Before driving Introduction Instrumentation Controls and features Seating and safety restraints Starting and driving Starting Driving Roadside emergencies Servicing Maintenance and care Capacities and specifications Reporting safety defects Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.
Page 2: Introduction
Introduction ICONS Indicates a warning. Read the following section on Warnings for a full explanation. Indicates vehicle information related to recycling and other environmental concerns will follow. Correct vehicle usage and the authorized disposal of waste cleaning and lubrication materials are significant steps towards protecting the environment.
Page 3: Instrumentation
Instrumentation...
Page 4: Headlamp Control
Instrumentation Headlamp control (pg. 26) Turn signal and wiper/washer control (pg. 35) LIGHTS AUTO LAMP Instrument panel Auto lamp dimmer switch (pg. 27) (pg. 27) Instrument cluster (pg. 6) — TURN ON HEAD LAMPS FILL ON RIGHT SERVICE ENGINE SOON BRAKE Speed control (pg.
Page 5: Heated Seat
Electronic sound system control (pg. 35) 000000.0 Heated seat control* Climate controls* (pg. 73) (pg. 36) Message Center (pg. 12) SYSTEM DRIVER ID SELECT MENU VEHICLE HANDLING DISPLAY TRIP RESET DTE ECON PUSH ON TAPE SEEK TUNE MUTE SIDE 1 2 AUTO BACK BACK...
Page 6 Instrumentation WARNING LIGHTS AND CHIMES TURN ON HEAD LAMPS FILL ON RIGHT SERVICE ENGINE SOON BRAKE Service engine soon Your vehicle is equipped with a computer that monitors the engine’s emission control system. This system is commonly known as the On Board Diagnostics System (OBD II).
Page 7 These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel and/or properly installing and securely tightening the gas cap. After three driving cycles without these or any other temporary malfunctions present, the Service Engine Soon light should turn off.
Page 8 Instrumentation Anti-lock brake system (ABS) Momentarily illuminates when the ignition is turned to the ON position and the engine is off. If the light remains on, continues to flash or fails to illuminate, have the system serviced immediately. Turn signal Illuminates when the left or right turn signal or the hazard lights are turned on.
Page 9 Engine oil pressure Illuminates when the oil pressure falls below the normal range. Stop the vehicle as soon as safely possible and switch off the engine immediately. Check the oil level and add oil if needed. Refer to Engine oil in the Maintenance and Care chapter.
Page 10 Instrumentation GAUGES TURN ON HEAD LAMPS FILL ON RIGHT SERVICE ENGINE SOON BRAKE Fuel gauge Displays approximately how much fuel is in the fuel tank (when the key is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion.
Page 11 Tachometer Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer in the red zone may damage the engine. Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H”...
Page 12 Instrumentation ELECTRONIC MESSAGE CENTER The electronic message center only works when the ignition is in the ON position. The message center tells you about the condition of your vehicle by two methods: operator selectable features continuous warning reporting of monitored systems You can select different features for the message center to display by using the message center controls...
Page 13 System check Pressing this control causes the message center to cycle through a status of each of the systems being monitored. For each of the monitored systems, the message center will indicate either an OK message or a warning message for three seconds. The sequence of the system check report is as follows: voltage level engine temperature...
Page 14 Instrumentation Door Ajar Driver’s Door Ajar Check Engine Temp Transmission Overheat Check Transmission Low Oil Level Check Charging System Low Fuel Level Low Engine Coolant Low Tire Pressure (if equipped) Gear Display Data ERR Brake Lamp Out Check Traction Control Check Ride Control Trunk Ajar Check Steering Assist...
Page 15 DTE/ECON Press the DTE/ECON control once to display the approximately how far you can drive before running out of fuel, or the distance to empty (DTE). To ensure accuracy, turn the ignition OFF when you fill the tank. Press the DTE/ECON control a second time to display the average fuel economy in liters/100 kilometers or miles/gallon, based on distance traveled and rate of fuel used information.
Page 16 Instrumentation RESET Press this control to reset: warnings average fuel economy trip odometers The other selectable features are unaffected by pressing RESET. DISPLAY Press this control to turn the message center display off. Press it again to turn the display on. Warnings override an off display and must be reset for the display to be off again.
Page 17 Traction control Refer to Traction Control Express window Standard vehicle setting is saved as vehicle setting only (not the Driver 1 or 2 individualized profiles). Standard vehicle with Memory Profile System: setting may be saved to either Driver 1 or 2 personalized profiles or as a vehicle setting. Settings: ON or OFF.
Page 18 Instrumentation Standard vehicle with Memory Profile System: setting may be saved to either the Driver 1 or 2 personalized profiles or as a vehicle setting. Settings: ON or OFF. Original setting: ON. Setting adjustment is made using the message center MENU/SELECT controls.
Page 19 Autolamp on/delay time Standard vehicle with Memory Profile System: setting may be saved to either the Driver 1 or 2 personalized profiles or as a vehicle setting. Instrument panel dim control setting Standard vehicle: setting is saved as vehicle setting only (not the Driver 1 or 2 individualized profiles).
Page 20 Instrumentation settings (not individualized settings). To change a feature setting see Driver profile features in this section. Associated systems Keyless Entry System Programming personalized codes: With a key and/or Key FOB outside of the vehicle: Enter the factory code Press the 1/2 control Enter the five digit personalized code Press: The 1/2 control to save the code as Driver 1.
