- Page 1 EXCELLENCE COOKER CX 601 G Instruction for the use - Installation advice KEEP IN A SAFE PLACE...
- Page 2 Dear Customer, IMPORTANT INSTRUCTIONS AND ADVICE FOR THE USE OF Thank you for having purchased and ELECTRICAL APPLIANCES given your preference to our product. The safety precautions and The use of any electrical appliance recommendations reported below are requires the compliance with some basic for your own safety and that of others.
-
Page 3: Important Precautions And Recommendations
IMPORTANT PRECAUTIONS WARNING When correctly installed, your product AND RECOMMENDATIONS meets all safety requirements laid down for this type of product category. After having unpacked the appliance, However special care should be taken check to ensure that it is not damaged around the rear or the underneath of and that the oven door closes correctly. -
Page 4: Cooking Hob
1 - COOKING HOB - CONTROL PANEL COOKING HOB 1. Auxiliary burner (A) 1,00 kW 2. Semi-rapid burner (SR) 1,75 kW 3. Rapid burner (SR) 3,00 kW Fig. 1.1 Fig. 1.2 CONTROLS DESCRIPTION 1. Front right burner control knob 2. Rear right burner control knob 3. -
Page 5: Use Of Cooking Hob
2 - USE OF COOKING HOB GAS BURNERS Other intermediate operating adjust- ments can be achieved by positioning Each burner is controlled by a gas tap the lever between the maximum and assuring the opening and the closing of minimum aperture positions, and never the gas supply. -
Page 6: Choice Of The Burner
CHOICE OF THE BURNER It is important that the diameter of the pot be suitable to the potentiality of the On the control panel, near every knob, burner so as not to compromise the high there is a diagram that indicates which output of the burners and therefore burner is controlled by that knob. -
Page 7: General Features
3 - USE OF THE GAS OVEN IGNITION OF THE OVEN BURNER Attention: the oven door becomes very hot during operation. The thermostat allows the automatic Keep children away. control of the temperature. The gas delivery to the oven burner is controlled by a two way thermostatic tap (oven and grill burners) with flame-failure GENERAL FEATURES... -
Page 8: Oven Thermostat
OVEN THERMOSTAT The numbers 1 to 10 printed on the con- trol panel (fig. 3.3) indicate the increas- ing oven temperature value (see table below - THERMOSTAT GRADE TABLE To regulate the temperature, set the chosen number onto the knob indicator. Fig. -
Page 9: Oven Cooking
OVEN COOKING COOKING EXAMPLES Before introducing the food, preheat the Temperatures and times are approxi- oven to the desired temperature. mate as they vary depending on the For a correct preheating operation, it is quality and amount of food. advisable to remove the tray from the Remember to use ovenproof dishes and oven and introduce it together with the to adjust the oven temperature during... - Page 10 IGNITION OF THE GRILL BURNER 3) Press the knob right down to prime the electric ignition. WARNING: Risk of explosion! The oven door must be open during this operation. Do not grill with oven door closed. In case of power cut, press the knob Always fit the heat shield supplied and put a lighted match to the right with the cooker under the front...
-
Page 11: Use Of The Grill
IMPORTANT WARNING USE OF THE GRILL For best results when using the grill, Very important: the grill must always place the shelf on the second level and be used with the oven door slightly when using the grill pan handle avoid open (Fig. -
Page 12: Electronic Clock/Alarm
4 - ELECTRONIC CLOCK/ALARM The electronic alarm is a device which ELECTRONIC ALARM groups the functions of 24 hours clock The alarm program consists only of a with illuminated display and 99 minutes buzzer which may be set for a maximum alarm. -
Page 13: Cleaning And Maintenance
5 - CLEANING AND MAINTENANCE GENERAL ADVICE IMPORTANT NOTES Installation, and any demonstration, – When the appliance is not being information or adjustments are not used, it is advisable to keep the gas included in the warranty. tap closed. The cooker must be installed by a quali- –... -
Page 14: Replacing The Oven Light Bulb
ENAMELLED PARTS INSIDE OF OVEN This must be cleaned regularly. All the enamelled parts must be cleaned Remove and refit the side runner frames with a sponge and soapy water or other as described on the next chapter. non-abrasive products. With the oven warm, wipe the inside Dry preferably with a soft cloth. - Page 15 BURNERS CORRECT REPLACEMENT OF THE BURNERS They can be removed and washed with soapy water only. It is very important to check that the They will remain always perfect if burner flame distributor F and the cap C cleaned with products used for silver- has been correctly positioned (see fig.
- Page 16 OVEN DOOR AND DRAWER ASSEMBLY AND DISMANTLING OF THE SIDE RUNNER FRAMES The internal glass of the oven door can be easily removed for cleaning by – Fit the side runner frames into the unscrewing the two lateral fixing screws holes on the side walls inside the (fig.
