11.11.19 Digicom Codes
Enter
Enter digit 0 - 6 .
11.11.20 Keyswitch Set Configuration
Enter
Enter digit 0 - 6.
11.11.21 Group Reporting Telephone Allocation
This selection requires all four Groups to be programmed.
Enter
- Group 1 'Alarm Codes'. Now select where you require the Alarm Codes to be reported to.
After a number has been selected, the next group will be automatically selected.
Group 2 'User Set/Unset Codes'. Select from the list above where you require User Set/Unset codes to be reported to.
Group 3 'Maintenance Codes'. Select from the list above where you require Maintenance codes to be reported to.
Group 4 '24hr. Test call'. Select from the list above where you require 24hr.Test Call codes to be reported to.
The dual tone sound indicates programming of Group Reporting is now complete.
11.11.22 Engineer NVM Reset
Enter
This function, if enabled in system options 3, resets the panel to factory defaults. The NVM link
must be shorted before this will work.
11.11.23 Follow Select
Enter
This function is used in conjunction with Programmable Output 1 and 2, option 5 'Follow Zone'.
Enter the zone to be followed.
-
for zones 1 to 8 or
Enter
if no zone is to be followed.
11.11.24 Exiting Engineer Mode
Enter
Page 26
SIA DTMF
SIA pulse format P1 - 1400 Hz handshake 10pps
SIA pulse format P2- 2300 Hz handshake 20pps
SIA pulse format P3 - 1400 Hz handshake 20pps
Reserved
Reserved
Reserved
Set A
Set B
Set C
Set D
Reserved
Reserved
Reserved
No reporting for group
Report to telephone number 1, backup to number 2
Report to telephone number 2 only
Report to both telephone numbers always
(Where
is the 4 digit Engineer Code).
