Lincoln Town Car 2004 Owner's Manual

page of 305

/ 305
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Introduction

Instrument Cluster

Warning and control lights

Gauges

Entertainment Systems

AM/FM stereo cassette with CD

Cd Changer

Navigation System

Climate Controls

Dual automatic temperature control

Rear Window Defroster

Lights

Headlamps

Turn Signal Control

Bulb replacement

Driver Controls

Windshield Wiper/washer control

Steering wheel adjustment

Message center

Locks

Anti-theft system

REVIEW COPY

2004 Town Car (tow), Owners Guide (post-2002-fmt) (own2002),

Market: USA_English (fus)

Table of Contents

101

102

114

115

117

122

130

141

Table of Contents

Summary of Contents for Lincoln Town Car 2004

Page 1 Table of Contents Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo cassette with CD CD changer Navigation system Climate Controls Dual automatic temperature control Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment...
Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Air bags Child restraints Driving Starting Brakes Traction control Air suspension Transmission operation Vehicle loading Trailer towing Recreational towing Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Lug Nut Torque...
Page 3 Table of Contents Maintenance and Specifications Engine compartment Engine oil Battery Fuel information Air filter(s) Tire Information Refill capacities Lubricant specifications Accessories Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Page 6 Introduction SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 6.0L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.
Page 7 Introduction Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls. Please read the section Supplemental restraint system (SRS) in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury. Front seat mounted rear-facing child or infant seats should NEVER be placed in front of an active passenger air bag.
Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor Brake Fluid -...
Page 9 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 10: Instrument Cluster
Instrument Cluster Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 11 Instrument Cluster Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Service engine soon warning light to come on. Refer to Fuel filler cap in the Maintenance and Specifications chapter.
Page 12 Instrument Cluster Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt, refer to the Seating and Safety Restraints chapter. Charging system: Illuminates when the battery is not charging properly. Engine oil pressure: Illuminates when the oil pressure falls below the normal range, refer to Engine oil in...
Page 13 Instrument Cluster Air suspension: Illuminates when the air suspension is turned OFF or the air suspension system requires servicing. Washer: Illuminates when the windshield washer fluid is low. Speed control: Illuminates when the speed control is activated. Turns off when the speed control system is deactivated.
Page 14 Instrument Cluster Trunk ajar: Illuminates when the trunk is not completely closed. This light will flash and sound a tone for one second, then the light remains Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb.
Page 15: Gauges
Instrument Cluster GAUGES Speedometer: Indicates the current vehicle speed. Select SPEED from the message center to display the digital speedometer on the left hand side of the cluster. Refer to the Message Center in the Driver Controls chapter for more information on the Trip A and B feature.
Page 16 Instrument Cluster Never remove the coolant reservoir cap while the engine is running or hot. Odometer: Registers the total miles (kilometers) of the vehicle. Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position).
Page 17: Entertainment Systems
Entertainment Systems Entertainment Systems AUDIOPHILE AM/FM STEREO/CASSETTE/SINGLE CD MUTE AM/FM TAPE BASS TREB TUNE SCAN FADE AUTO SIDE COMP SHUF SEEK PREMIUM AM/FM STEREO/CASSETTE/SINGLE CD MUTE AM/FM TAPE BASS TREB TUNE SCAN FADE AUTO SIDE COMP SHUF SEEK REVIEW COPY 2004 Town Car (tow), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 18 Entertainment Systems 1. Eject: Press to eject a tape. 2. Eject: Press to eject a CD. 3. Bass: Allows you to increase or decrease the audio system’s bass output. Press BASS then press SEL to decrease or increase the bass levels. Treble: Allows you to increase or decrease the audio system’s treble output.
Page 19 Entertainment Systems 8. REW (Rewind): Works in tape and CD modes. In tape mode, radio play continues until rewind is stopped (with the TAPE control) or the beginning of the tape is reached. In CD mode, REW control reverses the CD within the current track. FF (fast forward): Works in tape and CD modes.
Page 20 Entertainment Systems 10. Autoset: Press to set first six strong stations into AM, FM1 or FM2 memory buttons; press again to return to normal stations. 11. Scan: Works in radio, tape and CD modes. Press SCAN for a brief sampling of radio stations, tape selections or CD tracks.
Page 21: Cd Changer
Entertainment Systems REAR CONSOLE AUDIO CONTROLS (IF EQUIPPED) • NEXT: Press to access the next radio memory preset, the next CD track or the next tape selection. • VOL: Press the up arrow to increase the volume or the down arrow to decrease the volume.
Page 22 Entertainment Systems 2. Press to eject the magazine. 3. Pull the lever to remove a CD tray from the magazine. 4. Insert one disc into each CD tray of the magazine (up to 6 discs). Ensure that the label side is facing If you pull too hard on the disc holder, the disc holder may come completely out of the magazine.
Page 23 Entertainment Systems 6. Insert the CD magazine into the changer. 7. Slide the door to the left to close. Use only compact discs containing this mark. The magazine does not need to be full for the changer to operate. Radio power must be turned on to play the CDs in the changer. The magazine may be stored in the glove compartment when not being used.
Page 24 Entertainment Systems RADIO RECEPTION FACTORS There are three factors that can affect radio reception: • Distance/strength: The further you travel from an FM station, the weaker the signal and the weaker the reception. • Terrain: Hills, mountains, tall buildings, power lines, electric fences, traffic lights and thunderstorms can interfere with your reception.
Page 25: Navigation System
CDs and also navigate the vehicle using a navigation DVD. Your Lincoln Navigation System has a large range of features, yet is easy to use. Guidance is shown on the display screen and is supplemented with voice prompts.
Page 26 Entertainment Systems 1. VOL-PUSH: Press to turn the system ON/OFF. Turn to adjust the audio volume level. 2. AUDIO: Press to enter audio mode and access radio, CD, CDDJ, DVD (if equipped) settings. 3. MAP: Press to enter map mode and view your current vehicle position on the map.
Page 27 Entertainment Systems Initial map display After pressing AGREE to the initial WARNING screen, you will move into the initial map screen which shows the current vehicle location. Pressing the globe icon will take you to the user settings — audible feedback, navigation units, language and clock (if equipped).
Page 28 Entertainment Systems To play a previously loaded CD: 1. Ensure that the vehicle ignition is on. 2. Press AUDIO. 3. Press CD to select a CD which is already loaded. (NO CD will appear in the display if there are no CDs loaded into the system). Use the controls (1–6) to select the desired CD.
Page 29 Entertainment Systems 2. Press DEST. The warning screen will appear. After reading, press AGREE. The screen will show a map with your current location. Press DEST again. 3. Select the desired type of destination entry. You may select “Address”, “Point of Interest”, “Emergency”...
Page 30 Voice activated commands (if equipped) Your Lincoln Navigation System (LNS) may be equipped with a voice activated feature which allows you to “speak” certain commands to the system. Speaking clearly will help to ensure that the system correctly responds to your commands.
Page 31 Entertainment Systems Press VOICE briefly (on your steering wheel controls) and the voice icon appears on the Navigation display. Press the REPEAT button or arrow on your steering wheel controls to hear the previous command repeated from the navigation system. The voice activated command feature will not operate if a map DVD is not inserted into the navigation DVD unit.
Page 32 Entertainment Systems Commands that jump over screens: • Current position • Current location • Map While in navigation map mode, the following commands are available: • Zoom in • Zoom out • Minimum scale • Maximum scale • North up •...
Page 33 Entertainment Systems • Chinese food • Continental restaurant • Continental food • French restaurant • French food • Italian restaurant • Italian food • Japanese restaurant • Japanese food • Mexican restaurant • Mexican food • Seafood restaurant • Seafood •...
Page 34 • Radio help • Disc help Audio mode Your Lincoln Navigation Audio System has many features including a full range of audio functions. To access these functions, press AUDIO on the main bezel. This will take you into audio mode.
Page 35 Entertainment Systems Volume/power control Press knob to turn the audio system on/off. Turn to raise or lower volume. The levels will be displayed on the screen. To activate the navigation mode, press MAP or DEST. To adjust the navigation voice output level, select the NAV MENU button via the map screen.
Page 36 Entertainment Systems 3. SCV is located in the middle of the screen. Press to turn on. 4. Select setting 1 to 7 or turn off. The recommended level for the speed compensated volume is from level 1 through level 3. When activated, level 1 is the minimum setting and level 7 is the maximum setting.
Page 37 Entertainment Systems Tune adjust Press TUNE to manually move down/up ( ) the frequency band. In CD mode, press TRACK to select the previous/next ( Autoset memory preset Autoset allows you to set strong radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations.