-
Page 17: Removing The Oven Door
Type A REMOVING THE OVEN DOOR To facilitate oven cleaning, it is possible to remove the door. Please follow the instructions carefully: – Open the door completely. – Push down the lever “L” and, keeping it in this position, slowly close the door in order to block the hinge. - Page 18 Type B Fig. 5.10A REMOVING THE OVEN DOOR The oven door can easily be removed as follows: – Open the door to the full extent (fig. 5.10A). – Attach the retaining rings to the hooks on the left and right hinges (fig. 5.10B). Fig.
- Page 19 Advice for the installer IMPORTANT – Cooker installation, regulation and conversion to other gas types must only be carried out by QUALIFIED TECHNICIANS and in compliance with local safety standards. – The electrical mains outlet, if located behind the cooker, must not be higher than 18 cm above the floor level.
-
Page 20: Installation
6 - INSTALLATION This cookers has class “2/1” overheating protection so that it can be installed next to a cabinet. If the cooker is installed adjacent to furniture which is higher than the gas hob cooktop, a gap of at least 50 mm must be left between the side of the cooker and the furniture. The furniture walls adjacent to the cooker must be made of material resistant to heat. - Page 21 Fig. 6.3 + 8 mm Fig. 6.4 Fig. 6.2 + 8 mm + 35 mm FITTING THE ADJUSTABE FEET The cooker is equipped with 4 levelling feet which must be fitted to the base of the cooker before use, in the following manner: –...
-
Page 22: Provision For Ventilation
PROVISION FOR VENTILATION The room containing the cooker should have an air supply in accordance with BS.5540: Part 2: 1989. All rooms require an openable window or equivalent while some rooms require a permanent vent in addition to the openable window. The cooker should not be installed in a bed-sitting room, of volume less than 21 m Where a DOMESTIC COOKER is installed in a room or internal space, that room or internal space shall be provided with a permanent opening which communicates directly... -
Page 23: Gas Section
7 - GAS SECTION GAS INSTALLATION GAS CONNECTION IMPORTANT NOTE The installation of the cooker to Natural Gas or LP Gas must be carried out by a This appliance is supplied for use on qualified gas engineer. Installers shall NATURAL GAS only and cannot be take due account of the provisions of the used on any other gas without modifica- relevant British Standards Code of... - Page 24 GAS CONNECTION Left gas Right gas inlet pipe The gas supply must use the nearest inlet pipe gas inlet pipe which is located at the left or the right hand side at the rear of the appliance (fig. 7.1). The unused end inlet pipe must be closed with the plug interposing the gasket.
-
Page 25: Conversion To Lpg
CONVERSION TO LPG REPLACEMENT OF BURNER INJECTORS If the injectors are not supplied they can be obtained from the “Service Centre”. Select the injectors to be replaced according to the “Table for the choice of the injectors”. To replace the injectors proceed as fol- lows: - Remove pan supports and burners from the cooktop. - Page 26 TABLE FOR THE CHOICE OF THE INJECTORS Cat: 2H3+ G 30 - 28-30 mbar G 20 - 20 mbar BURNERS Nominal Reduced G 31 - 37 mbar Power Power Ø injector By-pass By-pass Ø injector Ring opening Ring opening [kW] [kW] [mm] [mm]...
- Page 27 OVEN BURNER AND GRILL BURNER REPLACEMENT OF INJECTORS a) oven burner – Lift and remove the lower panel inside the oven. – Remove the burner securing screw (fig. 7.6) – Withdraw the burner as shown in fig- Fig. 7.6 ure 7.7 and rest it inside the oven. Take care not to damage the wire to the ignition electrode and the safety valve probe.
- Page 28 PRIMARY AIR OF OVEN AND GRILL BURNERS Using a cross-head screwdriver, slacken the screw securing the air flow regulation collar (fig. 7.10 and 7.11) and move the collar forward or backward to increase or reduce the air aperture in accordance with gas type and the indications in the “ TABLE FOR THE CHOICE OF THE INJECTORS ”.
-
Page 29: Adjustment Of The Oven Burner Minimum
ADJUSTMENT OF THE OVEN BURNER MINIMUM To be effected only for the oven burner (as the grill burner has an only fixed input) operating on the thermostat as fol- lows: – Light the oven taking the knob to Max. position. –... -
Page 30: Electrical Section
8 - ELECTRICAL SECTION For your safety please read the A properly earthed three pin plug (fused following information: at 3 amps, to BS 1362 ASTA approved) must be used. This appliance must be installed by a qualified technician according with the As the colours of the wires in the mains current local... -
Page 31: After Sales Service
AFTER SALES SERVICE If you require After Sales Service contact the MASTERCARE Domestic Appliance Helpline Telephone 08701 565550. Ser. Nr. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service. - Page 32 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcrip- tion errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appliances.