Page 21 Driver profile features Express window Standard vehicle-setting is saved as vehicle setting only (not the DRIVER MEMORY 1 or 2 individualized profiles). Standard vehicle with Memory Profile System-setting may be saved to either the DRIVER MEMORY 1 or 2 personalized profiles or as a vehicle setting.
Page 22 Instrumentation Easy entry/exit seat access Standard vehicle-setting is saved as vehicle setting only (not the DRIVER MEMORY 1 or 2 individualized profiles). Standard vehicle with Memory Profile System-setting may be saved to either the DRIVER MEMORY 1 or 2 personalized profiles or as a vehicle setting.
Page 23 Standard vehicle with Memory Profile System-setting may be saved to either the DRIVER MEMORY 1 or 2 personalized profiles or as a vehicle setting. Settings-low, normal, high Original setting-normal Setting adjustment made using: Message Center-VEHICLE HANDLING/SELECT controls Autolamp on/delay time Standard vehicle with Memory Profile System-setting may be saved to either the DRIVER MEMORY 1 or 2 personalized profiles or as a vehicle setting.
Page 24 Instrumentation Standard vehicle with Memory Profile System-setting may be saved to either the DRIVER MEMORY 1 or 2 personalized profiles or as a vehicle setting. Settings-horizontal and vertical Original setting-N/A Setting adjustment made using: outside mirror control Basic operation In order for the system to be able to store or recall an individuals seat or mirror position preferences, the Driver Profile System must first recognize who will be driving the vehicle.
Page 25 Memory Profile System (if equipped) The Memory Profile System allows the two primary drivers to select and save individualized preferences for the following eleven vehicle features: Express window Auto door locks Horn chirp Easy entry/exit seat access Reverse mirrors Adjustable ride Adjustable steering Autolamp on/delay time Instrument panel dim control...
Page 26: Controls And Features
Controls and features HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps only. Rotate to the second position to also turn on the headlamps. Daytime running lamps (DRL) (if equipped) Turns the highbeam headlamps on with a reduced output. To activate: the engine must be running the headlamp control is in the OFF or Parking lamps position.
Page 27 INSTRUMENT PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlight and parklamp operation. Push up to brighten. Push down to dim. AUTOLAMP CONTROL The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 28 Controls and features Turning the EATC off Press OFF. The Outside Temperature (EXT) function will continue to operate until the ignition is turned off. AUTO Automatic operation Press AUTO and select the desired temperature. The selected temperature and the word AUTO will appear in the display window. The EATC system will either heat or cool to achieve the selected temperature.
Page 29 Controls and features To control the temperature, select any temperature between 18°C FRONT (65°F) and 29°C (85°F) by pressing the temperature control. REAR For continuous maximum cooling, push the temperature control until 16°C (60°F) is shown in the display window. The EATC will continue maximum cooling (disregarding the displayed temperature) until a warmer temperature is selected by pressing the temperature control.
Page 30 Controls and features steering wheel control up for higher fan speed or down for lower fan speed. The display will show graph to indicate manual fan operation and relative speed. To return to automatic fan operation, press AUTO. Manual override controls The override controls allow you to determine where airflow is directed.
Page 31 provided in this mode. The air will be heated or cooled based on the temperature selection. For added customer comfort, the air distributed through the floor ducts will be slightly warmer than the air sent to the instrument panel registers. -Allows for maximum heating by distributing outside air through the floor ducts.
Page 32 Controls and features changed, then the outside temperature will return to the window along with the override selection. The outside temperature reading is most accurate when the vehicle is moving. Higher readings may be obtained when the vehicle is not moving.
Page 33 The rear defroster control is located on the instrument panel. Press the defroster control to clear the rear window of thin ice and fog. The small LED will illuminate when the defroster is activated. The ignition must be in the ON position to operate the rear window defroster.
Page 34 Controls and features POSITIONS OF THE IGNITION 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 35 TURN SIGNAL CONTROL Push down to activate the left turn signal. Push up to activate the right turn signal. Cornering lamps (if equipped) When the turn signal is used when the headlamps are on, the cornering lamps will light either the right or left side depending on the direction of the turn.
Page 36 Controls and features Speed sensitive volume The recommended level for speed sensitive volume is from level 1 through level 3. Level 0 turns the speed sensitive volume off and Level 7 is the maximum setting for the speed sensitive volume. Climate control features Press TEMP up or down to adjust temperature.
Page 37 To turn speed control off Press OFF or Turn off the vehicle ignition. Once speed control is switched off, the previously programmed set speed will be erased. When the OFF control is pressed, the message “SPEED CONTROL OFF” will appear for 5 seconds in your message center. To set a speed Press SET ACC/SET ACCEL.
Page 38 Controls and features Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved. To set a higher set speed Press and hold SET ACC/SET ACCEL. Release the control when the desired vehicle speed is reached or Press and release SET ACC/SET ACCEL.
Page 39 Depress the brake pedal. When the desired vehicle speed is reached, press SET ACC/SET ACCEL. When the COAST or SET ACCEL control is pressed and released, the message “SPEED CONTROL SET” will appear for 5 seconds in your message center. To disengage speed control Depress the brake pedal.
Page 40 Controls and features TILT STEERING Pull the tilt steering control toward you to move the steering wheel up or down. Hold the control while adjusting the wheel to the desired position, then release the control. Never adjust the steering wheel when the vehicle is moving. INTERIOR LAMPS Map lamps To turn on the map lamps, press the control next to each lamp.