Page 38 Entertainment Systems Scan Press SCAN for a brief sampling of SOUND all listenable stations and CD tracks. SEEK TUNE Press again to disable and remain on SCAN PRESET SCAN AUTO SET the current selection. TRAFFIC INFO SET PTY 87.9 89.9 98.1 98.5 106.3...
Page 39 Entertainment Systems Traffic information not available in most U.S. markets. Information feature Press INFO to view the frequency, SOUND call letters and PTY category of the SEEK TUNE selected FM station. SCAN PRESET SCAN AUTO SET TRAFFIC INFO SET PTY 87.9 89.9 98.1...
Page 40 Entertainment Systems • Soft • Top 40 Once PTY has been programmed, press SEEK ( ) or SCAN to initiate a search up or down the frequency. Preset scan and Autoset also initiate PTY searches. The search will stop when the desired program type has been reached. If no program type is found, a message will display.
Page 41 Entertainment Systems Bass : Allows you to increase or decrease the audio system’s bass output. Treble : Allows you to raise or lower the audio system’s treble output. Fade : Allows you to adjust the amount of sound emitted from the front and rear speakers.
Page 42 Entertainment Systems Satellite ready capability Your Lincoln navigation system comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Lincoln dealer. Detailed Satellite instructions are included with the dealer installed kit. CD mode CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only.
Page 43 Entertainment Systems Press CD. CD play will begin where it stopped last. Loading a CD: 1. Press CD OPEN CLOSE on the bezel. REVIEW COPY 2004 Town Car (tow), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 44 Entertainment Systems 2. The navigation screen will fold down, allowing you access to the in-dash six CD system. 3. Press LOAD and the desired CD slot number. The indicator light will blink slowly at first, then quickly, signaling the system is ready. 4.
Page 45 Entertainment Systems Rewind/fast forward in CD mode Press to reverse or advance ) in the current CD track. Scan feature in CD mode Press SCAN to hear a brief sampling of all tracks on the current CD. Press again to disengage and remain with the current track.
Page 46 Entertainment Systems Pause In CD mode, press PAUSE to pause the current track. Press again to continue playing. Map mode Map display information To access the map display, press MAP on the bezel. Once pressed, the current map display will appear on the screen showing the current vehicle location.
Page 47 Entertainment Systems • Touch one of the arrow buttons repeatedly for the map to be displayed again at the final zoom level. • Touch one of the segments of the scale indicator for the map to be displayed at the selected zoom level. Additional map function buttons To initiate the display of additional map function buttons, tap the map...
Page 48 Entertainment Systems Route preferences After entering a destination, the Route preferences will appear on the screen showing what is currently selected. You may choose to activate/deactivate selections which the system will factor in when calculating your route. Those options are: •...
Page 49 Entertainment Systems You will be able to view the information (if available) as well as choose to store the destination as a memory point by pressing OK. Screen symbols Navigation symbol — Indicates the current vehicle position and points to the direction in which the vehicle is currently traveling.
Page 50 Entertainment Systems Avoid areas or points — The “X” symbol indicates a point. to be avoided in route calculations. If the avoid point is enlarged to an avoid area, it will appear on the screen as a shaded box. Way point symbol — Indicates the location of a way point (locations you wish to visit in route to your ultimate destination) on the map.
Page 51 Entertainment Systems Once pressed, the Navigation Menu will display showing the following options: • Route Options/Preferences • Navigation Set Up • Display Options • Stored Locations • On Route Scroll • Voice Guidance/Volume Depending upon whether or not a route is active will determine if route options/route preferences is contained on the Navigation Menu.
Page 52 Entertainment Systems While driving under route guidance, only follow an instruction when it is safe to do so as the system cannot be aware of changing conditions. Use voice guidance as much as possible, and only view the display when driving conditions permit. Ensure that you follow highway code restrictions and do not take any risks.
Page 53 Entertainment Systems Quick POI (Point of Interest) Allows you to change the Quick POI menu settings. Select the desired Quick POI (Gas, ATM, etc.) and then press ’List Categories’ for further categories, or ’Map Area POIs’ to show the desired POIs on your current map.
Page 54 Entertainment Systems DVD map version Displays the version of the inserted navigation DVD. Refer to Ordering additional map DVDs for further information. Display Options The Display Options screen will allow you make adjustments to the navigation display screen. You can choose from: •...
Page 55 Entertainment Systems Stored locations The Stored locations screen will allow you to choose from destinations that have been saved into the navigation system. In this screen, you can select from Memory Points, Special Memory Points, Home, Avoid Area, Destination and Way Point, or Previous Destination.
Page 56 Entertainment Systems Voice guidance/volume Allows you to turn the voice guidance option on/off and to determine the volume level of the guidance voice prompts. To adjust: 1. Press the MAP hard key. 2. Press “Nav Menu” at the bottom left hand corner of the screen. 3.
Page 57 Entertainment Systems Home To set home for the first time: 1. Press MAP. 2. Press “Nav. Menu”. 3. Press “Stored Locations”. 4. Press “Home”. 5. Press “Add”. REVIEW COPY 2004 Town Car (tow), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 58 Entertainment Systems 6. Select the desired menu item you wish to set as Home (Address, Memory Point, Point of Interest, Previous Destination). 7. Enter the required details. 8. Press OK to set the home position. To view home, press the home icon (house) on the Destination Entry screen.
Page 59 Entertainment Systems To view the set home position 1. Press MAP. 2. Press “Nav. Menu”. 3. Press “Stored Locations”. 4. Press “Home”. 5. Press “List”. REVIEW COPY 2004 Town Car (tow), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 60 Entertainment Systems Deleting a home location 1. Press MAP. 2. Press “Nav. Menu”. 3. Press “Stored Locations”. 4. Press “Home”. 5. Press “Delete”. REVIEW COPY 2004 Town Car (tow), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 61 Entertainment Systems 6. Press YES to confirm. Special memory points There are five possible special memory points that you can set. To set a memory point: 1. Press the MAP hard key. 2. Press “Nav. Menu”. REVIEW COPY 2004 Town Car (tow), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 62 Entertainment Systems 3. Press “Stored Locations”. 4. Press “Special Memory”. 5. Press “Add” and select a position. 6. Select point 1–5. 7. Input a destination. 8. Press OK. Once all five special memory points are entered, the “Add” control will read as “Full”.
Page 63 Entertainment Systems 3. Press “Stored Locations”. 4. Press “Special Memory”. 5. Press “Delete”. The list will display. 6. Select the special memory point to delete. 7. Press “Del. all” to delete all entered special memory points. 8. Press “Yes” to confirm. Detour options You may engage the detour option once a route has already been calculated by the system.
Page 64 Entertainment Systems Press DETOUR to activate. Use the soft controls to select and enter the number of miles you want to deviate off of the current road. Press DETOUR to confirm the selection and to activate the detour around the specified areas. Press NEW ROUTE if you would like the system to plan a different route.
Page 65 Entertainment Systems Avoiding an area while under guidance For one reason or another, you may choose to avoid a certain area while in route to your destination. To select the area to avoid: • From the MAP screen, press Nav Menu.
Page 66 Entertainment Systems Deleting areas to avoid To delete a selection from the “Avoid area” list: • From the stored locations menu, select “Avoid area”. • Press DELETE • Select the desired area to be deleted. • Press DEL. ALL to delete all stored areas.
Page 67 Entertainment Systems Initial map display After pressing AGREE to the initial WARNING screen, you will move into the initial map screen which shows the current vehicle location. Pressing the globe icon will take you to the user settings — audible feedback, navigation units, language and clock (if equipped).
Page 68 Entertainment Systems Selecting a destination Press DEST to set a destination. From this menu, you may select from the following options: • Address— Use to select a destination based on a known street address. • Point of Interest— Use to select a destination that is a point of interest location (i.e., airport, restaurant, hospital).
Page 69 Entertainment Systems 2. Input the house/building number and press OK. 3. Use the keyboard to type in the street name. When you are typing the street name, the system may bring up possible roads that you can select from. Use the arrows to scroll up or down to select the desired street.
Page 70 Entertainment Systems 5. You may use the keyboard to input the desired city. Points of interest (POI) Select “Point of Interest” from the Destination Entry Menu. In this next menu, you will have the following options: • By Name— Enter POI name on the keyboard.
Page 71 Entertainment Systems Deleting stored locations Your navigation system allows you to delete any stored locations (previous destinations, memory points, special memory points, home, avoid areas, destination and way points, etc.) To delete any of these stored locations: 1. Press the MAP hard key. 2.
Page 72 Entertainment Systems 4. Select the desired item you wish to delete (previous destination, memory point, etc.). 5. Press “Delete” at the bottom of the screen. 6. The list of stored locations will be displayed. 7. Select (touch) the entry to be deleted.
