressing the E/M control will alternate between English (miles) and Metric (kilometers) measurements. Tachometer Indicates the engine speed in revolutions per minute.
Page 12 Instrumentation Never remove the coolant reservoir cap while the engine is running or hot. This gauge indicates the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level the gauge indication will not be accurate. ELECTRONIC MESSAGE CENTER The electronic message center only works when the ignition is in the...
Page 13 If you have a vehicle with the Driver Select System, you have a DRIVER ID control in place of the E/M control. • Refer to DRIVER ID (if equipped) for DRIVER ID control information. • Refer to E/M (if equipped) for E/M control information.
Page 14 Instrumentation • distance to empty • traction control • ride control System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems. The message center will display the last selected feature if there are no more warning messages.
Page 15 Warning messages that have been reset are divided into two categories: • They will reappear on the display ten minutes from the reset. • They will not reappear until an ignition OFF-ON cycle has been completed. This acts as a reminder that these warning conditions still exist within the vehicle.
Page 16 Instrumentation E/M (if equipped) Press this control to switch the odometer and the message center display from metric (kilometers) to English (miles) units, and to change the temperature indication on the climate control unit. DRIVER ID (if equipped) Press this control to set vehicle DRIVER ID comfort settings for up to two drivers.
Page 17 Instrumentation Press the SELECT control to change SELECT these settings while in VEHICLE HANDLING mode. The combination of firm ride control (if equipped) and low steering effort is undesirable and cannot be selected. MENU Press this control to change various MENU convenience settings throughout the vehicle.
Page 18 Instrumentation under Operator Selectable Features. Refer to “Message Center” in this chapter for more information on the Message Center controls. The Message Center has a Driver ID control, which when pressed, allows the driver to select either Driver 1, Driver 2 or OFF. Selecting OFF will turn the system OFF.
Page 19 Once the system has identified the driver (DRIVER MEMORY 1 or DRIVER MEMORY 2), the seat and mirror will automatically begin to move to that driver profile. Changes made to the seat or mirror positions will automatically be saved to that profile. If the driver should enter the vehicle without first identifying themselves, all features will remain at their last setting or position and any settings will be saved as vehicle settings not individualized settings.
Page 20 Instrumentation • The DRIVER ID control will display the option of selecting Driver 1, Driver 2 or OFF (Driver Select System only). Memory profile features Express window • Setting is saved as vehicle setting only. • Vehicle with optional Driver Select System, setting may be saved to either the DRIVER MEMORY 1 or 2 personalized profiles or as a vehicle setting.
Page 21 • Vehicle with optional Driver Select System, setting may be saved to either the DRIVER MEMORY 1 or 2 personalized profiles or as a vehicle setting. • Settings-ON or OFF • Original setting-ON • Setting adjustment made using: Message Center-MENU/SELECT controls Reverse mirrors •...
Page 22 Instrumentation Adjustable steering • Setting is saved as vehicle setting only. • Vehicle with optional Driver Select System, setting may be saved to either the DRIVER MEMORY 1 or 2 personalized profiles or as a vehicle setting. • Settings-low, normal, high •...
Page 23 • Settings-8–way adjustment • Original setting-N/A • Setting adjustment made using: driver seat control Outside mirror position • Setting may be saved to either the DRIVER MEMORY 1 or 2 personalized profiles or as a vehicle setting. • Vehicle with optional Driver Select System, setting may be saved to either the DRIVER MEMORY 1 or 2 personalized profiles or as a vehicle setting.
Page 24: Controls And Features
Controls and features HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps only. Rotate to the second position to also turn on the headlamps. The exterior lamps will illuminate when the ignition is ON and the windshield wiper control is in the interval, LO or HI position.
Page 25 Flash to pass Pull toward you to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlight and parklamp operation. • Push up to brighten. • Push down to dim. AUTOLAMP CONTROL The autolamp system provides light sensitive automatic on-off control of the exterior lights normally...
Page 26: Automatic Operation
Controls and features CLIMATE CONTROL SYSTEM Electronic Automatic Temperature Control (EATC) system The EATC system will maintain a selected temperature and automatically control airflow. You can override automatic operation with any of the override controls, the fan speed control or the steering wheel controls (if equipped).
Page 27 Controls and features If unusual conditions exist (i.e.-window fogging, etc.), the manual override controls allow you to select airflow locations and the fan control allows you to adjust fan speed as necessary. Temperature selection The display window indicates the ˚ selected temperature, function (AUTO or one of the override controls) and manual control of fan...
Page 28 Controls and features Fan speed ( When AUTO is pressed, fan speed is adjusted automatically for existing conditions. You can override fan speed at any time. To control fan speed manually, press the fan control or the steering wheel fan speed control to cancel automatic AUTO fan speed operation.
Page 29 • MAX A/C-Uses recirculated air to cool the vehicle. The temperature will display 16°C (60°F). To exit, press AUTOMATIC or any other override controls. MAX A/C is noisier than normal A/C but more economical and will cool the inside of the vehicle faster. Airflow is from the instrument panel registers.
Page 30 Controls and features Displaying outside temperature Press EXT to display the outside air temperature. It will be displayed until EXT is pressed again. If the selected temperature is changed while the outside temperature is displayed, the new temperature will be displayed for four seconds after it is changed, then the outside temperature will return to the window.
Page 31 • If your vehicle has been parked with the windows closed during hot weather, the air conditioner will do a much faster job of cooling if you drive for two or three minutes with the windows open. This will force most of the hot, stale air out of the vehicle.