Page 41 It is important that you understand the limitations of your Lincoln RESCU System prior to initiating an activation. See Lincoln RESCU System Limitations later in this chapter for details. The RESCU system can be activated in three ways: Controls and features S.O.S.
Page 42 Controls and features 1. By pressing the Information control. 2. By pressing the Emergency (S.O.S) control. 3. The system will automatically activate if the vehicle’s air bags have been deployed. Quick summary To utilize your vehicle’s RESCU system, your cellular phone must be activated.
Page 43 In most situations, only the response center can terminate an assistance request. General description Lincoln’s Remote Emergency Satellite Cellular Unit (RESCU) is designed to expedite roadside, emergency or information assistance to distressed motorists who are uncertain of their location and/or are uncertain of who to contact for assistance.
Page 44 When this control is pressed, the Lincoln Security Response Center relays details of your situation and your location to the United States Auto Club (USAC) via three-way phone call. The response center/USAC will: dispatch the emergency help to your location.
Page 45 Controls and features Activation and deactivation When either of the two Lincoln RESCU controls are pressed, or the air bags are deployed (this will activate the system as an emergency automatically), a warning light, located in the overhead console, will begin to flash and status messages will be displayed on the vehicle’s...
Page 46 If vehicle messages are being displayed on the message center (low washer fluid, low oil, door ajar, etc.), they must be cleared in order to view the Lincoln RESCU messages. To clear the vehicle messages, press the message center RESET control which is located to the right of the display.
Page 47 Location data retransmit capability During an activation, the Lincoln Security Response Center operator has the capability to initiate a retransmission of the electronic data message. This may be necessary to ensure a more precise determination of vehicle location or to track a vehicle that is moving.
Page 48 Inoperative if battery discharged or disconnected Lincoln RESCU is powered by the vehicle’s battery and will not operate if the battery if discharged or disconnected. Potentially inoperative if vehicle involved in accident If the vehicle is involved in an accident, some components can be damaged, rendering your RESCU System inoperative.
Page 49 (PIN). In this situation, the user is required to enter the PIN with any phone calls made over the network. The Lincoln RESCU System is not compatible with the PIN feature. At the time your phone is activated, ask your carrier to assign you a phone number that does not require an personal identification number.
Page 50 911 or other emergency services. Registration requirement You are required to register with the Lincoln Security Response Center shortly after receiving your vehicle. The registration process is simple and can be accomplished by calling the Lincoln Security Response Center at 1–800–334–1327.
Page 51 (These activations should be made only when emergency or roadside assistance is required.) You will be responsible, however, for any charges imposed by your cellular phone carrier for the 1–800 phone call to the Lincoln...
Page 52 Relinquishing your vehicle At the time you relinquish your vehicle, it is important that you contact the Lincoln Security Response Center at 1–800–223–1327 and cancel your security service. Personal information provided to the response center at the time of your registration will be removed from the vehicle’s file.
Page 53 and gates, and can also control home or office lighting and security systems (with the available accessory package). When programming your HomeLink Universal Transmitter, you will be operating the garage door or gate. Be sure that people and objects are out to the way to prevent potential harm or damage. Do not use the HomeLink Universal Transmitter with any garage door opener that lacks safety stop and reverse features as required by U.S.
Page 54 Controls and features If you do not successfully program the HomeLink Universal Transmitter after repeated attempts, refer to Training a rolling code which follows or call toll-free customer assistance: 1–800–355–3515. Note to Canadian residents During programming, your hand-held transmitter may automatically stop transmitting after two seconds which may not be long enough to program the HomeLink Universal Transmitter.
Page 55 Controls and features 1. Locate the training control on the garage door opener receiver. Refer to the garage door opener manual or call 1–800–355–3515 if there is difficulty locating the training control. 2. Press the training control on the garage door opener receiver until the training light (next to the control) begins to flash (1-2 seconds).
Page 56 Controls and features calibration may be necessary. Refer to Compass calibration adjustment. Most geographic areas (zones) have a magnetic north compass point that varies slightly from the northerly direction on maps. This variation is four degrees between adjacent zones and will become noticeable as the vehicle crosses multiple zones.
Page 57 Controls and features 5. Release the switch, then slowly press it down again. Press the switch repeatedly until the correct zone setting for your geographic location is displayed on the upper right corner of the mirror. 6. To exit the zone setting mode, release pressure from the switch for greater than two seconds.
Page 58 Controls and features Press the control to turn the mirror on or off. The mirror will automatically return to the normal state whenever the vehicle is placed in R (reverse)(when the mirror is on) to ensure a bright clear view when backing up.
Page 59 POWER WINDOWS Press and hold the rocker switches to open and close windows. Press the top portion of the rocker switch to open. Pull the top portion of the rocker switch to close. Express down To make the driver window open fully without holding the window control, press the driver window control completely down and release...
Page 60 Controls and features Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls except for the driver’s press the right side of the control. Press the left side to restore the window controls.
Page 61 3. Return to the center position to lock mirrors in place. Heated outside mirrors Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place.
Page 62 Controls and features CENTER CONSOLE (IF EQUIPPED) Your vehicle is equipped with a variety of console features. These include: utility compartment cupholders ashtray and lighter compact disc changer (if equipped) power point cellular phone (if equipped) Use only soft cups in the cupholder. Hard objects can injure you in a collision.
Page 63 POSITIVE RETENTION FLOOR MAT Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal. To remove the floor mat, reverse the installation procedure.