Page 73 Entertainment Systems This screen will list the closest police station, hospital and dealer to your current location. Memory point Your navigation system allows you to go to special destinations you may wish to again visit. To view any of these “memory points” without a route calculated: 1.
Page 74 Entertainment Systems 1. Press the MAP hard key. 2. Press “Nav Menu” in the bottom left hand corner of the screen. 3. Press “Stored locations”. 4. Select “Memory Point”. 5. Press “Add” at the bottom of the screen. 6. Select the desired menu item. 7.
Page 75 Entertainment Systems To give the new memory point a name: 1. Select it from the list. 2. Press NAME. 3. Enter the desired name. Accessing memory point lists 1. Press the MAP hard key. 2. Press “Nav Menu” in the bottom left hand corner of the screen. 3.
Page 76 Entertainment Systems 4. Press “Memory Point”. 5. Press LIST 6. Select the desired entry to view its location details. Sorting memory point lists 1. Access the desired list. 2. Press the button to sort the list as desired (i.e. date, name, or icon). When sorted by distance, the points are ordered by distance from the current vehicle location.
Page 77 Entertainment Systems Choosing from the icon list After selecting a location, press ICON to edit. There will be 15 normal and three sound icons displayed. Press the icon you wish to use. The normal icons will be displayed on the map to indicate the map location identified with that icon.
Page 78 Entertainment Systems Freeway Entrance/Exit To set a freeway entrance or exit as a destination: 1. Press the DEST hard key. 2. Press “ Next page” to access the second page of the Destination Entry menu. 3. Select “Freeway Entrance/Exit”. 1. Enter freeway name— Enter the freeway name using the keyboard.
Page 79 Entertainment Systems Destination and way points The Store Dest. & Way Point menu is used after a destination or way point has been entered for the first time using the Destination Entry menu. You can store and delete destinations and way points (locations you wish to visit in route to your ultimate destination).
Page 80 Entertainment Systems Editing and changing order of way points and destination Press “Chg. Order” to change the order in which the way points are visited. The points are listed chronologically from bottom up, the destination being on the top. Press the MAP button to edit the way point location on the map display.
Page 81 Entertainment Systems Route calculation Once the route criteria is selected, the navigation system automatically calculates the selected destination. The route appears on the display screen and a voice prompt provides instructions. The system may calculate up to four routes for the desired destination. Press “Next”...
Page 82 To access menu mode, press the MENU hard control. Menu mode allows you to access: • System Set-up • Information — Gives you the Lincoln Customer Assistance Center information. • Brightness/Contrast — Allows you to adjust the brightness and contrast on the screen.
Page 83 Do not attempt to service, repair or modify the system. See your Ford or Lincoln Mercury dealer. The driver must not attempt to operate any detailed operation of the navigation system while the vehicle is in motion. Give full attention to driving and to the road.
Page 84 Ford or Lincoln Dealer. Federal Communication Commission (FCC) Compliance Changes or modifications not approved by Ford Lincoln Mercury could void user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 85 Entertainment Systems Radio reception factors There are certain factors that may effect your radio reception. • Distance/strength. The further an FM signal travels, the weaker it is. The listenable range of the average FM station is approximately 40 km (24 miles). This range can be affected by “signal modulation.” Signal modulation is a process radio stations use to increase their strength/volume relative to other stations.
Page 86 Entertainment Systems Ensure that you do not have any metal objects on the rear parcel shelf. If your windows are tinted, ensure that you use non-metal tinting instead of metal oxide tinting. Both of these factors can interrupt GPS reception. Cleaning the display Do not spray cleaning fluid directly onto the unit.
Page 87 Entertainment Systems Latest map DVDs The map content is constantly changing due to new roads, traffic restrictions, etc. . Therefore, it is not always possible to exactly match the DVD map with the current roadways. For best results, always use the latest version of the map DVD.
Page 88: Climate Controls
Climate Controls Climate Controls DUAL ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (DEATC) SYSTEM 1. A/C control: Cools the vehicle and is used to reduce humidity in the vehicle. Press to turn on/off. 2. Recirculation control: Cools the vehicle more quickly by recirculating the cabin air instead of using outside air and helps prevent unpleasant outside odors or fumes from entering the vehicle.
Page 89 Climate Controls : Distributes air through the windshield defroster vents and the side window demisters. : Distributes air through the windshield defroster vents, the side window demisters and floor vents. : Distributes air through the floor vents. : Distributes air through the instrument panel vents and the floor vents.
Page 90 Climate Controls 16. Temperature conversion: Press to toggle between Fahrenheit and Celsius temperature on the DEATC display only. The set point temperatures in Celsius will be displayed in half-degree increments. OPERATING TIPS • To reduce fog build up on the windshield during humid weather, place the air flow selector in the position.
Page 91: Rear Window Defroster
Climate Controls REAR CONSOLE CLIMATE CONTROLS (IF EQUIPPED) • TEMP: Press to increase or decrease airflow temperature. • FAN: Press to increase or decrease the fan speed. REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog.
Page 92: Lights
Lights Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Autolamp control The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
Page 93 Lights Daytime running lamps (DRL) (if equipped) The daytime running light system turns the headlamps on, with a reduced light output, when: • the ignition is in RUN, • the transmission is not in P (Park), • the high beams are not in the flash to pass position and •...
Page 94 Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlight and parklamp operation. • Rotate the thumbwheel from left to right to brighten the instrument panel. • Rotate the thumbwheel from right to left to dim the instrument panel.
Page 95: Turn Signal Control
Lights 3. Turn on the low beam headlamps to illuminate the wall or screen and open the hood. 4. On the wall or screen you will observe an area of high intensity light. The top of the high intensity area should touch the horizontal reference line, if not, the beam will need to be adjusted.
Page 96 Lights INTERIOR LAMPS Map/Courtesy lamps To turn on the map lamps, press the map lamp control. Rear courtesy/reading lamps The courtesy lamp lights when: • any door is opened. • any of the remote entry controls are pressed and the ignition is OFF.
Page 97 Lights Function Trade Number Headlamp (HI beam) 9005 Headlamp (LOW beam)* Park and turn lamp (front) 3457 AK Sidemarker (front) Backup lamp 3156 K Stop, tail, turn and sidemarker lamp (rear) 3157 K Cornering lamp 3156 K License plate lamp High-mount brakelamp - Stop** 20 (LEDS) Luggage compartment lamp...
Page 98 Lights Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position. 2. Remove the protective bulb cover by loosening and removing the five screws. 3. Rotate the light bulb socket counter clockwise and pull it straight out from the assembly.
Page 99 Lights 3. Rotate the bulb socket counterclockwise and remove from lamp assembly. 4. Carefully pull bulb straight out of the socket and push in the new bulb until it snaps, locking it into position. 5. To complete installation, follow the removal procedure in reverse order.
Page 100 Lights 8. Install the plastic retainer and carefully push the carpet back into place. Replacing license plate lamp bulbs 1. Make sure headlamp switch is in OFF position, then remove two screws, grommets and the license plate lamp assembly from the trunk lid.
Page 101: Driver Controls
Driver Controls Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: •...
Page 102 Driver Controls Changing the wiper blades 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
Page 103 Driver Controls ILLUMINATED VISOR MIRROR (IF EQUIPPED) Lift the mirror cover to turn on the visor mirror lamps. OVERHEAD CONSOLE (IF EQUIPPED) The appearance of your vehicle’s overhead console will vary according to your option package. Some of the features in the overhead console include Compass, Homelink, Oil minder and Park assist deactivation.
Page 104 Driver Controls Compass mode The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy. 1. Turn ignition to the ON position. 2.
Page 105 Driver Controls 2. Hold down the MODE button for 5 seconds to enter zone mode. The display will read PRESS RESET TO SET ZONE XX where XX is the current zone. 3. Release the MODE button. 4. Determine which magnetic zone you are in by referring to the zone map.
Page 106 Driver Controls 2. Hold down the MODE button for 10 seconds to enter the calibration mode. The display will read PRESS RESET TO DECAL. 3. Release the MODE button. 4. Press the RESET button to de-calibrate the compass. The display will read CIRCLE SLOWLY TO CALIBRATE for a few seconds and then display a direction with CAL displayed on the right side.
Page 107 Driver Controls HomeLink mode (if equipped) Train mode Note: Do not train the HomeLink with the vehicle parked in the garage. To train a HomeLink button to control a specific device: 1. Select the HomeLink button to train. 2. Press and continuously hold the button for 20 seconds.
Page 108 Driver Controls 6. DID NOT TRAIN will be displayed if the channel did not properly train. 7. Release the channel X button. Training is complete. Note: Additional training may be required for rolling code equipped devices. Refer to the Rolling code programming in this section.
Page 109 Driver Controls Transmit mode 1. Select the button for the desired channel (for example, for the garage door you wish to open). 2. Press the button. CHANNEL X TRANSMIT is displayed. 3. The proper signal is transmitted to the device being controlled. 4.