Page 32 Controls and features CLOCK Press + to increase the time displayed. Press – to decrease the time displayed. USING YOUR AUDIO SYSTEM Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated.
Page 33 High Level Audio System with Premium AM/FM Stereo/Cassette (Radio Controlled CD Changer Compatible) PUSH ON TAPE MUTE Premium AM/FM Stereo/Cassette/Alpine Audio System (Radio Controlled CD Changer Compatible) PUSH ON TAPE MUTE Controls and features DOLBY B NR SEEK TUNE SIDE 1-2 SEEK SIDE 1-2 BASS...
Page 34 Controls and features Your vehicle is equipped with a delayed accessory feature. This feature enables the audio playing media to continue playing up to 10 minutes after the ignition has been turned off, or until a door is opened. Volume/power control Press the control to turn the audio system on or off.
Page 35 • to increase volume compensation • to decrease or shut off the volume compensation AM/FM select The AM/FM select control works in radio, tape and CD modes (if equipped). AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations.
Page 36 Controls and features Tune adjust for CD changer (if equipped) • Press to select the previous disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in shuffle mode.) Refer to Shuffle feature for more information. Hold the control to continue reversing through the disc.
Page 37 Controls and features Scan function The scan function works in radio, tape or CD mode (if equipped). SCAN Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to stop the scan mode.
Page 38 Controls and features Autoset memory preset Autoset allows you to set strong radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations. Starting autoset memory preset 1.
Page 39 Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. Tape/CD select (if equipped) • To begin tape play (with a tape loaded into the audio system) while in the radio or CD mode, press the TAPE control.
Page 40 Controls and features • In CD mode, pressing the REW control for less than three seconds results in slow rewind. Pressing the control for more than three seconds results in fast rewind. Fast forward The fast forward control works in tape and CD modes (if equipped).
Page 41 Press the COMP control to activate and deactivate compression adjust. Shuffle feature The shuffle feature operates in CD mode and plays all tracks on the current disc in random order. If equipped with the CD changer, the shuffle feature continues to the next disc after all tracks are played. Press the SHUFFLE control to start this feature.
Page 42 Controls and features • Use the SEL control to select the program type. With the feature on, use the SEEK or SCAN control to find the desired program type from the following selections: • Classic • Country • Info • Jazz •...
Page 43 Mute mode Press the control to mute the playing media. Press the control again to return to the playing media. Digital signal processing (if equipped) The digital signal processing (DSP) feature allows you to change the signal mode to suit your listening tastes.
Page 44 Controls and features CD changer (if equipped) Your CD changer is either located in the passenger’s footwell area or in the center console. Slide the door to access the CD changer magazine. Press to eject the magazine. Make sure only one disc is inserted in each slot.
Page 45 The magazine does not need to be full for the changer to operate. Radio power must be turned on to play the CDs in the changer. The magazine may be stored in the glove compartment when not being used. The CD magazine may be inserted or ejected with the radio power off. Troubleshooting the CD changer (if equipped) The laser beam used in the compact disc player is harmful to the eyes.
Page 46 Controls and features CD and CD changer care • Handle discs by their edges only. Never touch the playing surface. • Do not expose discs to direct sunlight or heat sources for extended periods of time. • Do not insert more than one disc into each slot of the CD changer magazine.
Page 47 Radio reception factors Three factors can affect radio reception: • Distance/strength. The further an FM signal travels, the weaker it is. The listenable range of the average FM station is approximately 40 km (24 miles). This range can be affected by “signal modulation.” Signal modulation is a process radio stations use to increase their strength/volume relative to other stations.
Page 48 Controls and features WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals.
Page 49 The flash rate of the turn signal will speed up considerably if the Lighting Control Module detects a left or right turn lamp bulb (front or rear) is burned out. STEERING WHEEL CONTROLS (IF EQUIPPED) Radio control features • Press BAND/MODE to select AM, FM1, FM2, TAPE or CD (if equipped).
Page 50 Controls and features SPEED CONTROL To turn speed control on • Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). When the ON control is pressed, the message “SPEED CONTROL READY”...
Page 51 To set a speed • Press SET ACC/SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). When the SET ACCEL control is pressed, the message “SPEED CONTROL SET”...
Page 52 Controls and features • Accelerate with your accelerator pedal, then press and release SET ACC/SET ACCEL. When the SET ACCEL control is pressed and released, the message “SPEED CONTROL SET” will appear for 5 seconds in your message center. You can accelerate with the accelerator pedal at any time during speed control usage.
Page 53 • Press the OFF control. Pressing OFF will erase the previously programmed set speed. When the OFF control is pressed, the message “ SPEED CONTROL OFF” will appear for 5 seconds in your message center. To return to a previously set speed •...
Page 54 Controls and features Never adjust the steering wheel when the vehicle is moving. INTERIOR LAMPS Map lamps To turn on the map lamps, press the control next to each lamp. If equipped with a moon roof, the map lamps are located on the rearview mirror.
Page 55 It is important that you understand the limitations of your Lincoln RESCU System prior to initiating an activation. See Lincoln RESCU System Limitations later in this chapter for details. The RESCU system can be activated in three ways: 1. By pressing the Information control.
Page 56 Controls and features Quick summary • To utilize your vehicle’s RESCU system, your cellular phone must be activated and plugged into the vehicle interface. • Information or emergency assistance can be requested whenever your key is in the RUN/START position and for six minutes after the vehicle is turned off.
