- Page 1 EX-PD24 Installation manual Copyright © 2021 TKH Security B.V.. Version 1.0. TKH Security | Siqura EX-PD24 | Installation manual...
- Page 2 Any brand names mentioned in this manual are registered trademarks of their respective owners. Liability TKH Security accepts no liability for claims from third parties arising from improper use other than that stated in this manual. Although considerable care has been taken to ensure a correct and suitably comprehensive description of all relevant product components, this manual may nonetheless contain errors and inaccuracies.
-
Page 3: Table Of Contents
Installation instruction ....................9 Assemby ........................10 Grounding / Earthing ....................11 Internal wiring diagram....................12 Drill template ........................ 13 Safety hook ........................13 Getting started ........................14 Access from a browser ....................15 TKH Security | Siqura EX-PD24 | Installation manual... -
Page 4: Description
IP66 and IP68. This product must only be installed by suitably trained personnel in accordance with the relevant code of practice (e.g., EN60079-14). These instructions are intended for their sole use. TKH Security | Siqura EX-PD24 | Installation manual... -
Page 5: Before You Continue
When a fibre optical cable is used on the equipment it shall be suitably protected against mechanical damage. The camera must be installed so that the risk of impact on the dome is low. TKH Security | Siqura EX-PD24 | Installation manual... -
Page 6: Install The Unit
Check the proper position of the O-ring seals in their groove Keep the unit tightly closed when operating. Disconnect the equipment from the supply circuit and wait at least five minutes before opening. TKH Security | Siqura EX-PD24 | Installation manual... -
Page 7: Special Conditions For Safe Use
This camera shall only be installed in locations with a low risk of impact to the dome (bubble) Use caution when servicing, the surface temperature at cable entry point of the camera can reach temperatures up to 75℃ TKH Security | Siqura EX-PD24 | Installation manual... -
Page 8: Marking (Label)
Marking (label) Every camera shall be labeled with a marking plate similar as the one shown below: TKH Security | Siqura EX-PD24 | Installation manual... -
Page 9: Camera Installation
CABLE GLAND Cable entry thread : M20 / M25 Cable Size M20 : 9~15.3 mm M25 : 13~20 mm SE OF EXPLOSION PROOF CERTIFIED PRODUCTS EARTH BOLT COVER-2 FLANGE BODY COVER-1 BUBBLE (Dome) TKH Security | Siqura EX-PD24 | Installation manual... -
Page 10: Assemby
TKH Security Proposal | RFP Name | RFP Number Assemby TKH Security | Siqura EX-PD24 | Installation manual... -
Page 11: Grounding / Earthing
TKH Security Proposal | RFP Name | RFP Number Grounding / Earthing TKH Security | Siqura EX-PD24 | Installation manual... -
Page 12: Internal Wiring Diagram
TKH Security Proposal | RFP Name | RFP Number Internal wiring diagram * For the network cable connection, a user can choose either Network Connector wiring or RJ45 connector option depend on the cable wiring preferences. TKH Security | Siqura EX-PD24 | Installation manual... -
Page 13: Drill Template
TKH Security Proposal | RFP Name | RFP Number Drill template Safety hook Eye bolt TKH Security | Siqura EX-PD24 | Installation manual... -
Page 14: Getting Started
TKH Security Proposal | RFP Name | RFP Number Getting started To be able to find the camera, make sure your computers network card is set to the proper network settings: The default IP address of the camera is 192.168.30.220. By typing this address in your browser, you also get access to the web interface of the camera. -
Page 15: Access From A Browser
TKH Security Proposal | RFP Name | RFP Number Access from a browser Start a browser (Internet Explorer). Enter the given IP address or host name of the network camera in the Location/Address field of your browser. You can see a starting page. Click Live View, Playback, or Setup to enter web page. - Page 16 TKH Security Proposal | RFP Name | RFP Number tkhsecurity.com Brands Our Brands © 2020, TKH Security. © 2021, TKH Security B.V. TKH Security | Siqura EX-PD24 | Installation manual...