Page 110 Driver Controls HomeLink default code mode HomeLink uses default codes for testing and for optional home lighting accessories. To load the default codes: 1. Simultaneously press and hold buttons 1 and 3. CLEARING CHANNELS is displayed. 2. After 20 seconds CHANNELS CLEARED is displayed.
Page 111 Driver Controls Oil minder mode Normal mode To enter oil minder mode, press the MODE button repeatedly until OIL LIFE XX% is displayed. XX will be 6–100 when oil life is OK. Change oil soon The overhead console will warn the user that it is time to change the oil based on the number of engine revolution counts, number of miles...
Page 112 Driver Controls Reset oil life mode To reset oil minder when the vehicle oil is changed: 1. Press the MODE button repeatedly until one of these three messages is displayed; OIL LIFE XX%, CHANGE OIL SOON or CHANGE OIL NOW. 2.
Page 113 Driver Controls CLOCK Press the right control to move the time display foward. Press the left control to move the time display backwards. AUXILIARY POWER POINT Power outlets are designed for accessory plugs only. Do not hang any type of accessory or <...
Page 114: Power Windows
Driver Controls POWER WINDOWS Press and hold the rocker switches to open and close windows. • Press the top portion of the rocker switch to close. • Press the bottom portion of the rocker switch to open. One touch down •...
Page 115: Mirrors
Driver Controls MIRRORS Automatic dimming inside rear view mirror (if equipped) Your vehicle is equipped with an inside rear view mirror which has an auto-dimming function (available as an option on the outside driver’s side mirror). The electronic day/night mirror will change from the normal state to the non-glare state when bright lights (glare) reach the mirror.
Page 116 Driver Controls Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place.
Page 117: Speed Control
Driver Controls SPEED CONTROL With speed control set, you can maintain a speed of 30 mph (48 km/h) or more without keeping your foot on the accelerator pedal. Speed control does not work at speeds below 30 mph (48 km/h). Do not use the speed control in heavy traffic or on roads that are winding, slippery or unpaved.
Page 118 Driver Controls Resuming a set speed Press the RES/RESUME control and release it. This will automatically return the vehicle to the previously set speed. The message “SPEED ACCEL CONTROL” will be displayed in the message center. The RES/RESUME COAST control will not work if the vehicle speed is not faster than 30 mph (48 km/h).
Page 119 Driver Controls • Depress the brake pedal until the desired vehicle speed is reached, press the SET ACCEL control. ACCEL COAST Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal. This will not erase your vehicle’s previously set speed.
Page 120 Driver Controls STEERING WHEEL CONTROLS (IF EQUIPPED) These controls allow you to operate some radio and climate control features. Radio control features • Press MODE to select AM, FM1, FM2, TAPE or CD (if equipped). In Radio mode: • Press NEXT to select a preset NEXT station from memory.
Page 121 Driver Controls Rear radio/climate controls Refer to Steering Wheel Controls in this chapter for operation instructions. Without navigation system With navigation system Rear radio/climate controls lockout The rear radio/climate control feature can be locked out by pressing the 3 and the 5 buttons on the radio simultaneously while the radio is on. To enable the rear radio/climate controls, press the 3 and the 5 buttons again.
Page 122: Message Center
Driver Controls MOON ROOF (IF EQUIPPED) To open the moon roof: • Press and release the control. • For one-touch operation, press and release the rear portion of the control; this will fully open the moon roof. • To stop one-touch operation at the desired position, press and release the forward portion of the control.
Page 123 Driver Controls The message center allows you to: • see problems such as door ajar and trunk ajar. • check the on/off status of air suspension, autolamp and speed control systems. • see a more accurate speed while driving (this may not show the same speed as your analog speedometer).
Page 124 Driver Controls Reset Press this control to reset the SELECT RESET selected message center function to zero. (The only functions which can be reset are FUEL ECON and TRIP A or B.) Message center functions Speed To use this function, select SPEED and press the RESET control.
Page 125 Driver Controls You may notice gradual improvement in fuel economy over the course of your vehicle’s break-in period (approximately 1 000 miles [1 600 kilometers]). 1. Set the speed control. Refer to Speed control in this chapter. 2. Select FUEL ECON 3.
Page 126 Driver Controls DTE is calculated using a running average fuel economy, which is based on your recent driving history of 500 miles (800 km). This value is not the same as the average fuel economy display. The running average fuel economy is reinitialized to a factory default value if the battery is disconnected.
Page 127 Driver Controls POWER TRUNK (IF EQUIPPED) Your vehicle may be equipped with a power trunk controlled by the interior trunk control, the key fob or the keypad on the door. If anything obstructs the power trunk while it is closing, the trunk will automatically reverse to the open position, provided it meets sufficient resistance.
Page 128 Driver Controls FUEL DOOR RELEASE Your vehicle is equipped with a locking fuel door. To open the door, press the control located on the door. Fuel filler door override release If the remote release is inoperative, open the trunk, then pull the override release handle located inside the trunk to open the fuel filler door.
Page 129 Driver Controls Remote seat adjustment The rear passenger can move the front passenger seat forward or backward using the control located in the rear center console. Move the control forward or backward to move front passenger seat. Remote seat adjustment lockout The window lockout control, located WINDOW LOCK on the drivers door, will also lockout...
Page 130: Locks And Security
Locks and Security Locks and Security KEYS Your vehicle is equipped with a master key and a valet (identified with the word VALET) key lock system. The master key will access: • the driver’s door, • the trunk, • the glove box, •...
Page 131 Locks and Security Central locking/unlocking • All doors are locked when the key is inserted into the driver door key cylinder and turned to the lock position. • The driver’s door is unlocked when the key is inserted into the driver door key cylinder and turned to the unlock position.
Page 132 Locks and Security INTERIOR LUGGAGE COMPARTMENT RELEASE Your vehicle is equipped with a mechanical interior luggage compartment release handle that provides a means of escape for children and adults in the event they become locked inside the luggage compartment. Adults are advised to familiarize themselves with the operation and location of the release handle.
Page 133 Locks and Security REMOTE ENTRY SYSTEM This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 134 Locks and Security • the headlamp control is in the autolamp position, and • the unlock control is pressed on the remote entry transmitter. The headlamps and parklamps remain illuminated: • for 25 seconds, or • until you turn the ignition from the 3 (OFF) position, or •...
Page 135 Locks and Security Press a second time to deactivate the alarm. You may also deactivate the alarm in the following ways: • Turn the ignition to the 1 (ACCESSORY), 4 (ON) or 5 (START) positions. • Wait 2 minutes and 45 seconds for the alarm to time-out. Opening the trunk Press once to open the trunk.
Page 136 Locks and Security 2. Do not wipe off any grease on the battery terminals on the back surface of the circuit board. 3. Remove the old battery. Note: Please refer to local regulations when disposing of transmitter batteries. 4. Insert the new battery. Refer to the diagram inside the remote entry transmitter for the correct orientation of the battery.
Page 137 Locks and Security To reprogram the remote entry transmitters: 1. Ensure the vehicle is electronically unlocked. 2. Put the key in the ignition. 3. Turn the key from the 2 (LOCK) position to 3 (OFF). 4. Cycle eight times rapidly (within 10 seconds) between the 3 (OFF) position and 4 (ON).
Page 138 Locks and Security The inside lights will not turn off if: • they have been turned on with the dimmer control, or • any door is open. The battery saver will shut off the interior lamps 30 minutes after the last door is closed, or after 10 minutes if the last door is left open.
Page 139 Locks and Security Press once to unlock the driver’s door and move the memory features to the corresponding memory position, just as if you had pressed the memory control in the vehicle. Activating the memory seat/mirrors/adjustable pedals feature To activate this feature: 1.
Page 140 Locks and Security Programming a personal entry code To create your own personal entry code: 1. Enter the factory set code. 2. Within five seconds press the 1 • 2 on the keypad. 3. Enter your personal 5-digit code. Each number must be entered within five seconds of each other.
Page 141: Anti-Theft System
Locks and Security Unlocking and locking the doors using keyless entry keypad To unlock the driver’s door, enter the factory set 5-digit code or your personal code. Each number must be pressed within five seconds of each other. The interior lamps will illuminate after pressing the first control on the keypad.
Page 142 Locks and Security objects will not cause damage to the coded key, but may cause a momentary issue if they are too close to the key when starting the engine. If a problem occurs, turn the ignition off, remove all objects on the key chain away from the coded key and restart the engine.
Page 143 Locks and Security Replacement keys If your keys are lost or stolen and you don’t have an extra coded key, you will need to have your vehicle towed to a dealership. The key codes need to be erased from your vehicle and new coded keys will need to be programmed.
