- Page 1 EXCELLENCE COOKER CX 907 G Instruction for the use - Installation advice KEEP IN A SAFE PLACE...
- Page 2 Dear Customer, IMPORTANT INSTRUCTIONS AND ADVICE FOR THE USE OF Thank you for having purchased and ELECTRICAL APPLIANCES given your preference to our product. The safety precautions and The use of any electrical appliance recommendations reported below are requires the compliance with some basic for your own safety and that of others.
-
Page 3: Important Precautions And Recommendations
IMPORTANT PRECAUTIONS WARNING When correctly installed, your product AND RECOMMENDATIONS meets all safety requirements laid down for this type of product category. After having unpacked the appliance, However special care should be taken check to ensure that it is not damaged around the rear or the underneath of and that the oven door closes correctly. -
Page 4: Cooking Hob
1 - COOKING HOB Fig. 1.1 COOKING HOB 1. Triple-ring burner (TC) 3,50 kW 2. Semi-rapid burner (SR) 1,75 kW 3. Rapid burner (R) 3,00 kW 4. Auxiliary burner (A) 1,00 kW 5. Semi-rapid burner (SR) 1,75 kW 6. Auxiliary burner (A) 1,00 kW... -
Page 5: Control Panel
2 - CONTROL PANEL Fig. 2.1 CONTROL PANEL - Controls description 1. Gas oven/gas grill control knob 2. Minute minder 3. Front left burner control knob 4. Rear left burner control knob 5. Front central burner control knob 6. Rear central burner control knob 7. -
Page 6: Use Of Cooking Hob
3 - USE OF COOKING HOB GAS BURNERS Other intermediate operating adjust- ments can be achieved by positioning Each burner is controlled by a gas tap the lever between the maximum and assuring the opening and the closing of minimum aperture positions, and never the gas supply. -
Page 7: Choice Of The Burner
CHOICE OF THE BURNER It is important that the diameter of the pot be suitable to the potentiality of the On the control panel, near every knob, burner so as not to compromise the high there is a diagram that indicates which output of the burners and therefore burner is controlled by that knob. - Page 8 CORRECT USE OF TRIPLE-RING BURNER (Fig. 3.4a - 3.4b) The flat-bottomed pans are to be placed directly onto the pan-support. When using a WOK you need to place the supplied stand in the burner to avoid any faulty operation of the double-ring burner (Fig. 3.4a - 3.4b). WRONG CORRECT Fig.
-
Page 9: General Features
4 - GAS OVEN IGNITION OF THE OVEN BURNER Attention: the oven door becomes The thermostat allows the automatic very hot during operation. control of the temperature. Keep children away. The gas delivery to the oven burner is controlled by a two way thermostatic tap (oven and grill burners) with flame-fail- GENERAL FEATURES ure device. -
Page 10: Oven Thermostat
OVEN THERMOSTAT The numbers 1 to 10 printed on the con- trol panel (fig. 4.2) indicate the increas- ing oven temperature value (see table below - THERMOSTAT GRADE TABLE To regulate the temperature, set the chosen number onto the knob indicator. Fig. -
Page 11: Oven Cooking
OVEN COOKING COOKING EXAMPLES Before introducing the food, preheat the Temperatures and times are approxi- oven to the desired temperature. mate as they vary depending on the For a correct preheating operation, it is quality and amount of food. advisable to remove the tray from the oven and introduce it together with the Remember to use ovenproof dishes and food, when the oven has reached the... - Page 12 IGNITION OF THE GRILL BURNER The grill burner generates the infra-red rays for grilling. To light the grill burner operate as follow: 1) Open the oven door. Do not grill with oven door closed. Always fit the heat shield supplied 2) Lightly press and turn the thermostat with the cooker under the front knob clockwise to the...
-
Page 13: Oven Light
Notes: – The grill burner has only one setting, that is full-on – It is important that the heat shield is fitted the correct way up, as shown in the figure 4.6. Fig. 4.6 IMPORTANT WARNING For best results when using the grill, place the shelf on the second level and when using the grill pan handle avoid contact with the heat shield which will be HOT during use OVEN LIGHT... -
Page 14: Minute Counter
5 - MINUTE COUNTER MINUTE MINDER (Fig. 5.1) The minute counter is a timed acoustic warning device which can be set for a maximum of 60 minutes. The knob (Fig. 5.1) must be rotated clockwise as far as the 60 minute posi- tion and then set to the required time by rotating it anticlockwise. -
Page 15: Cleaning And Maintenance
6 - CLEANING AND MAINTENANCE GENERAL ADVICE ENAMELLED PARTS All the enamelled parts must be cleaned – When the appliance is not being with a sponge and soapy water or other used, it is advisable to keep the gas non-abrasive products. tap closed. - Page 16 WARNING GAS TAPS When correctly installed, your product In the event of operating faults in the gas meets all safety requirements laid down taps, call the After Sales Service for this type of product category. Department. However special care should be taken around the rear or the underneath of the appliance as these areas are not BURNERS...
- Page 17 CORRECT REPLACEMENT OF THE TRIPLE RING BURNER BURNERS The triple ring burner must be correctly positioned (see fig. 6.5); the burner rib It is very important to check that the must be enter in their logement as burner flame distributor F and the cap C shown by the arrow see fig.