Page 57 Controls and features General description Lincoln’s Remote Emergency Satellite Cellular Unit (RESCU) is designed to expedite roadside, emergency or information assistance to distressed motorists who are uncertain of their location and/or are uncertain of who to contact for assistance. The Lincoln RESCU system utilizes Global Positioning System (GPS) technology and the nation’s cellular phone network to track vehicle...
Page 58 • when medical attention is required. • to receive assistance in an emergency situation. When this control is pressed, the Lincoln Security Response Center relays details of your situation and your location to the appropriate authorities via three-way phone call. While the appropriate authorities dispatch help to your location, the response center will: •...
Page 59 Controls and features Activation and deactivation When either of the two Lincoln RESCU controls are pressed, or the air bags are deployed (this will activate the system as an emergency automatically), a warning light, located in the overhead console, will begin to flash and status messages will be displayed on the vehicle’s...
Page 60 Controls and features Message center interface During an activation, Lincoln RESCU communicates with the vehicle’s message center. Status messages describing the sequence of the steps being executed are displayed, allowing you to visually follow the activation process. The following messages are typical of those displayed during an assistance request.
Page 61 Location data retransmit capability During an activation, the Lincoln Security Response Center operator has the capability to initiate a retransmission of the electronic data message. This may be necessary to ensure a more precise determination of vehicle location or to track a vehicle that is moving.
Page 62 • Inoperative if battery discharged or disconnected Lincoln RESCU is powered by the vehicle’s battery and will not operate if the battery is discharged or disconnected. • Inoperative if cellular phone is not installed in the vehicle interface Lincoln RESCU utilizes your vehicle’s cellular phone and will not operate...
Page 63 (PIN). In this situation, the user is required to enter the PIN with any phone calls made over the network. The PIN feature is not compatible with the Lincoln RESCU System. At the time your phone is activated, ask your carrier to assign you a phone number that does not require a personal identification number.
Page 64 Some cellular carriers offer customers various optional features with their cellular services. Several of these features are not compatible or could potentially limit the performance of your Lincoln RESCU System. No outgoing calls, hotline and NPA restrictions are incompatible cellular features and must be avoided.
Page 65 Security Response Center, indicate that you are a new user and the operator will follow special acquaintance period support procedures which are intended to familiarize you with your Lincoln RESCU System. As described previously, the acquaintance call can also be used to...
Page 66 You will be responsible, however, for any charges imposed by your cellular phone carrier for the 1–800 phone call to the Lincoln Security Response Center. After your initial service period expires, you will be required to pay a monitoring fee if you elect to continue emergency and roadside assistance.
Page 67 ILLUMINATED VISOR MIRROR To turn on the LH visor mirror lamps, lift the mirror cover. Adjust the amount of light by sliding the control. To turn on the RH visor mirror lamps, lift the mirror cover. HOMELINK UNIVERSAL TRANSCEIVER (IF EQUIPPED) The HomeLink Universal Transceiver, located on the driver’s visor, provides a convenient way to replace up to three hand-held transmitters with a single built-in device.
Page 68 Controls and features Programming 1. Prepare for programming the HomeLink Universal Transceiver by erasing the three factory default codes by holding down the two outside buttons until the red light begins to flash after 20 seconds. Release both buttons. 2. Hold the end of your hand-held transmitter 5–14 cm (2–5 inches) away from the HomeLink Universal Transceiver surface (located on your visor) while keeping the red light in...
Page 69 To program your hand-held transmitters: • continue to hold the button on the HomeLink Universal Transceiver. • press and re-press the hand-held transmitter button every two seconds until the red light changes from a slow to a fast flash. Operating the HomeLink Universal Transceiver Once programmed, the HomeLink Universal Transceiver can be used in place of hand-held transmitters.
Page 70 Controls and features 3. Press and release the programmed HomeLink button. Press and release the HomeLink button a second time to complete the training process. (Some garage door openers may require this procedure to be done a third time to complete the training). The 2nd or 3rd press from step 3 will activate the door.
Page 71 Controls and features ELECTRONIC COMPASS (IF EQUIPPED) The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antennas. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy. Usually, when something affects the compass readings, the compass will correct itself after a few days of operating your vehicle in normal conditions.
Page 72 Controls and features 2. Locate the compass module mounted at the base of mirror. 3. Turn the ignition to the ON position. 4. Insert an appropriate diameter rod (paperclip) into the right switch access hole underneath the compass module and gently press for 1 to 2 seconds until ZONE and the current zone setting are displayed on the upper right corner of the mirror.
Page 73 Controls and features 5. Release pressure from the switch. 6. Slowly drive the vehicle in a circle (less than 5 km/h [3 mph]) until the CAL indicator turns off. This will take up to five circles to complete calibration. 7. The compass is now calibrated. The compass display will remain on for approximately 40-45 minutes after the ignition key is removed.
Page 74 Controls and features POWER DOOR LOCKS Press U to unlock all doors and L to lock all doors. Smart locks With the key in the ignition, in any switch position, and either the driver’s or passenger’s door open, the doors cannot be locked using the front door lock switches.
Page 75 Controls and features • Pull the top portion of the rocker switch to close. Express down To make the driver window open fully without holding the window control, press the driver window control completely down. Press or pull the control to stop window operation.
Page 76 Controls and features POWER SIDE VIEW MIRRORS The ignition must be in ACC or ON position to adjust the power side view mirrors. To adjust your mirrors: 1. Select L to adjust the left mirror or R to adjust the right mirror. 2.