Page 64 Controls and features If a door is open, the system is prearmed and is waiting for the door to close. The anti-theft indicator on the instrument panel will be lit continuously when the system is prearmed. Once the doors are closed, the system will arm in 30 seconds. Disarming the system You can disarm the system by any of the following actions: Unlock the doors by using your...
Page 65 Controls and features If one or both of your SecuriLock keys are lost or stolen and you want to ensure the lost or stolen key will not operate your vehicle, bring your vehicle and all available SecuriLock keys to your dealership for reinitialization.
Page 66 Controls and features Opening the trunk Press the control once to open the trunk. Be certain the trunk is closed before driving your vehicle. The trunk may appear closed, but it may not be latched. Failure to do so may cause objects to fall out of the trunk or block rear view vision.
Page 67 structures around the vehicle other vehicles parked next to the vehicle To replace the battery: 1. Twist a thin coin between the two halves of the transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE TRANSMITTER APART.
Page 68 Controls and features The inside lights will not turn off if: they have been turned on with the dimmer control or any door is open. The battery saver will shut off the interior lamps 40 minutes after the ignition has been turned to the OFF position. KEYLESS ENTRY SYSTEM With the keyless entry keypad, you can:...
Page 69 3/4 recalls personality 2 9/0 does not recall a personality All of the vehicle doors will lock and unlock to confirm programming of the new code. Each personality driver profile (personality 1 or personality 2) can be associated with only one personal code. The factory-set code cannot be associated with a personality profile.
Page 70 Controls and features After the factory-set code or personal code has been entered, you can unlock all doors (press 3/4) and release the trunk (press 5/6) as long as the controls are pressed within 5 seconds of each other. Locking doors with the keyless entry system It is not necessary to enter the factory-set code prior to locking all doors.
Page 71: Seating And Safety Restraints
SEATING Head restraints Push or pull the head rests to the desired position. Adjusting the power front seats – door mounted controls The controls for the power seats are located on the inside of each front door. Never adjust the driver’s seat or seatback when the vehicle is moving.
Page 72 Seating and safety restraints Press to move the seat forward or backward. Press to move the front portion of the seat cushion up or down. Press to move the rear portion of the seat cushion up or down.
Page 73 Heated seats (if equipped) To operate the heated seats: Slide the control to BACK to heat the seatback only. Slide the control to BOTH to heat the seatback and the seat cushion. Rotate the thumbwheel to select the desired heat (from 0 (OFF) to 5 (HI)).
Page 74 Seating and safety restraints Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision. All occupants of the vehicle, including the driver, should always wear their safety belts.
Page 75 2. To unfasten, push the red release button and remove the tongue from the buckle. The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front and rear seat passenger outboard safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in...
Page 76 Seating and safety restraints How to use the automatic locking mode Buckle the combination lap and shoulder belt. Grasp the shoulder portion and pull downward until the entire belt is extracted. Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
Page 77 Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height control down.
Page 78 Seating and safety restraints Insert the tongue into the correct buckle. To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle. To tighten the belt, pull the loose end of the belt through the tongue until it fits snugly across the hips.
Page 79 Conditions of operation If... The driver’s safety belt is not buckled before the ignition switch is turned to the ON position... The driver’s safety belt is buckled while the indicator light is illuminated and the warning chime is sounding... The driver’s safety belt is buckled before the ignition switch is turned to the ON position...
Page 80 Seating and safety restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) – ANTI ACTIVE THEFT FILL ON RIGHT RPMx1000 SERVICE ENGINE SOON BRAKE LIGHTS AUTO LAMP Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to: work with the safety belt to protect the driver and right front passenger.
Page 81 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer. Children and air bags For additional important safety information, read all information on safety restraints in this guide.
Page 82 Seating and safety restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the air bag.
Page 83 section in the Instrumentation chapter. Routine maintenance of the air bag is not required. A difficulty with the system is indicated by one or more of the following: The readiness light will either flash or stay lit. The readiness light will not illuminate immediately after ignition is turned on.
Page 84 Seating and safety restraints Children and safety belts Children who are too large for child safety seats (as specified by your child safety seat manufacturer) should always wear safety belts. Follow all the important safety restraint and air bag precautions that apply to adult passengers in your vehicle.
Page 85 When installing a child safety seat: Use the correct safety belt buckle for that seating position. Make sure the tongue is securely fastened in the buckle. Keep the buckle release button pointing up and away from the safety seat, with the tongue between the child seat and the release button, to prevent accidental unbuckling.
Page 86 Seating and safety restraints Air bag can kill or injure a child in a child seat. If you must use a forward-facing child seat in the front seat, move seat all the way back. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together.
Page 87 Seating and safety restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 88 Additional kit can be obtained and installed at no charge from any Ford or Lincoln-Mercury dealer. The tether strap anchorage bracket for the rear center seating position was factory installed and is located directly beneath the rear window...
Page 89 Seating and safety restraints trim panel, which is behind the rear seat back. To use this anchorage, do the following: 1. Open the hinged cover located at the front of the high mount stop light. This cover conceals the tether strap anchor bracket.
Page 90: Starting
Starting PREPARING TO START YOUR VEHICLE Engine starting is controlled by the ignition system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
Page 91 2. Make sure the headlamps and vehicle accessories are off. Make sure the parking brake is set. Make sure the gearshift is in P (Park). 3. Turn the key to 4 (ON) without turning the key to 5 (START). Starting HOOD...