Page 144 Locks and Security 7. Within twenty seconds of removing the previously programmed coded key, insert the unprogrammed key (new/valet key) into the ignition. 8. Turn the ignition from the 3 (OFF) position to the 4 (ON) position. Keep the ignition in the 4 (ON) position for at least one second. 9.
Page 145 Locks and Security The system will wait 20 seconds after one of the actions is performed before allowing an alarm to go off. After the 20–second pre-arm phase, the interior trim remote trunk release control and the power door unlock control are disabled, in order to further protect your vehicle.
Page 146: Seating And Safety Restraints
Seating and Safety Restraints Seating and Safety Restraints SEATING Adjustable head restraints Your vehicle’s seats are equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 147 Seating and Safety Restraints Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. To adjust the front seatback using the manual recliner: • Lift and hold the handle located on the side of the seat.
Page 148 Seating and Safety Restraints Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision.
Page 149 Seating and Safety Restraints Press to move the front portion of the seat cushion up or down. Press to move the rear portion of the seat cushion up or down. Heated seats (if equipped) To operate the heated seats: • Push the indicated side of the control for maximum heat.
Page 150 Seating and Safety Restraints The heated seat module resets at every ignition run cycle. While the ignition is in the ON position, activating the high or low heated seat switch enables heating mode. When activated, they will turn off automatically when the ignition is turned to the OFF position. The indicator light will illuminate when the heated seats have been activated.
Page 151: Safety Restraints
Seating and Safety Restraints • To program position two, repeat the previous procedure using control • To program position three, repeat the previous procedure but press controls 1 and 2 simultaneously. A position can only be recalled when the transmission gearshift is in Park.
Page 152 Seating and Safety Restraints RCM activates the safety belt pretensioners and/or either one or both stages of the dual-stage air bag supplemental restraints based on crash severity and occupant conditions. The fact that the pretensioners or air bags did not activate for both front seat occupants in a collision does not mean that something is wrong with the system.
Page 153 Seating and Safety Restraints during a frontal or near-frontal collision. This maximizes the effectiveness of the safety belts and helps properly position the occupant relative to the air bag to improve protection. The safety belt pretensioners can be either activated alone or, if the collision is of sufficient severity, together with the air bags.
Page 154 Seating and Safety Restraints To reduce the risk of injury, make sure children sit in the back seat where they can be properly restrained. Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision.
Page 155 Seating and Safety Restraints Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.
Page 156 Seating and Safety Restraints Webbing extraction sensitive mode The webbing sensitive locking mode locks the webbing and prevents more belt from being pulled out if the belt is pulled out too quickly. The belt will unlock when you stop pulling on it. Automatic locking mode In this mode, the shoulder belt is automatically pre-locked.
Page 157 Seating and Safety Restraints • Grasp the shoulder portion and pull downward until the entire belt is pulled out. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.
Page 158 Seating and Safety Restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front outboard passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height adjuster down.
Page 159 Seating and Safety Restraints The lap belt does not adjust automatically. Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 160 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the ON warning chime sounds 4-8 seconds. position...
Page 161 Seating and Safety Restraints If... Then... The driver’s safety belt is The BeltMinder feature will not buckled before the ignition activate. switch is turned to the ON position... The following are reasons most often given for not wearing safety belts: (All statistics based on U.S.
Page 162 Seating and Safety Restraints Reasons given... Consider... “The people I’m with don’t Set the example, teen deaths occur 4 wear belts” times more often in vehicles with TWO or MORE people. Children and younger brothers/sisters imitate behavior they see. “I have an air bag” Air bags offer greater protection when used with safety belts.
Page 163 Seating and Safety Restraints To reduce the risk of injury, do not deactivate/activate the Belt Minder feature while driving the vehicle. 1. Turn the ignition switch to the RUN (or ON) position. (DO NOT START THE ENGINE) 2. Wait until the safety belt warning light turns off. (Approximately 1 minute) •...
Page 164 Seating and Safety Restraints Use only extensions manufactured by the same supplier as the safety belt. Manufacturer identification is located at the end of the webbing on the label. Also, use the safety belt extension only if the safety belt is too short for you when fully extended.
Page 165: Air Bags
Seating and Safety Restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) CHECK TRAC < FILL ON LEFT km/h SERVICE ENGINE SOON MIST AM/FM TAPE BASS TREB TUNE SCAN MUTE FADE AUTO SIDE COMP SHUF SEEK F/ C DUAL AUTO Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger...
Page 166 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. The front passenger air bag is not designed to offer protection to an occupant in the center front seating position.
Page 167 Seating and Safety Restraints Children and air bags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 168 Seating and Safety Restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 169 Seating and Safety Restraints If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
Page 170 Do not attempt to service, repair, or modify the air bag SRS, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle should always wear their safety belts even when an air bag SRS is provided.
Page 171 Seating and Safety Restraints The side air bags are fitted on the outboard side of the seatbacks of the front seats. In certain lateral collisions, the air bag on the side affected by the collision will be inflated. The air bag was designed to inflate between the door panel and occupant to further enhance the protection provided occupants in side impact collisions.
Page 172 Seating and Safety Restraints • The readiness light will not illuminate immediately after ignition is turned on. • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and/or light are repaired. If any of these things happen, even intermittently, have the SRS serviced at your dealership or by a qualified technician immediately.
Page 173 Seating and Safety Restraints Follow all the important safety restraint and air bag precautions that apply to adult passengers in your vehicle. If the shoulder belt portion of a combination lap and shoulder belt can be positioned so it does not cross or rest in front of the child’s face or neck, the child should wear the lap and shoulder belt.
Page 174 Seating and Safety Restraints • Is the shoulder belt centered on the shoulder and chest? • Can the child stay seated like this for the whole trip? Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder...
Page 175 Seating and Safety Restraints never use a booster seat with a lap belt only. It is best to use a booster seat with lap/shoulder belts in the back seat- the safest place for children to ride. Follow all instructions provided by the manufacturer of the booster seat.
Page 176 Seating and Safety Restraints • Place seat back in upright position. • Put the safety belt in the automatic locking mode. Refer to Automatic locking mode. • LATCH lower anchors are recommended for use by children up to 48 pounds (22 kg) in a child restraint. Top tether anchors can be used for children up to 60 pounds (27 kg) in a child restraint, and to provide upper torso restraint for children up to 80 pounds (36 kg) using an upper torso harness and a belt-positioning booster.
Page 177 Seating and Safety Restraints 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat...
Page 178 Seating and Safety Restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 179 Seating and Safety Restraints 8. Allow the safety belt to retract to remove any slack in the belt. 9. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward.
Page 180 Seating and Safety Restraints 2. Route the child safety seat tether strap over the back of the seat. For vehicles with adjustable head restraints, route the tether strap under the head restraint and between the head restraint posts, otherwise route the tether strap over the top of the seatback.
Page 181 Seating and Safety Restraints Attaching safety seats with LATCH (Lower Anchors and Tethers for Children) attachments Some child safety seats have two rigid or webbing mounted attachments that connect to two anchors at certain seating positions in your vehicle. This type of child seat eliminates the need to use seat belts to attach the child seat.
Page 182 LATCH attachments. Two plastic LATCH guides can be obtained at no charge from any Ford or Lincoln-Mercury dealer. They snap onto the LATCH lower anchors in the seat to help attach a child seat with rigid attachments.
Page 183 Seating and Safety Restraints Attach LATCH lower attachments of the child seat only to the anchors shown. If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it.
Page 184: Driving
Driving Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 185 Driving Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. Do not park, idle, or drive your vehicle in dry grass or other dry ground cover.
Page 186 Driving 4. Make sure the parking brake is set. 5. Turn the key to 4 (ON) without turning the key to 5 (START). Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. •...
Page 187 Driving Starting the engine 1. Turn the key to 4 (ON) without turning the key to 5 (START). If there is difficulty in turning the key, rotate the steering wheel until the key turns freely. 2. Turn the key to 5 (START), then release the key as soon as the engine starts.