Page 77 Controls and features CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the LOCKED doors are unlocked. VERROUILLEE The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 78 Controls and features FUEL DOOR RELEASE Your vehicle is equipped with a locking fuel door. To open the door, press the control located on the door. Fuel filler door override release If the remote release is inoperative, open the trunk, then pull the override release handle located inside the trunk on the passenger side to open the fuel filler door.
Page 79 Mini console (if equipped) The mini console is available in the six passenger vehicle only, and consists of the: • cupholder • compact disc changer (if equipped) • ashtray and lighter Use only soft cups in the cupholder. Hard objects can injure you in a collision.
Page 80 Controls and features The system is ready to arm whenever the ignition is turned OFF. Any of the following actions will prearm the alarm system: • Lock the doors with the remote transmitter (doors opened or closed). The horn will chirp to confirm that the control was pressed.
Page 81 • Unlock the doors by using your keyless entry keypad. • Unlock the doors with a key. Turn the key full travel (toward the front of the vehicle) to make sure the alarm disarms. • Turn ignition to ACC or ON. REMOTE ENTRY SYSTEM The remote entry system allows you to lock or unlock all vehicle doors without a key.
Page 82 Controls and features This process will arm your anti-theft system (if equipped). For more information on arming the anti-theft system, refer to Perimeter anti-theft system in this chapter. Opening the trunk Press the control once to open the trunk. Ensure that the trunk is closed and latched before driving your vehicle.
Page 83 Controls and features Replacing the battery The transmitter is powered by one coin type three-volt lithium battery CR2032 or equivalent. Typical operating range will allow you to be up to 10 meters (33 feet) away from your vehicle. A decrease in operating range can be caused by: •...
Page 84 Controls and features Replacing lost transmitters Take all your vehicle’s transmitters to your dealer if service is required. If you purchase additional transmitters (up to four may be programmed), perform the following procedure: To reprogram the transmitters yourself, place the key in the ignition and turn from OFF to ON eight times in rapid succession (within 10 seconds) end in ON.
Page 85 Press the control once to unlock the driver’s door and move the memory features to the corresponding memory position, just as if you had pressed the memory control in the vehicle. • transmitter #1 will recall memory profile position #1. •...
Page 86 Controls and features Your vehicle has a factory-set 5–digit code that operates the keyless entry system. You can also program your own 5–digit personal entry code. The factory-set code is located: • on the owner’s wallet card in the glove compartment •...
Page 87 Erasing personal code To erase all of the personal entry codes programmed to a vehicle: 1. Enter the factory-set code. 2. Press 1/2 within 5 seconds of step 3. Press and hold 1/2 for two seconds. All of the vehicle doors will lock and then unlock to confirm erasure.
Page 88 Controls and features Locking doors with the keyless entry system It is not necessary to enter the factory-set code prior to locking all doors. To lock the doors: 1. Press 7/8 and 9/0 at the same time. 7 8 9 0 Autolock The autolock feature will lock all of the doors when: •...
Page 89 The SecuriLock passive anti-theft system provides an advanced level of vehicle theft protection. Your vehicle’s engine can only be started with the two special SecuriLock your vehicle. Each time you start your vehicle, the SecuriLock read by the SecuriLock key identification code matches the code stored in the SecuriLock passive anti-theft system, the vehicle’s engine is allowed to start.
Page 90 Controls and features Theft indicator The theft indicator on top of the dash will operate as follows: • When the ignition is OFF, the theft indicator will flash briefly every 2 seconds to indicate the SecuriLock vehicle. • When the ignition is turned to RUN or START, the theft indicator will light for 3 seconds and then go out.
Page 91 Controls and features 3. Within five seconds of turning the ignition to OFF, insert the second previously programmed SecuriLock key into the ignition and turn the ignition from OFF to RUN (maintain ignition in RUN for at least one second but no more than 5 seconds). 4.
Page 92: Seating And Safety Restraints
Seating and safety restraints SEATING Adjustable head restraints Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 93 Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Press the control to recline the seatback forward or backward.
Page 94 Seating and safety restraints Press to move the rear portion of the seat cushion up or down. Heated seats (if equipped) To operate the heated seats: • Slide the control to BACK to heat the seatback only. • Slide the control to BOTH to heat the seatback and the seat cushion.
Page 95 Easy access/easy out feature This feature automatically moves the driver’s seat backward when: • the transmission is in N (Neutral) or P (Park) • the key is removed from the ignition cylinder The seat will move 5cm (2 inches) forward (to the original position) when: •...
Page 96 Seating and safety restraints Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only.
Page 97 Automatic locking mode In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. When to use the automatic locking mode •...
Page 98 Seating and safety restraints • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode.
Page 99 Seating and safety restraints Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 100 Seating and safety restraints Safety belt warning light and indicator chime The seat belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If... The driver’s safety belt is not buckled before the ignition switch is turned to the ON position...
Page 101 AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) – ANTI ACTIVE THEFT FILL ON RIGHT RPMx1000 SERVICE ENGINE SOON BRAKE LIGHTS AUTO LAMP Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries.
Page 102 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer. Children and air bags For additional important safety information, read all information on safety restraints in this guide.
Page 103 Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 104 Seating and safety restraints While the system is designed to help reduce serious injuries, it may also cause minor burns, abrasions, swelling or temporary hearing loss. Because air bags must inflate rapidly and with considerable force, there is the risk of death or serious injuries such as fractures, facial and eye injuries or internal injuries, particularly to occupants who are not properly restrained or are otherwise out of position at the time of air bag deployment.
Page 105 Do not attempt to service, repair, or modify the air bag Supplemental Restraint System, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always wear their safety belts even when an air bag SRS is provided.