Page 92: Starting The Engine
Starting TURN ON HEAD LAMPS FILL ON RIGHT SERVICE ENGINE SOON BRAKE Make sure the corresponding lights illuminate briefly. If a light fails to illuminate, have the vehicle serviced. If the driver’s safety belt is fastened, the light ( STARTING THE ENGINE 1.
Page 93 Using the engine block heater (if equipped) An engine block heater warms the engine coolant, which improves starting, warms up the engine faster and allows the heater-defroster system to respond quickly. Use of an engine block heater is strongly recommended if you live in a region where temperatures reach -23°C (-10°F) or below.
Page 94 Starting Important ventilating information If the engine is idling while the vehicle is stopped in an open area for long periods of time, open the windows at least 2.5 cm (one inch). Adjust the heating or air conditioning (if equipped) to bring in fresh air. Improve vehicle ventilation by keeping all air inlet vents clear of snow, leaves and other debris.
Page 95: Driving
Driving BRAKES Your brakes are self-adjusting. Refer to the “Service Guide” for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 96 Driving light will remain on and your vehicle should be serviced as soon as possible. Normal braking is still effective unless the BRAKE warning lamp is also illuminated. Using ABS In an emergency or when maximum efficiency from the ABS is required, apply continuous full force on the brake.
Page 97 Your vehicle has an automatic parking brake release. To release the parking brake: 1. Turn the ignition to the RUN position. 2. Press the brake pedal. 3. Move the gearshifter from the P (Park) position to one of the forward gears (the parking brake will not release automatically when you shift into reverse).
Page 98 Driving sound coming from the engine compartment and the engine will not “rev-up” when you push further on the accelerator. This is normal system behavior. If you should become stuck in snow or on a very slippery road surface, try switching the Traction Control wheel spin to “dig”...
Page 99 The air suspension shut-off switch is located on the left side of the trunk. If this switch is in the OFF position, the rear air suspension will not operate. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle.
Page 100 Driving on the accelerator in each gear. Do not rock the vehicle for more than a few minutes, because it could damage the vehicle. Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn off the ignition whenever you leave your vehicle.
Page 101 Driving R (Reverse) With the gearshift in R (Reverse), the vehicle will move backward. You should always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift in the N (Neutral) position, the vehicle can be started and is free to roll.
Page 102 Driving D (Overdrive) The overdrive position is the normal driving position for an automatic overdrive transaxle. It works the same way as 3 (Third) but shifts to a fourth gear — an overdrive gear — when your vehicle cruises at a constant speed for any length of time.
Page 103 1 (First) Use 1 (First) for when added engine braking is desired when descending steep hills. The automatic transaxle will shift to the proper gear to ascend any grade without any need to shift to 1 (First). Do not go faster than 61 km/h (38 mph) when in this gear. You can upshift from 1 (First) to overdrive at any time.
Page 104 Driving VEHICLE LOADING Before loading a vehicle, familiarize yourself with the following terms: Base Curb Weight: Weight of the vehicle including any standard equipment, fluids, lubricants, etc. It does not include passengers or aftermarket equipment. Payload: Combined maximum allowable weight of cargo, passengers and optional equipment.
Page 105 38°C [100°F]). Your vehicle does not come from the factory fully equipped to tow. However, you can contact your local Lincoln dealer to get the proper towing equipment. Do not tow a trailer until your vehicle has been driven at least 3 200 km (2 000 miles).
Page 106 Driving Do not exceed the GVWR or the GAWR specified on the Safety Compliance Certification Label. Towing trailers beyond the maximum recommended gross trailer weight could result in engine damage, transmission/axle damage, structural damage, loss of control, and personal injury. Preparing to tow Use the proper equipment for towing a trailer, and make sure it is properly attached to your vehicle.
Page 107 Lincoln dealer. Be sure to follow their instructions carefully. If you do not install trailer lights correctly, you may cause damage to the vehicle’s lighting system or other vehicle systems. Driving while you tow Do not drive faster than 88 km/h (55 mph) when towing a trailer.
Page 108 Driving FUEL CONSUMPTION Fuel economy can be improved by avoiding: lack of regular, scheduled maintenance. excessive speed. rapid acceleration. extended idle. CHECKING YOUR HIGHWAY FUEL ECONOMY USING THE ELECTRONIC MESSAGE CENTER DISPLAY The following procedure will allow you to accurately monitor your actual highway fuel economy.
Page 109: Roadside Emergencies
Roadside emergencies HAZARD FLASHER For information on the hazard flasher control, refer to Hazard lights control in the Roadside emergencies chapter. FUEL PUMP SHUT-OFF SWITCH If the engine cranks but does not start after a collision, the fuel pump shut-off switch may have been activated. The shut-off switch is a device intended to stop the electric fuel pump when your vehicle has been involved in a substantial jolt.
Page 110 Roadside emergencies Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Standard fuse amperage rating and color Fuse rating 5 amp 7.5 amp 10 amp...
Page 111 Roadside emergencies...
Page 112 Roadside emergencies The fuses are coded as follows: Fuse/Relay Location Fuse Amp Rating Description Lighting Control Module: Anti-Theft Indicator Lamp, PWM Dimming Output, Illumination Lamps for Microphone, RR and LR Door Ashtrays, Heated Seat Switches, Rear Defrost Control Switch, EATC Control Panel, Message Center Switches, Speed Control Switches,...