Page 188: Brakes
Driving BRAKES Occasional brake noise is normal. If a metal-to-metal, continuous grinding or continuous squeal sound is present, the brake linings may be worn-out and should be inspected by a qualified service technician. If the vehicle has continuous vibration or shudder in the steering wheel while braking, the vehicle should be inspected by a qualified service technician.
Page 189 Driving Parking brake with auto-release Apply the parking brake whenever the vehicle is parked. To set the parking brake: 1. Move the gearshift to P (Park). 2. Push pedal downward. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the ignition is turned ON) until the parking brake is fully released.
Page 190: Traction Control
Driving If the parking brake fails to release after completing this procedure, use the manual parking brake release lever. Pull the lever to manually release the parking brake. TRACTION CONTROL For Traction Control warning lights refer to Warning Lights in the Instrument cluster chapter.
Page 191 Driving Aggressive driving in any road conditions can cause you to lose control of your vehicle increasing the risk of severe personal injury or property damage. The occurrence of a Traction Control event is an indication that at least some of the tires have exceeded their ability to grip the road;...
Page 192: Air Suspension
Driving If the amount of effort required to steer your vehicle changes while driving at a constant vehicle speed, have the power steering system checked by your dealer or a qualified service technician. AIR SUSPENSION SYSTEM The air suspension system is designed to improve ride, handling and general vehicle performance during: •...
Page 193 Driving 2. Insert the key and turn it to OFF. Apply the brake pedal and shift to N (Neutral). When the key is in the ignition and in the OFF position, the automatic transmission shift lever can be moved from the P (Park) position without the brake pedal depressed.
Page 194 Driving To put your vehicle in gear: • Start the engine • Depress the brake pedal • Move the gearshift lever into the desired gear To put your vehicle in P (Park): • Come to a complete stop • Move the gearshift lever and securely latch it in P (Park) Always set the parking brake fully and make sure the gearshift is latched in P (Park).
Page 195 Driving The transmission control indicator light (TCIL) will illuminate on the instrument cluster. Drive (not shown) Drive is activated when the transmission control switch is pressed. • This position allows for all forward gears except overdrive. • O/D OFF lamp is illuminated. •...
Page 196 Driving Forced downshifts • Allowed in (Overdrive) or Drive. • Depress the accelerator to the floor. • Allows transmission to select an appropriate gear. If your vehicle gets stuck in mud or snow If your vehicle gets stuck in mud or snow, it may be rocked out by shifting between forward and reverse gears, stopping between shifts in a steady pattern.
Page 197 Driving This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting objects to avoid damaging the vehicle. The system may not detect smaller objects, particularly those close to the ground.
Page 198 Driving The extended rear park aid is automatically enabled when the gear selector is placed in R (Reverse) and the ignition is ON. A park aid control allows the driver to disable the extended rear park aid only when the ignition is ON, and the gear selector is in R (Reverse).
Page 199: Vehicle Loading
Driving VEHICLE LOADING – WITH AND WITHOUT A TRAILER This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance.
Page 200 Driving Note: For trailer towing information refer to Trailer towing found in this chapter or the RV and Trailer Towing Guide provided by your dealership. GVW (Gross Vehicle Weight) – is the Vehicle Curb Weight + cargo + passengers. GVWR (Gross Vehicle Weight Rating) –...
Page 201 Driving GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 202: Trailer Towing
Driving Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. TRAILER TOWING Your vehicle is classified as a light duty towing vehicle. Do not tow a trailer until your vehicle has been driven at least 2,000 miles (3,200 km). Towing a trailer places an additional load on your vehicle’s engine, transmission, brakes, tires and suspension.
Page 203 Driving Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. The braking system of the tow vehicle is rated for operation at the GVWR not GCWR.
Page 204: Recreational Towing
Driving • The trailer tongue weight should be 10–15% of the loaded trailer weight. • After you have traveled 50 miles (80 km), thoroughly check your hitch, electrical connections and trailer wheel lug nuts. • To aid in engine/transmission cooling and A/C efficiency during hot weather while stopped in traffic, place the gearshift lever in P (Park).
Page 205 Driving • Maximum distance is 50 miles (80 km) If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, you must disconnect the driveshaft. Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation.
Page 206: Roadside Emergencies
In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, the card is found in the Owner Information Guide in the glove compartment.
Page 207: Fuel Pump Shut-Off Switch
If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who need to obtain reimbursement information, call 1–800–665–2006.
Page 208: Fuses And Relays
Roadside Emergencies The fuel pump shut-off switch is located on a bracket inside of the luggage compartment. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
Page 209 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 210 Roadside Emergencies RELAY The fuses are coded as follows. Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Lighting Control Module (LCM), Left-hand low beam headlamp Back-up aide Back-up aide, Fog lamps LCM, Right-hand low beam headlamp 7.5A Instrument cluster 7.5A LCM, Instrument panel light EATC, Heated seats...
Page 211 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Restraint Control Module (RCM), Air bags Stoplamps/Speed control Instrument cluster, Anti-theft, Ignition coils, PCM relay coil Anti-lock brake module, Traction control switch, ABS relay Transmission control switch, LCM, Decklid, A/C clutch relay Multi-function switch, Turn signals 7.5A...
Page 212 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description DTR sensor, Starter relay coil Fuel filler door release switch Heated mirrors Left front door module (DDM) 7.5A Trunk lid release switch, Door lock switches, Left front seat control switch, Left front door module, Power mirror switch, Adjustable pedals, Power decklid...
Page 213 Roadside Emergencies The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 30A* Radio, I/P Fuse 33 20A* Front power point — Not used 15A* Horn 20A* Fuel pump, Inertia switch 20A* Right rear power point (Long Wheel Base only) 30A* Front driver and front passenger...
Page 214 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 7.5A* To alternator 20A* Rear door cigar lighters (Long Wheel Base only) – Not used – Not used – Not used – Not used 15A* MAF sensor, DPFE sensor, Injectors, 15A* PCM, Canister vent solenoid, VMV, HEGOs...
Page 215 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 40A** Ignition switch, I/P fuses, 10, 12, 14, 16, 18 40A** I/P fuses, 1, 3, 5, 7, 9, 31 30A** RASM compressor 40A** I/P fuses 11, 19, 21, 23, 25, 27 30A** Wipers 30A**...
Page 216 Roadside Emergencies CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road. The use of tire sealants is not recommended and may damage your tires.
Page 217 Roadside Emergencies Your vehicle may be equipped with a dissimilar spare tire/wheel. A dissimilar spare tire/wheel is defined as a spare tire and/or wheel that is different in brand, size or appearance from the road tires and wheels. If you have a dissimilar spare tire/wheel, then it is intended for temporary use only.
Page 218 Roadside Emergencies Tire change procedure To help prevent the vehicle from moving when you change a tire, be sure the parking brake is set, then block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire being changed.
Page 219 Roadside Emergencies On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle. Refer to Air suspension system in the Driving chapter for more information. 4. Remove the lug wrench (A) from the jack.
Page 220 Roadside Emergencies Before placing the jack under the vehicle, NOTE the jack location markings: JACK LOCATION-FRONT The jack location markings can be found on the lower outer edge of the body. • Locate the jack locator mark (B - semi-circle) on the body (C) near the tire you are changing, then place the jack (D) under the frame (A) of the vehicle...
Page 221 Roadside Emergencies To lessen risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is ONLY meant for changing the tire. •...
Page 222: Lug Nut Torque
Roadside Emergencies WHEEL LUG NUT TORQUE SPECIFICATIONS Retighten the lug nuts to the specified torque at 500 miles (800 km) after any wheel disturbance (tire rotation, changing a flat tire, wheel removal, etc.). Bolt size Wheel lug nut torque* lb.ft. N•m ⁄...
Page 223 Roadside Emergencies 3. Park the booster vehicle close to the hood of the disabled vehicle making sure the two vehicles do not touch. Set the parking brake on both vehicles and stay clear of the engine cooling fan and other moving parts.
Page 224 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 225 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
Page 226 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 227: Wrecker Towing
Roadside Emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member of a roadside assistance program, your roadside assistance service provider. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment.
Page 228: Customer Assistance
GETTING THE SERVICES YOU NEED At home You must take your Lincoln or Mercury vehicle to an authorized Lincoln Mercury dealer for warranty repairs. While any Ford, Lincoln or Mercury dealership handling your vehicle line will provide warranty service, we recommend you return to your selling dealer who wants to ensure your continued satisfaction.