Page 106 Seating and safety restraints How does the side air bag system work? The side air bag system consists of the following: • An inflatable nylon bag (air bag) with a gas generator concealed behind the outboard bolster of the driver and front passenger seatbacks.
Page 107 Several air bag system components get hot after inflation. Do not touch them after inflation. If the side air bag has deployed, the air bag will not function again. The side air bag system (including the seat) must be inspected and serviced by a qualified technician in accordance with the vehicle service manual.
Page 108 Seating and safety restraints SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children. Also see Air Bag Supplemental Restraint System (SRS) in this chapter for special instructions about using air bags.
Page 109 Children and safety belts If the child is the proper size, restrain the child in a safety seat. Children who are too large for child safety seats (as specified by your child safety seat manufacturer) should always wear safety belts. Follow all the important safety restraint and air bag precautions that apply to adult passengers in your vehicle.
Page 110 Seating and safety restraints SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child. Carefully follow all of the manufacturer’s instructions with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.
Page 111 Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps, refer to Attaching safety seats with tether straps. Carefully follow all of the manufacturer’s instructions included with the safety seat you put in your vehicle.
Page 112 Seating and safety restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 113 Seating and safety restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 114 Additional kit can be obtained and installed at no charge from any Ford or Lincoln-Mercury dealer. The tether strap anchorage bracket for the rear center seating position was factory installed and is located directly beneath the rear window trim panel, which is behind the rear seat back.
Page 115: Starting
PREPARING TO START YOUR VEHICLE Engine starting is controlled by the ignition system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
Page 116 Starting 2. Make sure the headlamps and vehicle accessories are off. • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). 3. Turn the key to 4 (ON) without turning the key to 5 (START). HOOD...
Page 117: Starting The Engine
TURN ON HEAD LAMPS FILL ON RIGHT SERVICE ENGINE SOON BRAKE Make sure the corresponding lights illuminate briefly. If a light fails to illuminate, have the vehicle serviced. • If the driver’s safety belt is fastened, the STARTING THE ENGINE 1.
Page 118 Starting Using the engine block heater (if equipped) An engine block heater warms the engine coolant, which improves starting, warms up the engine faster and allows the heater-defroster system to respond quickly. Use of an engine block heater is strongly recommended if you live in a region where temperatures reach -23°C (-10°F) or below.
Page 119 Starting Important ventilating information If the engine is idling while the vehicle is stopped in an open area for long periods of time, open the windows at least 2.5 cm (one inch). Adjust the heating or air conditioning (if equipped) to bring in fresh air. Improve vehicle ventilation by keeping all air inlet vents clear of snow, leaves and other debris.
Page 120: Driving
Driving BRAKES Your service brakes are self-adjusting. Refer to the maintenance guide and or service guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 121 ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned on and the engine is off. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the...
Page 122 Driving Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn off the ignition whenever you leave your vehicle. The parking brake is not recommended to stop a moving vehicle. However, if the normal brakes fail, the parking brake can be used to stop your vehicle in an emergency.
Page 123 Driving Wheel-speed sensors allow excess front wheel spin to be detected by the Traction Control portion of the ABS computer. Any excessive wheel spin is controlled by automatically applying and releasing the front brakes in conjunction with engine torque reductions. Engine torque reduction is realized via the fully electronic spark and fuel injection systems.
Page 124 Driving If the power steering system breaks down (or if the engine is turned off), you can steer the vehicle manually, but it takes more effort. If the steering wanders or pulls, the condition could be caused by any of the following: •...
Page 125 The air suspension shut-off switch is located on the left side of the trunk. If this switch is in the OFF position, the rear air suspension will not operate. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle.
Page 126 Driving If your vehicle gets stuck in mud or snow it may be rocked out by shifting from forward and reverse gears in a steady pattern. Press lightly on the accelerator in each gear. Do not rock the vehicle for more than a few minutes, because it could damage the vehicle.
Page 127 Understanding gearshift positions P (Park) Always come to a complete stop before shifting into P (Park). Make sure the gearshift is securely latched in P (Park). This locks the transaxle and prevent the front wheels from rotating. Always set the parking brake fully and make sure the gearshift is securely latched in P (Park).
Page 128 Driving N (Neutral) With the gearshift in the N (Neutral) position, the vehicle can be started and is free to roll. Hold the brake pedal down while in this position. D (Overdrive) The overdrive position is the normal driving position for an automatic overdrive transaxle.
Page 129 Driving When to use 3 (Third) 3 (Third) eliminates the needless shifting back and forth between third and fourth gears that your vehicle may do when driving on hilly terrain. It also gives more engine braking than overdrive to slow your vehicle on downgrades.
Page 130 Driving When parking, do not use the gearshift in place of the parking brake. Always set the parking brake fully and make sure that the gearshift is securely latched in Park (P). Turn off the ignition whenever you leave your vehicle. Never leave your vehicle unattended while it is running.
Page 131 • GAWR (Gross Axle Weight Rating) : Carrying capacity for each axle system. The GAWR is specific to each vehicle and is listed on the Safety Compliance Label on the driver’s door pillar. • GCWR (Gross Combined Weight Rating) : Maximum combined weight of towing vehicle (including passengers and cargo) and the trailer.
Page 132 38°C [100°F]) Your vehicle does not come from the factory fully equipped to tow. However, you can contact your local Lincoln dealer to get the proper towing equipment. Do not tow a trailer until your vehicle has been driven at least 3 200 km (2 000 miles).
