Parts List - Linear Technology DC1760A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
1 2 C1, C56
2 3 C11, C12, C15
3 6 C13, C14, C33, C37, C39, C40
4 2 C16, C20
5 1 C17
6 0 C18, C45, C46, C47, C48
7 2 C2, C5
8 19 C3, C4, C6-C10, C21,C25-C27, C32,
C34-C36, C41, C43, C44, C57
9 0 C42
10 1 J10
11 2 J2, J4
12 3 J7, J8, J9
13 1 L1
14 5 R1, R5, R6, R7, R8
15 0 R10, R11, R42, R46, R47, R52, R53
16 1 R15
17 1 R16
18 1 R17
19 0 R18, R19, R20
20 1 R2
21 1 R24
22 3 R25, R26, R29
23 2 R3, R31
24 2 R39, R40
25 5 R4, R14, R32, R33, R35
26 1 R43
27 2 R49, R54
28 4 R57, R58, R59, R60
29 9 R9, R12, R13, R41, R48, R50, R51, R55,
R56
30 8 TP1, TP2, TP3, TP4, TP5, TP6, TP7, TP8
31 1 U1
32 1 U10
33 2 U2, U4
34 2 U3, U5
35 1 U6
36 1 U7
37 1 U9
38 SHUNTS
39 4 MTG1, MTG2, MTG3, MTG4
40 2 STENCILS FOR BOTH SIDES
DEMO MANUAL DC1760A
PART DESCRIPTION
CAP ., 0603 2.2μF 6.3V 20% X5R
CAP ., 0402 1000pF 5% 50V COG
CAP ., 0402 1μF 10V 10% X5R
CAP ., Tant., 100μF , 10V, 20% 6032
CAP ., 0805 2.2μF 10V 20% X5R
CAP ., 0402
CAP ., 0201 0.8pF 25V ±0.1pF NP0
CAP ., 0402 0.1μF 10V 10% X5R
CAP ., 0402
HEADER, 3-PIN 0.079 SINGLE ROW
HEADER, 2 × 3 PIN 0.079 DOUBLE ROW
CONN., SMA 50Ω EDGE-LANCH
IND., BEAD, 60Ω Impedance 0805
RES., ARRAY, 33Ω 0402 5%
RES., 0402
RES., 0402 100Ω 1% 1/16W
RES., 0201 100Ω 1% 1/20W
RES., 0402 10Ω 1% 1/16W
RES., 0402
RES., 0402 10k 1% 1/16W
RES., 0402 100k 1% 1/16W
RES., 0402 4.99k 1% 1/16W
RES., 0402 180k 1% 1/16W 5%?
RES., 0201 10Ω 5% 1/20W
REA., 0603 1k 5% 1/16W
RES., 0402 66.5Ω 1% 1/16W
RES., 0402 30.1Ω 1% 1/16W
RES., 0402 150Ω 5% 1/16W
RES., 0402 0Ω JUMPER
TP , TURRET, 0.064"
I.C., Serial EEPROM TSSOP-8
IC, LT6409 QFN-3MM × 2MM
IC, LT3080EDD
IC, FXLH42245 DFN-8X4
IC, NC7SP17P5X SC70-5
IC, PCF8574 SSOP20
IC, LTC2262IUJ, TQFN-6 × 6-40PIN
STAND-OFF , NYLON (SNAP ON), 0.25" TALL KEYSTONE, 8831(SNAP ON)
MANUFACTURER/PART NUMBER
AVX, 06036D255MAT2A
MURATA, GRM1555C1H102JA01
AVX, 0402ZD105KAT2A
AVX, TAJW107M010R
AVX, 0805ZD225MAT
OPT
AVX, 02013A0R8BAT2A
AVX, 0402ZD104KAT
TBD
SAMTEC, TMM-103-02-L-S
SAMTEC, TMM-103-02-L-D
CONNEX, 132357 / 142-0701-851
MURATA, BLM21BB600SN1D
VISHAY, CRA04S08333R0JTD
TBD
VISHAY, CRCW0402100RFKED
VISHAY, CRCW0201100RFNED
VISHAY, CRCW040210R0FKED
OPT
VISHAY, CRCW040210K0FKED
VISHAY, CRCW0402100KFKED
VISHAY, CRCW04024K99FKED
VISHAY, CRCW0402180KFKED
VISHAY, CRCW020110R0JNED
VISHAY, CRCW06031K00FKEA
VISHAY, CRCW040266R5FKED
VISHAY, CRCW040230R1FKED
VISHAY, CRCW0402150RJNED
VISHAY, CRCW04020000Z0ED
MILL-MAX, 2308-2-00-80-00-00-07-0
MICROCHIP , 24LC025-I/ST
LINEAR, LTC6409CUD#PBF
LINEAR, LT3080EDD#PBF
FAIRCHILD, FXLH42245MPX
FAIRCHILD, NC7SP17P5X
PHILLIPS, PCF8574TS
LINEAR, LTC2262IUJ-14#PBF
STENCIL DC1760A-1
dc1760af
7