Page 113 Fuse/Relay Location Roadside emergencies Fuse Amp Rating Description Virtual Image Instrument Cluster, Lighting Control Module (LCM RUN/START Sense), Autolamp Light Sensor Virtual Image Instrument Cluster, RF Park/Turn Lamp Power Point Fuel Filler Door Release Switch, Trunk Lid Relay Air Bag Diagnostic Monitor, EATC Module, Blower Motor Relay...
Page 114 Roadside emergencies Fuse/Relay Location Fuse Amp Rating Description Lighting Control Module (LCM): RF Turn Lamp, Right Turn Indicator (VIC), RR Side Marker Lamps, Tail Lamps, License Lamps, LR Stop/Turn Lamps, Clock Illumination Cigar Lighter ABS Evac and Fill Connector Moonroof Switch NOT USED Lighting Control Module...
Page 115 Fuse/Relay Location Roadside emergencies Fuse Amp Rating Description Virtual Image Instrument Cluster, EATC Module NOT USED Shift Lock Actuator, Vehicle Dynamic Module, Virtual Image Instrument Cluster, Rear Window Defrost, Heated Seat Switch Assembly, Low Tire Pressure Module Radio Heated Mirrors Lighting Control Module (LCM): FCU, Electronic Day/Night...
Page 116 Roadside emergencies Fuse/Relay Location Fuse Amp Rating Description Console Shift Illumination, A/C Clutch Cycling Pressure Switch, A/C Clutch Relay (DTR) Sensor, Intake Manifold Runner Control, Backup Lamps NOT USED NOT USED Subwoofer Amplifier, Radio Analog Clock, CD Player, Mobile Telephone Transceiver, RESCU Power Door Locks, Power Seats, Power...
Page 117 Power distribution box The power distribution box is located in the engine compartment near the battery. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
Page 118 Roadside emergencies The high-current fuses are coded as follows: Fuse/Relay Location Fuse Amp Rating 30A** 30A** 40A** 40A** 40A** 30A** 40A** 60A** 60A** 60A** 60A** 40A** 60A** 30A* 20A* 30A* 30A* 10A* 20A* 15A* Description Generator/Voltage Regulator Driver’s Seat Module Passenger’s Seat Module Ignition Switch...
Page 119 Fuse/Relay Location * Mini Fuses ** Maxi Fuses CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road. Tire change procedure 1.
Page 120 Roadside emergencies 5. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. Refer to Anti-theft lug nuts for information on removing anti-theft lug nuts. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your...
Page 121 (not the dealer) to get a replacement key. If the lug wrench/lug nut key assembly is lost, see your nearest Ford or Lincoln/Mercury dealer who has access to the master set of keys. Do not use an impact wrench with the anti-theft key.
Page 122 Roadside emergencies JUMP STARTING YOUR VEHICLE The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Do not push start your vehicle. You could damage the catalytic converter.
Page 123 Connecting the jumper cables 1. Position the vehicles so that they do not touch one another. 2. Switch off the engine. Switch off any unnecessary electrical equipment. 3. Connect the positive (+) terminal of the discharged battery (1) to the positive (+) terminal of the booster battery (2).
Page 124 Roadside emergencies Removing the jumper cables 1. Remove the jumper cables in reverse order. Take the cable off the alternator mounting brace stud (1) first, followed by the cable on the negative (-) booster battery terminal (2). 2. Remove the cable from the positive (+) terminal of the booster battery (3) and then the discharged battery (4).
Page 125 Roadside emergencies If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. When calling for a tow truck, tell the operator what kind of vehicle you have.
Page 126: Maintenance And Care
Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: We highlight do-it-yourself items in the engine compartment for easy location. We provide a “Service Guide” which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide necessary parts and service.
Page 127 Do not start your engine with the air cleaner removed and do not remove it while the engine is running. OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel. 2.
Page 128 Maintenance and care 3. Engine coolant reservoir 4. Passenger compartment air filter assembly 5. Transaxle fluid dipstick 6. Brake fluid reservoir 7. Battery 8. Air filter assembly 9. Engine oil dipstick 10. Engine oil fill cap ENGINE OIL Checking the engine oil Check the engine oil each time you fuel your vehicle.
Page 129 If the oil level is between the MIN and MAX marks, the oil level is acceptable. DO NOT ADD OIL. If the oil level is below the MIN mark, add enough oil to raise the level within the MIN-MAX range. Oil levels above the MAX mark may cause engine damage.
Page 130 Maintenance and care Use SAE 5W-30 motor oil certified for gasoline engines by the American Petroleum Institute. Do not use supplemental engine oil additives, oil treatments or engine treatments. They are unnecessary and could, under certain conditions, lead to engine damage which is not covered by your warranty. Changing the engine oil and filter Change your engine oil and filter according to the appropriate schedule listed in the “Service Guide”.
Page 131 Brake fluid is toxic. If you use a brake fluid that is not DOT 3, you will cause permanent damage to your brakes. Do not let the reservoir for the master cylinder run dry. This may cause the brakes to fail. WINDSHIELD WASHER FLUID Checking and adding washer fluid Check the washer fluid whenever...
Page 132 Maintenance and care If the engine coolant has not been checked for a long period of time, the engine coolant reservoir may eventually empty. If this occurs, a LOW ENGINE COOLANT warning illuminate in the message center and you will need to add engine coolant to the coolant reservoir. For more information on engine coolant maintenance, refer to Adding engine coolant in this chapter.