Page 133 The amount of weight your loaded trailer should be no more than 907 kg (2 000 lbs.). Do not exceed the GVWR or the GAWR specified on the Safety Compliance Certification Label. Towing trailers beyond the maximum recommended gross trailer weight could result in engine damage, transmission/axle damage, structural damage, loss of control, and personal injury.
Page 134 Do not connect a trailer’s lighting system directly to your vehicle’s lighting system. To get the proper equipment for hooking up your trailer’s lamps, see your Lincoln dealer. Be sure to follow their instructions carefully. If you do not install trailer lights correctly, you may cause damage to the vehicle’s lighting system or other vehicle systems.
Page 135: Roadside Emergencies
HAZARD FLASHER Use only in an emergency to warn traffic of vehicle breakdown, approaching danger, etc. The hazard flashers can be operated when the ignition is off. • The hazard lights control is located on top of the steering column. •...
Page 136 Roadside emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Always replace a fuse with one that has the specified amperage rating.
Page 137 Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal. Remove the panel cover to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 138 Roadside emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating Description Lighting Control Module: Anti-Theft Indicator Lamp, PWM Dimming Output, Illumination Lamps for Microphone, RR and LR Door Ashtrays, Heated Seat Switches, Rear Defrost Control Switch, EATC Control Panel, Message Center Switches, Speed Control Switches, Cigar Lighter, Console and Ashtray Data Link Connector (DLC), Powertrain...
Page 139 Fuse/Relay Fuse Amp Location Rating — — —— — Roadside emergencies Description Lighting Control Module Lighting Control Module (LCM): RF Turn Lamp, Right Turn Indicator (VIC), RR Side Marker Lamps, Tail Lamps, License Lamps, LR Stop/Turn Lamps, Clock Illumination Cigar Lighter ABS Evac and Fill Connector Moonroof Switch Not Used...
Page 140 Roadside emergencies Fuse/Relay Fuse Amp Location Rating — — — Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
Page 141 Always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs. The high-current fuses are coded as follows: Fuse/Relay Location — Roadside emergencies USED Fuse Amp Rating Generator/Voltage Regulator 30A** Driver’s Seat Module 30A** Passenger’s Seat Module 40A** Ignition Switch...
Page 142 Roadside emergencies Fuse/Relay Location * Mini Fuses ** Maxi Fuses Auxiliary relay box The auxiliary relay box is located in the engine compartment. The auxiliary relay box contains the high and low speed cooling fan relays. CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed.
Page 143 Roadside emergencies 3. Remove the spare tire, jack and lug wrench. 4. Locate pry off notch (if equipped) and remove the center ornament from the aluminum wheel with the tapered end of the wheel nut wrench that came with your vehicle.
Page 144 Roadside emergencies On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle. Refer to Air suspension system in the Driving chapter for more information. 6. Put the jack in the jack notch next to the door closest to the tire you are changing.
Page 145 (not the dealer) to get a replacement key. If the lug wrench/lug nut key assembly is lost, see your nearest Ford or Lincoln/Mercury dealer who has access to the master set of keys. Do not use an impact wrench with the anti-theft key.
Page 146 Roadside emergencies JUMP STARTING YOUR VEHICLE The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Do not push start your vehicle. You could damage the catalytic converter.
Page 147 Roadside emergencies Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 148 Roadside emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor.
Page 149 Roadside emergencies Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2. Start the engine of the disabled vehicle. 3. Once the disabled vehicle has been started, run both engines for a further three minutes before disconnecting the jumper cables.
Page 150 Roadside emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 151 Roadside emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment.
Page 152: Maintenance And Care
Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a Scheduled Maintenance Guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide necessary parts and service.
Page 153 Do not start your engine with the air cleaner removed and do not remove it while the engine is running. OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel. 2.
Page 154 Maintenance and care 1. Automatic transmission fluid dipstick 2. Brake fluid reservoir 3. Battery 4. Air filter assembly 5. Engine oil dipstick 6. Engine oil filler cap 7. Power steering fluid reservoir 8. Windshield washer fluid reservoir 9. Engine coolant reservoir 10.
Page 155 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable. DO NOT ADD OIL. • If the oil level is below the MIN mark, add enough oil to raise the level within the MIN-MAX range.
Page 156 Maintenance and care Engine oil and filter recommendations Look for this certification mark. Ford oil specification is WSS-M2C153-G. Use SAE 5W-30 motor oil certified for gasoline engines by the American Petroleum Institute. Do not use supplemental engine oil additives, oil treatments or engine treatments.
Page 157 BRAKE FLUID Checking and adding brake fluid Brake fluid should be checked and refilled as needed. Refer to the Scheduled Maintenance Guide for the service interval schedules: 1. Clean the reservoir cap before removal to prevent dirt or water from entering the reservoir. 2.
Page 158 Maintenance and care WINDSHIELD WASHER FLUID Checking and adding washer fluid Check the washer fluid whenever you stop for fuel. The reservoir is highlighted with a If the level is low, add enough fluid to fill the reservoir. In very cold weather, do not fill the reservoir all the way.
Page 159 If the engine coolant has not been checked at the recommended interval, the engine coolant reservoir may become empty. If this occurs, a LOW ENGINE COOLANT warning will illuminate in the message center and you will need to add engine coolant to the coolant reservoir. For more information on engine coolant maintenance, refer to Adding engine coolant in this chapter.
Page 160 The use of an improper coolant may void your warranty of your vehicle’s engine cooling system. Recycled engine coolant Ford Motor Company recommends that Ford and Lincoln-Mercury dealers use recycled engine coolant produced by Ford-approved processes. For vehicles with green coolant, not all coolant recycling processes produce coolant which meets Ford specification ESE-M97B44–A, and use...
