CC-Link network configuration

To configure the network double click on the "Network" under "Parameter". Choose CC-Link.
Figure 4 Configuring the CC-Link network.
Specify the parameters as shown below.
Figure 5 Setting the CC-Link parameters.
The PLC is a master unit and the "Type"
version of CC-Link, version 1.0 or 2.0. . "All connect count"
In this case the number of station is 1 since the Anybus module is the only connected station. In the fields
Remote input(RX) and Remote output(RY)
www.anybus.com
How to set up an Anybus CC-Link slave module with a Mitsubishi PLC
is therefore selected to master. The next step is to select the
the offset for the I/O data is entered.
HMS Industrial Networks AB
1
2
3
4
specifies the number of connected stations.