Page 229 1-800-565-3673 (FORD) www.ford.ca If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 230 • Protection against covered repair costs after your Bumper-to-Bumper Warranty expires. You may purchase Ford ESP from any participating Ford and Lincoln Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs.
Page 231 What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance concerns as on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle warranty are eligible for review, except those involving: •...
Page 232 Customer Assistance What the Board needs To have your case reviewed you must complete the application in the DSB brochure and mail it to the address provided on the application form. Some states will require you to use certified mail, with return receipt requested.
Page 233 Customer Assistance Every effort is made to decide the case within 40 days of the date that all requested information is received by the Board. Since the Board generally meets once a month, it may take longer for the Board to consider some cases.
Page 234 Customer Assistance parties, make decisions and, when appropriate, render awards to resolve disputes. CAMVAP decisions are fast, fair, and final; the arbitrator’s award is binding both to you and Ford of Canada. CAMVAP services are available in all territories and provinces. For more information, without charge or obligation, call your CAMVAP Provincial Administrator directly at 1-800-207-0685.
Page 235 Customer Assistance ORDERING ADDITIONAL OWNER’S LITERATURE To order the publications in this portfolio, contact Helm, Incorporated at: HELM, INCORPORATED P.O. Box 07150 Detroit, Michigan 48207 Or call: For a free publication catalog, order toll free: 1-800-782-4356 Monday-Friday 8:00 a.m. - 6:00 p.m. EST Helm, Incorporated can also be reached by their website: www.helminc.com.
Page 236: Reporting Safety Defects (U.s. Only)
Customer Assistance 3. The vehicle is out of service for repair of nonconformities for a total of more than 30 calendar days (not necessarily all at one time) In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Ford Motor Company...
Page 237: Cleaning
Cleaning Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 238 Cleaning PAINT CHIPS Your dealer has touch-up paint and sprays to match your vehicle’s color. Take your color code (printed on a sticker in the driver’s door jam) to your dealer to ensure you get the correct color. • Remove particles such as bird droppings, tree sap, insect deposits, tar spots, road salt and industrial fallout before repairing paint chips.
Page 239 Cleaning • Cover the highlighted areas to prevent water damage when cleaning the engine. • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your dealer.
Page 240 Cleaning • Do not use abrasives, as they may cause scratches. • Do not use fuel, kerosene, or paint thinner to clean any parts. • Wiper blades can be cleaned with isopropyl (rubbing) alcohol or windshield washer solution. Be sure to replace wiper blades when they appear worn or do not function properly.
Page 241 FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 242 Cleaning Motorcraft Bug and Tar Remover (ZC-42) Motorcraft Extra Strength Upholstery Cleaner (not available in Canada) (ZC-41) Motorcraft Custom Bright Metal Cleaner (ZC-15) Motorcraft Wheel and Tire Cleaner (ZC-37–A) Motorcraft Dash and Vinyl Cleaner (ZC-38–A) Motorcraft Car Care Kit (ZC-26) Motorcraft Premium Car Wash Concentrate (ZC-17-B) Motorcraft Carlite Glass Cleaner (Canada only) (CXC-100) Motorcraft Spot and Stain Remover (ZC-14)
Page 243: Maintenance And Specifications
Maintenance and Specifications Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 244 Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front of the hood in the grille.
Page 245: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.6L SOHC V8 engine 1. Brake fluid reservoir 2. Engine oil dipstick 3. Air filter assembly 4. Power steering fluid reservoir 5. Engine coolant reservoir 6. Battery 7. Windshield washer fluid reservoir 8.
Page 246: Engine Oil
Maintenance and Specifications WINDSHIELD WASHER FLUID Windshield washer fluid Add fluid to fill the reservoir if the level is low. In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specifications. Refer to Refill capacities in this chapter.
Page 247 Maintenance and Specifications 5. Locate and carefully remove the engine oil level indicator (dipstick). DO NOT OVERFILL 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is within this range, the oil level is acceptable. DO NOT ADD OIL.
Page 248 Maintenance and Specifications • If required, add engine oil to the engine. Refer to Adding engine oil in this chapter. • Do not overfill the engine with oil. Oil levels above this mark may cause engine damage. If the engine is overfilled, some oil must be removed from the engine by a qualified service technician.
Page 249 Maintenance and Specifications Engine oil and filter recommendations Look for this certification trademark. Use SAE 5W-20 engine oil. Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). To protect your engine’s warranty use Motorcraft SAE 5W-20 or an equivalent 5W-20 oil meeting Ford specification WSS-M2C153-H.
Page 250: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the Scheduled Maintenance Guide for the service interval schedules.
Page 251 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 252 Maintenance and Specifications • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. RECYCLE ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the mileage intervals listed in the Scheduled Maintenance Guide.
Page 253 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
Page 254 Maintenance and Specifications Do not add engine coolant when the engine is hot. Steam and scalding liquids released from a hot cooling system can burn you badly. Also, you can be burned if you spill coolant on hot engine parts. Do not put engine coolant in the windshield washer fluid container.
Page 255 Maintenance and Specifications remove the coolant pressure relief cap on the radiator of a vehicle with an overflow system, follow these steps to add engine coolant. To reduce the risk of personal injury, make sure the engine is cool before unscrewing the coolant pressure relief cap. The cooling system is under pressure;...
Page 256 Maintenance and Specifications Used engine coolant should be disposed of in an appropriate manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in this section.
Page 257 Maintenance and Specifications What you should know about fail-safe cooling If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred. The “fail-safe” distance depends on ambient temperatures, vehicle load and terrain.
Page 258 Maintenance and Specifications 2. Arrange for the vehicle to be taken to a service facility. 3. If this is not possible, wait a short period for the engine to cool. 4. Check the coolant level and replenish if low. Never remove the coolant reservoir cap while the engine is running or hot.
Page 259 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 260 Maintenance and Specifications Use the following guidelines to avoid static build-up when filling an ungrounded fuel container: • Place approved fuel container on the ground. • DO NOT fill a fuel container while it is in the vehicle (including the cargo area).
Page 261 Maintenance and Specifications If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible personal injury.
Page 262 Maintenance and Specifications It should not be necessary to add any aftermarket products to your fuel tank if you continue to use high quality fuel of the recommended octane rating. Aftermarket products could cause damage to the fuel system. Repairs to correct the effects of using an aftermarket product in your fuel may not be covered by your warranty.
Page 263 Maintenance and Specifications The advertised capacity is the amount of the indicated capacity and the empty reserve combined. Indicated capacity is the difference in the amount of fuel in a full tank and a tank when the fuel gauge indicates empty.
Page 264 Maintenance and Specifications Keep a record for at least one month and record the type of driving (city or highway). This will provide an accurate estimate of the vehicle’s fuel economy under current driving conditions. Additionally, keeping records during summer and winter will show how temperature impacts fuel economy.
Page 265 Maintenance and Specifications • Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in your vehicle scheduled maintenance guide. Conditions • Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed.
Page 266 Maintenance and Specifications • Do not turn off the ignition while your vehicle is moving, especially at high speeds. • Have the items listed in your Scheduled Maintenance Guide performed according to the specified schedule. The scheduled maintenance items listed in the Scheduled Maintenance Guide are essential to the life and performance of your vehicle and to its emissions system.
Page 267 Maintenance and Specifications service technician in properly servicing your vehicle. When the Check engine/Service engine soon light illuminates, the OBD-II system has detected a malfunction. Temporary malfunctions may cause your Check engine/Service engine soon light to illuminate. Examples are: 1. The vehicle has run out of fuel. (The engine may misfire or run poorly.) 2.
Page 268 Maintenance and Specifications CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
Page 269 Maintenance and Specifications add fluid. If the fluid levels are outside of the normal operating range, the performance of your brake system could be compromised, seek service from your dealer immediately. TRANSMISSION FLUID Checking automatic transmission fluid (if equipped) Refer to your Scheduled Maintenance Guide for scheduled intervals for fluid checks and changes.
Page 270 Maintenance and Specifications Low fluid level Do not drive the vehicle if the fluid level is at the bottom of the dipstick and the ambient temperature is above 10°C (50°F). Correct fluid level The transmission fluid should be checked at normal operating temperature 66°C-77°C (150°F-170°F) on a level surface.