Page 133 The use of an improper coolant may void your warranty of your vehicle’s engine cooling system. Recycled engine coolant Ford Motor Company recommends that Ford and Lincoln-Mercury dealers use recycled engine coolant produced by Ford-approved processes. Not all coolant recycling processes produce coolant which meets Ford specification ESE-M97B44–A, and use of such coolant may...
Page 134 Maintenance and care coolant concentration above 60%. Leave a 50/50 mixture of engine coolant and water in your vehicle year-round in non-extreme climates. CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid at least twice a year. If adding fluid is necessary, use only MERCON ATF power steering fluid.
Page 135 Maintenance and care Before adding any fluid, make sure the correct type is used . The type of fluid used is normally indicated on the dipstick and/or dipstick handle and also in the Lubricant specifications section in the Capacities and specifications chapter. Do not drive the vehicle if the fluid level is below the hole at the bottom of the dipstick and outside temperatures are above 10°C (50°F).
Page 136 Maintenance and care 8. If an overfill occurs, excess fluid should be removed by a qualified technician. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. If the fluid level is above the crosshatch (hot operating range) area after driving the vehicle for approximately 30 km (20 miles), excess transmission fluid should be removed by a qualified technician.
Page 137 If your battery has a cover/shield, make sure it is reinstalled after the battery is replaced. Because your vehicle’s engine is electronically controlled by a computer, some control conditions are maintained by power from the battery. When the battery is disconnected or a new battery is installed, the engine must relearn its idle conditions before your vehicle will drive properly.
Page 138 Maintenance and care CABIN AIR FILTER The cabin air filter restricts the entry of airborne dust and pollen particles. The filter is located just in front of the windshield under the cowl vent screen on the passenger side of the vehicle. To replace the filter, perform the following procedure: 1.
Page 139 Maintenance and care 3. Pull the rubber cowl seal (number 1 in figure) away from the cowl vent screen. Remove the right half of the cowl vent screen (number 2 in figure) by placing your hand underneath the cowl vent screen and lifting straight up to release the four spring clips.
Page 140 Maintenance and care Checking the wiper blades If the wiper blades do not wipe properly, clean both the windshield and wiper blades using undiluted windshield wiper solution or a mild detergent. Rinse thoroughly with clean water. To avoid damaging the blades, do not use fuel, kerosene, paint thinner or other solvents.
Page 141 If the warning remains on after you have adjusted the tires to the recommended air pressure levels, take your vehicle to an authorized Lincoln/Mercury dealer for service. Flat tire warning If the sensors detect a tire pressure lower than 68 kPa (10 psi), the LOW...
Page 142 Maintenance and care your SecuriTire requires service as soon as possible. Refer to Servicing your SecuriTires. The Pressure Alert System will activate only when the vehicle is moving faster than 15 km/h (10 mph). Servicing your SecuriTires If you cannot service your SecuriTire immediately, replace it with your temporary spare as soon as safely possible.
Page 143 Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire grade 150 would wear one and one-half (1 1/2) times as well on the government course as a tire grade 100.
Page 144 Maintenance and care SERVICING YOUR TIRES Checking the tire pressure Use an accurate tire pressure gauge. Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles).
Page 145 Replacing the tires Replace the tires when the wear band is visible through the tire treads. Failure to follow these precautions may adversely affect the handling of the vehicle and make it easier to lose control and roll over. Tires that are larger or smaller than your vehicle’s original tires may also affect the accuracy of your speedometer.
Page 146 Maintenance and care WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. If you do not use the proper fuel cap, the pressure in the fuel tank can damage the fuel system or cause it to work improperly in a collision.
Page 147 Be particularly careful if you are taking “Antabuse” or other forms of disulfiram for the treatment of alcoholism. Breathing gasoline vapors or skin contact could cause an adverse reaction. Consult a physician immediately. Choosing the right fuel Use only UNLEADED FUEL. The use of leaded fuel is prohibited by law and could damage your vehicle.
Page 148 Maintenance and care The American Automobile Manufacturers Association (AAMA) issued a gasoline specification to provide information on high quality fuels that optimize the performance of your vehicle. We recommend the use of gasolines that meet the AAMA specification if they are available.
Page 149 EMISSION CONTROL SYSTEM Your vehicle is equipped with various emission control components and a catalytic converter which will enable your vehicle to comply with applicable exhaust emission standards. To make sure that the catalytic converter and other emission control components continue to work properly: Use only unleaded fuel.
Page 150 Maintenance and care the Vehicle Emission Control Information Decal located on or near the engine. This decal identifies engine displacement and gives some tune up specifications. Please consult your “Warranty Guide” for complete emission warranty information. Readiness for inspection/maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostic (OBD-II) system.
Page 151 Maintenance and care 3. At the back of the headlamp, pull back and up slightly on the two right angle brackets to release the headlamp assembly from the vehicle. 4. Carefully pull the headlamp assembly away from the vehicle to expose the back of the bulb and wiring connector.
Page 152 Maintenance and care 5. Turn the headlamps on and make sure they work properly. If the headlamp was correctly aligned before you changed the bulb, you should not need to align it again. AIMING THE HEADLAMPS Your vehicle is equipped with a Vehicle Headlamp Aim Device (VHAD) on each headlamp.
Page 153 2. Use a 4mm wrench or socket to turn the horizontal adjusting screw until the “0” mark on the yellow dial lines up with the reference mark on the marker (as shown) when viewed directly from above. Turning the horizontal adjusting screw in the direction of the arrow changes the horizontal aim as shown.