Page 161 Maintenance and care Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in the Capacities and specifications chapter. Have your dealer check the engine cooling system for leaks if you have to add more than 1.0 liter (1.0 quart) of engine coolant per month.
Page 162 Maintenance and care 4. Check the fluid level in the reservoir. It should be between the MIN and MAX lines. Do not add fluid if the level is in this range. 5. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the range between the MIN and MAX lines.
Page 163 7. Remove the dipstick and inspect the fluid level. The fluid should be in the designated areas for normal and room temperature. Low fluid level Do not drive the vehicle if the fluid level is at the bottom of the dipstick and the outside temperatures are above 10°C (50°F).
Page 164 Maintenance and care An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level.
Page 165 Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 166 Maintenance and care If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected. • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal.
Page 167 Maintenance and care 2. Release and open the hood. HOOD 3. Pull the rubber cowl seal (number 1 in figure) away from the cowl vent screen. Remove the right half of the cowl vent screen (number 2 in figure) by placing your hand underneath the cowl vent screen and lifting straight up to release the four spring clips.
Page 168 Maintenance and care Be careful when installing the new filter. Avoid bending or tearing the filter and make sure it is fully seated in its mounting location after installation. WINDSHIELD WIPER BLADES Check the wiper blades at least twice a year or when they seem less effective.
Page 169 If the warning remains on after you have adjusted the tires to the recommended air pressure levels, take your vehicle to an authorized Lincoln/Mercury dealer for service.
Page 170 Maintenance and care Flat tire warning If the sensors detect a tire pressure lower than 68 kPa (10 psi), the LOW TIRE PRESSURE warning will appear in the overhead console and the message WARNING LOW TIRE PRESSURE will be displayed in the message center, indicating an impending flat tire.
Page 171 Tire Quality Grades apply to new pneumatic tires for use on passenger cars. They do not apply to deep tread, winter-type snow tires, space-saver or temporary use spare tires, tires with nominal rim diameters of 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2).
Page 172 Maintenance and care Temperature A B C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 173 • Four tire rotation Replacing the tires Replace the tires when the wear band is visible through the tire treads. Failure to follow these precautions may adversely affect the handling of the vehicle and make it easier for the driver to lose control and roll over.
Page 174 Maintenance and care SNOW TIRES AND CHAINS Driving too fast for conditions creates the possibility of loss of vehicle control. Driving at very high speeds for extended periods of time may result in damage to vehicle components. Snow tires must be the same size and grade as the tires you currently have on your vehicle.
Page 175 Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 176 Maintenance and care Fuel Filler Cap Your fuel tank filler cap has an indexed design with a one-eighth turn on/off feature. When fueling your vehicle: 1. Turn the engine off. 2. Carefully turn the filler cap counterclockwise 1/8 of a turn until it stops.
Page 177 If the problems persist, see your dealer or a qualified service technician. The American Automobile Manufacturers Association (AAMA) issued a fuel specification to provide information on high quality fuels that optimize the performance of your vehicle. We recommend the use of fuels that meet the AAMA specification if they are available.
Page 178 Maintenance and care Cleaner air Ford approves the use of gasolines to improve air quality, including reformulated gasolines that contain oxygenates up to 10% ethanol or 15% MTBE. Running out of fuel Avoid running out fuel because this situation may have an adverse affect on modern powertrain components.
Page 179 The advertised fuel capacity of the fuel tank on your vehicle is equal to the rated refill capacity of the fuel tank as listed in the Refill Capacities chart in this “Owner Guide.” The advertised capacity is the amount of the Indicated Capacity and the Empty Reserve combined.
Page 180 Maintenance and care Keep a record for at least one month and record the type of driving (city or highway). This will provide an accurate estimate of the vehicle’s fuel economy. Additionally, keeping records during summer and winter will show how temperature impacts fuel economy. In general, lower temperatures give lower fuel economy.
Page 181 • Operating a vehicle with the wheels out of alignment will reduce fuel economy. • Use recommended engine oil. Refer to Lubricant Specifications. • Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in your vehicle Scheduled Maintenance Guide. Conditions •...
Page 182 Maintenance and care EMISSION CONTROL SYSTEM Your vehicle is equipped with various emission control components and a catalytic converter which will enable your vehicle to comply with applicable exhaust emission standards. To make sure that the catalytic converter and other emission control components continue to work properly: •...
Page 183 Maintenance and care Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, items, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 184 Maintenance and care • Backup lamps • License plate lamp Do not remove lamp bulbs unless they will be replaced immediately. If a bulb is removed for an extended period of time, contaminants may enter the lamp housings and affect performance. Replacing headlamp bulbs Handle a halogen headlamp bulb carefully and keep out of children’s reach.
Page 185 Maintenance and care 5. Release clip and disconnect the electrical connector from the bulb. 6. Remove the bulb retaining ring by rotating it counterclockwise. 7. Remove the old bulb from the lamp assembly by pulling it straight out of the lamp assembly. To install the new bulb: 1.
Page 186 Maintenance and care 5. Carefully position the headlamp assembly onto the vehicle making sure the alignment pins are inserted into the proper holes. 6. Hold the headlamp assembly snugly against the vehicle and push down on the retainer pins to lock the lamp into place. 7.