-
Page 18: Oven Floor
INSIDE OF OVEN This must be cleaned regularly. Remove and refit the side runner frames as described on the next chapter. With the oven warm, wipe the inside walls with a cloth soaked in very hot soapy water or another suitable product. The bottom of the oven, side runner frames, tray and rack can be removed and washed. -
Page 19: Replacing The Oven Light Bulb
Fig. 6.9 Fig. 6.10 REPLACING THE OVEN LIGHT BULB OVEN DOOR Switch the cooker off at the mains. The internal glass panel can be easily removed for cleaning by unscrewing the When the oven is cool unscrew and 4 retaining screws (Fig. 6.9) replace the bulb with another one resis- tant to high temperatures (300°C), volt- age 230 V (50 Hz), 15 W, E14. -
Page 20: Removing The Oven Door
REMOVING THE OVEN DOOR Fig. 6.11A The oven door can easily be removed as follows: – Open the door to the full extent (fig. 6.11A). – Attach the retaining rings to the hooks on the left and right hinges (fig. 6.11B). - Page 21 Advice for the installer IMPORTANT – Cooker installation, regulation and conversion to other gas types must only be carried out by QUALIFIED TECHNICIANS. Failure to observe this rule will invalidate the war- ranty. – The electrical mains outlet, if located behind the cooker, must not be higher than 18 cm above the floor level.
-
Page 22: Installation
7 - INSTALLATION This cookers has class “2/1” overheating protection so that it can be installed next to a cabinet. If the cooker is installed adjacent to furniture which is higher than the gas hob cooktop, a gap of at least 50 mm must be left between the side of the cooker and the furniture. The furniture walls adjacent to the cooker must be made of material resistant to heat. -
Page 23: Fitting The Adjustable Feet
FITTING THE ADJUSTABLE FEET The adjustable feet must be fitted to the base of the cooker before use. Rest the rear of the cooker an a piece of the polystyrene packaging exposing the base for the fitting of the feet. WARNING Fig. -
Page 24: Provision For Ventilation
PROVISION FOR VENTILATION The room containing the cooker should have an air supply in accordance with BS.5540: Part 2: 1989. All rooms require an openable window or equivalent while some rooms require a perma- nent vent in addition to the openable window. The cooker should not be installed in a bed-sitting room, of volume less than 21 m Where a DOMESTIC COOKER is installed in a room or internal space, that room or inter- nal space shall be provided with a permanent opening which communicates directly with... -
Page 25: Gas Section
8 - GAS SECTION GAS INSTALLATION GAS CONNECTION IMPORTANT NOTE The installation of the cooker to Natural Gas or LP Gas must be carried out by a This appliance is supplied for use on qualified gas engineer. Installers shall NATURAL GAS only and cannot be take due account of the provisions of the used on any other gas without modifica- relevant British Standards Code of... - Page 26 GAS CONNECTION The gas supply must use the nearest gas inlet pipe which is located at the left or the right hand side at the rear of the appliance (fig. 8.1). The unused end inlet pipe must be closed with the plug interposing the gasket. Flexible hoses can be used where the sited ambient temperature of the hose does not exceed 70°C.
- Page 27 To avoid damage to the appliance gas rail inlet pipe the fittings should be tightened using two suitable spanners (fig. 8.2). After connection to the mains gas supply the couplings should be checked for gas soundness/tightness as per current regulations for the gas type being used Fig.
-
Page 28: Conversion To Lpg
CONVERSION TO LPG REPLACEMENT OF BURNER INJECTORS If the injectors are not supplied they can be obtained from the “Service Centre”. Select the injectors to be replaced according to the “Table for the choice of the injectors”. To replace the injectors proceed as fol- lows: - Remove pan supports and burners from the cooktop. - Page 29 TABLE FOR THE CHOICE OF THE INJECTORS Cat: 2H3+ G 30 - 28-30 mbar G 20 - 20 mbar Nominal Reduced BURNERS G 31 - 37 mbar Power Power Ø injector By-pass Ø injector By-pass Ring opening Ring opening [kW] [kW] [mm] [1/100 mm]...
- Page 30 OVEN BURNER AND GRILL BURNER REPLACEMENT OF INJECTORS a) oven burner – Lift and remove the lower panel inside the oven. – Unscrew and remove the burner securing screw A (fig. 8.6). – Slacken screw B (fig. 8.6). – Withdraw the burner in the manner shown in figure 8.7, and rest it inside the oven.
- Page 31 b) grill burner – Unscrew and remove the burner securing screw ‘C’ (fig. 8.8). – Slacken screw ‘D’ (fig. 8.8). – Move the burner in the manner shown in figure 8.9. Take care not to damage the wire to the ignition electrode and the safety valve probe.
- Page 32 Fig. 8.10 REGULATION OF AIR SUPPLY TO OVEN AND GRILL BURNERS Using a cross-head screwdriver, slacken the screw securing the air flow regulation collar (fig. 8.10 and 8.11) and move the collar forward or backward to increase or reduce the air aperture in accordance with gas type and the indications in the “...
-
Page 33: Adjustment Of The Oven Burner Minimum
ADJUSTMENT OF THE OVEN Flame correct BURNER MINIMUM To be effected only for the oven burner (as the grill burner has an only fixed input) operating on the thermostat as fol- Flame faulty in lows: primary air – Light the oven taking the knob to Max. position. -
Page 34: Electrical Section
9 - ELECTRICAL SECTION For your safety please read the fol- A properly earthed three pin plug (fused lowing information: at 3 amps, to BS 1362 ASTA approved) must be used. This appliance must be installed by a qualified technician according with the As the colours of the wires in the mains current local regulations and in compli- lead of this appliance may not corre-... -
Page 35: After Sales Service
AFTER SALES SERVICE If you require After Sales Service contact the MASTERCARE Domestic Appliance Helpline Telephone 08701 565550. Ser. Nr. IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. At the end of its working life, the product must not be disposed of as urban waste. It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this service. - Page 36 The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the present booklet. The manufacturer reserves the right to make all modifications to its products deemed necessary for manufacture or commercial reasons at any moment and without prior notice, without jeopardising the essential functional and safety characteristics of the appli- ances.