Page 154 Maintenance and care 3. The “U” and “D” on the bubble indicate the directional change (up or down) of the vertical aim. 4. Use a 4 mm wrench or socket to turn the vertical adjusting screw until the bubble is centered between the two red lines which represents the “0”...
Page 155 Function Door mounted lamp (front) Illuminated visor mirror Overhead console reading lamp (without moon roof) Passenger assist handle (rear seat) To replace all instrument panel lights - see your dealer. CLEANING AND CARING FOR YOUR VEHICLE Refer to the “Customer Assistance Guide” for a list of Ford-approved cleaners, polishes and waxes.
Page 156 Maintenance and care Repairing paint chips Minor scratches or paint damage from road debris may be repaired with touch-up paint, repair foil or aerosol paint spray from the Ford accessory line. Observe the application instructions on the products. Remove particles such as bird droppings, tree sap, insect remains, tar spots, road salt and industrial fallout immediately.
Page 157 Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. Cleaning plastic exterior parts Use vinyl cleaner for routine cleaning. Clean with a tar remover if necessary. Do not clean plastic parts with thinners, solvents or petroleum-based cleaners.
Page 158 Maintenance and care Cleaning leather seats For routine cleaning, wipe the surface with a soft, damp cloth. For more thorough cleaning, wipe the surface with a leather and vinyl cleaner or a mild soap. The type of scrubbing pad is very critical because the common 3M “Scotch Brite”...
Page 159 Maintenance and care Inside windows Use glass cleaner for the inside windows if they become fogged. Cleaning mirrors Do not clean your mirrors with a dry cloth or abrasive materials. Use a soft cloth and mild detergent and water. Be careful when removing ice from outside mirrors because you may damage the reflective surface.
Page 160: Capacities And Specifications
Capacities and specifications MOTORCRAFT PART NUMBERS Component Air filter Cabin air filter Fuel filter Battery Oil filter Spark plugs* * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information. **If a spark plug needs to be replaced, use only spark plugs with the same service part number suffix letter “EE”...
Page 161 Fluid Ford Part Name Fuel tank Automatic Motorcraft transaxle MERCON V Windshield Ultra-Clear washer fluid Windshield Washer Concentrate LUBRICANT SPECIFICATIONS Ford Part Item Name or equivalent Brake fluid High Performance DOT 3 Motor Vehicle Brake Fluid Door latch, hood Multi-Purpose latch, auxiliary Grease latch, seat...
Page 162 Capacities and specifications Ford Part Item Name or equivalent Engine oil Motorcraft 5W30 Super Premium Motor Oil Constant CV Joint Grease velocity joints (High Temp.) Engine coolant Ford Premium Cooling System Fluid Power steering Motorcraft fluid MERCON ATF Windshield Ultra-Clear washer fluid Windshield Washer...
Page 163 VEHICLE DIMENSIONS Vehicle dimensions (1) Overall length (2) Overall width (3) Overall height (4) Wheelbase (5) Track - Front (5) Track - Rear Capacities and specifications mm (in) 5 294.7 (208.4) 1 870.3 (76.3) 1 421.9 (55.9) 2 769.8 (109.0) 1 600.2 (63.0) 1 562.1 (61.5)
Page 164 Capacities and specifications IDENTIFYING YOUR VEHICLE Safety compliance label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the front door latch pillar on the driver’s side.
Page 165 Capacities and specifications Vehicle identification number The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. ENGINE NUMBER The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and transfer case (if so equipped).
Page 166: Reporting Safety Defects
Reporting safety defects REPORTING SAFETY DEFECTS (U.S. ONLY) If you believe that your vehicle has a defect that could cause a crash, or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company.
Page 167: Index
Air bag supplemental restraint system ...80 and child safety seats ...81 description ...80 disposal ...83 indicator light ...82 passenger air bag ...81 Air suspension description ...98 Anti-lock brake system (ABS)#$description Anti-theft system ...63 Battery ...136 Brakes ...95 anti-lock ...95 anti-lock brake system (ABS) warning light ...95 fluid, checking and adding ...130 traction control ...97...
Page 168 Index high beam ...26 Heating ...27 High beams indicator light ...8 Hood release lever ...127 Ignition positions of the ignition ...34 Jump-starting your vehicle ...122, attaching cables ...123 disconnecting cables ...124 Keyless entry system autolock ...70 keypad ...68 programming entry code ...68, Keys key in ignition chime ...9 Lamps...
Page 169 Speed control ...36 canceling a set speed ...39 resuming a set speed ...39 tap up/tap down ...38 turning off ...37 Speedometer ...10 Starting your vehicle ...90,92 Sunvisor ...52 Tachometer mechanical cluster ...11 Tilt steering wheel ...40 Tires ...142,144 changing ...119 checking the pressure ...144 replacing ...145 rotating ...144...
Page 176: Filling Station Information
Filling station information Recommended fuel Fuel tank capacity Engine oil capacity (with filter change) Automatic transaxle fluid capacity Tire size and pressure Hood release Coolant capacity Power steering fluid capacity Ensure correct automatic transmission fluid is used for a specific application.

This manual is also suitable for:

Continental 1998

Lincoln 1998 Continental Owner's Manual

Quick Links

Related Manuals for Lincoln 1998 Continental

Summary of Contents for Lincoln 1998 Continental

This manual is also suitable for:

Table of Contents