Page 187 High-mount brakelamp bulbs For bulb replacement, see a dealer or qualified technician. Replacing tail lamp/backup bulbs For bulb replacement, see a dealer or qualified technician. Replacing license plate lamp bulbs For bulb replacement, see a dealer or qualified technician. Replacing the interior bulbs Check the operation of the following interior bulbs frequently: •...
Page 188 Maintenance and care Function Illuminated visor mirror Overhead console reading lamp (without moon roof) Passenger assist handle (rear seat) To replace all instrument panel lights - see your dealer. AIMING THE HEADLAMPS Your vehicle is equipped with a Vehicle Headlamp Aim Device (VHAD) on each headlamp.
Page 189 Maintenance and care 3. Use a 4 mm wrench or socket to turn the horizontal adjusting screw until the “0” mark on the yellow dial lines up with the reference mark on the marker (as shown) when viewed directly from above. Turning the horizontal adjusting screw in the direction of the arrow changes the horizontal aim as...
Page 190 Maintenance and care 3. The “U” and “D” on the bubble indicate the directional change (up or down) of the vertical aim. 4. Use a 4 mm wrench or socket to turn the vertical adjusting screw until the bubble is centered between the two red lines which represents the “0”...
Page 191 Waxing your vehicle Wax when water stops beading on the surface. This could be every three or four months, depending on operating conditions. Use only carnauba or synthetic-based waxes. Use cleaning fluid or alcohol with a clean cloth to remove any bugs and tar before waxing vehicle.
Page 192 Maintenance and care • Cover the highlighted areas to prevent water damage when cleaning the engine. • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. Cleaning plastic exterior parts Use vinyl cleaner for routine cleaning.
Page 193 treatments used by commercial car washes. Clean the outside of the windshield with a non-abrasive cleanser such as the non-abrasive Bon-Ami powder. Rinse thoroughly with clean water. Do not use abrasive cleansers on glass as they may cause scratches. The windshield is clean if beads do not form when you rinse it with water.
Page 194 Maintenance and care Cleaning leather seats (if equipped) To clean, simply use a soft cloth dampened with water and a mild soap. Wipe the leather again with a damp cloth to remove soap residue. Dry with a soft cloth. For tougher soiling concerns, Ford recommends using the leather cleaning kit F8AJ-19G253–AA, which is available from your Ford Dealer.
Page 195: Capacities And Specifications
MOTORCRAFT PART NUMBERS Component Air filter Cabin air filter Fuel filter Battery Oil filter PCV valve Spark plugs* * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. REFILL CAPACITIES Fluid Ford Part Name Engine oil Motorcraft 5W30 (includes filter Super Premium...
Page 196 Capacities and specifications Use only brake fluids certified to meet Ford specifications. Refer toAdding engine coolant, in the Maintenance and Care chapter. DOT 3 fluid is recommended. However, if DOT 3 is not available, DOT 4 fluid can be used. LUBRICANT SPECIFICATIONS Ford Part Item...
Page 197 Ford Part Item Name or equivalent Power steering Motorcraft fluid MERCON ATF Windshield Ultra-Clear washer fluid Windshield Washer Concentrate Use only brake fluids certified to meet Ford specifications. Refer to Lubricant specifications. DOT 3 fluid is recommended. However, if DOT 3 is not available, DOT 4 fluid meeting Ford specification SAE J 1704 DOT 4 can be used.
Page 198 Capacities and specifications...
Page 199 IDENTIFYING YOUR VEHICLE Safety compliance label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the front door latch pillar on the driver’s side.
Page 200 Capacities and specifications Vehicle identification number The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. For your protection, you will also find the vehicle identification number in the following areas (if applicable): •...
Page 201: Reporting Safety Defects
Reporting safety defects REPORTING SAFETY DEFECTS (U.S. ONLY) If you believe that your vehicle has a defect that could cause a crash, or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company.
Page 202: Index
Index Accessory delay ...75 Air bag supplemental restraint system ...101 and child safety seats ...102 description ...101,105 disposal ...107 indicator light ...105,107 passenger air bag ...103,106 Air conditioning automatic temperature control system ...26,27,28,30 Air filter, cabin ...166 Air suspension warning light ...124 Anti-theft system ...79,122 arming the system ...79 disarming a triggered system ..80...
Page 203 Fuses ...136,137 Gas mileage (see Fuel economy) ...178,179,180,181 Gauges ...10 engine coolant temperature gauge ...11 Hazard flashers ...135 Head restraints ...92 Headlamps aiming ...188,189 bulb specifications ...187 high beam ...8,24 turning on and off ...8 warning chime ...10 Heating ...26 Hood ...153 Ignition ...197 Inspection/maintenance (I/M)
Page 204 Index replacement/additional transmitters ...84 replacing the batteries ...83 Safety belts (see Safety restraints) ...9 Safety restraints cleaning the safety belts ...100,193 extension assembly ...99 for children ...108,109 lap belt ...98 warning light and chime ...9,100 Seat belts (see Safety restraints) ...95,96,97,98 Seats ...92 child safety seats ...110 cleaning ...193,194...
Page 208: Filling Station Information
Filling station information Item Recommended fuel Fuel tank capacity Engine oil capacity (includes filter change) Automatic transaxle fluid capacity Tire size and pressure Hood release Coolant capacity Power steering fluid capacity Ensure correct automatic transmission fluid is used for a specific application.

This manual is also suitable for:

Continental 1999

Lincoln 1999 Continental Owner's Manual

Quick Links

Related Manuals for Lincoln 1999 Continental

Summary of Contents for Lincoln 1999 Continental

This manual is also suitable for:

Table of Contents