Page 271 Maintenance and Specifications High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used.
Page 272 Maintenance and Specifications Changing the air filter element 1. Release the clamps that secure the air filter housing cover. 2. Carefully separate the two halves of the air filter housing. 3. Remove the air filter element from the air filter housing. 4.
Page 273 Maintenance and Specifications U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 274 Maintenance and Specifications TIRES Tires are designed to give many thousands of miles of service, but they must be maintained in order to get the maximum benefit from them. Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry.
Page 275 Maintenance and Specifications Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
Page 276 Maintenance and Specifications Note: You may not find this information on all tires because it is not required by federal law. Letter rating Speed rating - mph (km/h) 99 mph (159 km/h) 106 mph (171 km/h) 112 mph (180 km/h) 118 mph (190 km/h) 124 mph (200 km/h) 130 mph (210 km/h)
Page 277 Maintenance and Specifications 12. Treadwear, Traction and Temperature Grades • Treadwear: The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 ⁄...
Page 278 Maintenance and Specifications Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
Page 279 Maintenance and Specifications Information on “T” type tires T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example. 1. T: Indicates a type of tire, designated by the Tire and Rim Association (T&RA), that is intended for temporary service on cars, SUVs, minivans and light...
Page 280 Maintenance and Specifications inaccurate. Ford recommends the use of a digital or dial type tire pressure gauge rather than a stick type tire pressure gauge. Use the recommended cold inflation pressure for optimum tire performance and wear. Under-inflation or over-inflation may cause uneven treadwear patterns.
Page 281 Wheel misalignment in the front or the rear can cause uneven and rapid treadwear of your tires and should be corrected by a qualified technician at a Ford or Lincoln/Mercury dealer. Front wheel drive (FWD) vehicles and those with an independent rear suspension (if equipped) may require alignment of all four wheels.
Page 282 Maintenance and Specifications • Front Wheel Drive (FWD) vehicles (front tires at top of diagram) • Rear Wheel Drive (RWD) vehicles/Four Wheel Drive (4WD) vehicles (front tires at top of diagram) Sometimes irregular tire wear can be corrected by rotating the tires. REVIEW COPY 2004 Town Car (tow), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 283 Maintenance and Specifications Note: If your tires show uneven wear ask a qualified technician at a Ford or Lincoln/Mercury dealership to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation. Note: Your vehicle may be equipped with a dissimilar spare tire/wheel. A dissimilar spare tire/wheel is defined as a spare tire and/or wheel that is different in brand, size or appearance from the road tires and wheels.
Page 284 If you have questions regarding tire replacement, see an authorized Ford or Lincoln-Mercury dealer. Make sure all tires and wheels on the vehicle are of the same size, type, tread design, brand, load-carrying capacity and speed rating because it...
Page 285 Maintenance and Specifications Never spin the tires in excess of the 35 mph (55 km/h) point indicated on the speedometer. Highway hazards No matter how carefully you drive there’s always the possibility that you may eventually have a flat tire on the highway. Drive slowly to the closest safe area out of traffic.
Page 286 Maintenance and Specifications MOTORCRAFT PART NUMBERS Component 4.6L SOHC V8 engine Air filter element FA-1668 Fuel filter FG-986B Battery-standard BXT-65-650 Battery-heavy duty BXT-65-750 Oil filter FL-820-S PCV valve Spark plugs Included in long wheelbase package. The PCV valve is a critical emission component. It is one of the items listed in the Scheduled Maintenance Guide and is essential to the life and performance of your vehicle and to its emissions system.
Page 287: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Name Capacity Engine oil (includes Motorcraft SAE 5W-20 filter change) Premium Synthetic Blend Motor Oil (US) 5.7L (6.0 quarts) Motorcraft SAE 5W-20 Super Premium Motor Oil (Canada) Brake fluid Motorcraft High Performance DOT 3 Fill to line on reservoir Motor Vehicle Brake Fluid...
Page 288: Lubricant Specifications
Maintenance and Specifications Add the coolant type originally equipped in your vehicle. Rear axles are considered lubricated for life when the vehicle is used for normal service. See your Scheduled Maintenance Guide for Severe Duty requirements. Add 118 ml (4 oz.) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification EST-M2C118–A for complete refill of Traction-Lok rear axle.
Page 289 Maintenance and Specifications Item Ford part Ford part Ford name number specification Engine oil Motorcraft SAE XO-5W20-QSP WSS-M2C153-H 5W20 Premium (US) with API Synthetic Blend CXO-5W20–LSP12 Certification Motor Oil (US) (Canada) Mark Motorcraft SAE 5W-20 Super Premium Motor Oil (Canada) Hinges, latches, Multi-Purpose XG-4 or XL-5...
Page 290 Maintenance and Specifications Add 118 ml (4 oz.) of Additive Friction Modifier XL-3 or equivalent meeting Ford specification EST-M2C118-A for complete refill of Traction-Lok rear axles. For limousine, use 2.1-2.3L (4.50-4.75 pints) of Motorcraft SAE 75W-140 High Performance Rear Axle Lubricant XY-75W140–QL or equivalent meeting Ford Specification WSL-M2C192-A for complete refill of rear axles.
Page 291 Maintenance and Specifications REVIEW COPY 2004 Town Car (tow), Owners Guide (post-2002-fmt) (own2002), Market: USA_English (fus)
Page 292 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the structure by the trailing edge of the driver’s door or the edge of the driver’s door.
Page 293 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) 1.
Page 294 Maintenance and Specifications Transmission/Transaxle code designations You can find a transmission/transaxle code on the vehicle certification label. The following table tells you which transmission or transaxle each code represents. Truck application: Code Transmission Description Manual transmission Manual 5–speed (AKK)) Manual 5–speed overdrive (Close ratio) Manual 5–speed overdrive (Dana ZF) Manual 6–speed ZF Automatic transmission...
Page 295 Maintenance and Specifications Code Transmission Description Electric One speed electric Automatic 5–speed overdrive (5R44E) Automatic 5–speed overdrive (5R55S) Passenger car application: Code Transmission/Transaxle Description Front wheel drive manual transaxle 5–speed overdrive (MTX75) 5–speed overdrive (M5) Front wheel drive automatic transaxle 4–speed overdrive (4F27E) 4–speed overdrive (4FE) 3–speed (Mazda)
Page 296: Accessories
Not all accessories are available for all models. Following is a list of several Genuine Lincoln Accessory products. Not all accessories are available for all models. To find out what accessories are available for your vehicle, please contact your dealer or visit our online store at: www.lincolnaccessories.com.
Page 297 Accessories Floor mats Interior trim kits Leather wrapped steering wheels Scuff plates Speed control Lifestyle Bike racks Cargo organization and management Engine block heaters and blankets Peace of mind Airbag anti-theft locks First aid and safety kits Full vehicle covers Locking gas cap Navigation systems Remote start...
Page 298: Index
Index Index jumping a disabled battery ..222 maintenance-free ....250 Accessory delay ......114 replacement, specifications ...286 servicing ........250 Air bag supplemental restraint system ........165, 169 BeltMinder .........160 and child safety seats ....167 Brakes ........188 description ......165, 169 anti-lock ........188 disposal ........172 anti-lock brake system (ABS) driver air bag ....167, 170 indicator light ....169, 171...
Page 299 Index wiper blades ......239 Defrost rear window ......91 Climate control (see Air conditioning or Heating) ....88 Dipstick automatic transmission Clock ..........113 fluid ..........269 Compass, electronic engine oil .........246 set zone adjustment ....104 Doors Console lubricant specifications ..288 overhead ........103 rear ..........128 Driving under special conditions ........196 Controls...
Page 300 Index aiming ........94 autolamp system .......92 Fail safe cooling ......257 bulb specifications ....96 Floor mats .........129 daytime running lights .....93 flash to pass ......93 Fluid capacities ......287 high beam .........93 Fuel ..........258 replacing bulbs ......98 calculating fuel turning on and off ....92 economy ....107, 124, 262 cap ...........260 HomeLink universal...
Page 301 Index Moon roof ........122 Motorcraft parts ....262, 286 Lamps autolamp system .......92 bulb replacement specifications chart ....96 Navigation system .......25 daytime running light ....93 cd functions ......42 headlamps .........92 destination mode ......66 headlamps, flash to pass ..93 DVD location ......86 instrument panel, dimming ..94 map mode .........46 interior lamps .....96–97...
Page 302 Index Specification chart, lubricants ......288, 290 Radio ..........17 Speed control ......117 Rear window defroster ....91 Starting your Relays ........208 vehicle ......184–185, 187 Remote entry system jump starting ......222 illuminated entry ....137 locking/unlocking doors ..134 Steering opening the trunk ....135 speed sensitive .......191 Reverse sensing system ...196 Steering wheel Roadside assistance ....206...
Page 303 Index fluid, checking and adding (automatic) ......269 fluid, refill capacities ....287 Warning lights (see Lights) ..10 lubricant specifications ..288, 290 Washer fluid ......246 Trunk .........132 remote release ....127, 135 Water, Driving through .....198 Turn signal ........95 Windows power ........114 Windshield washer fluid and Vehicle dimensions ....290 wipers ........101 Vehicle Identification Number...

Lincoln Town Car 2004 Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Quick Links

Table of Contents

Related Manuals for Lincoln Town Car 2004

Summary of Contents for Lincoln Town Car 2004

Table of Contents
