Install The Unit - PowerWalker VFI ICT IoT Series User Manual

3.3 Install the Unit

Always keep 200 mm of free space behind the UPS rear panel.
Check that the indications on the name plate located on the top cover of the UPS
meets to the AC-power source and the true electrical consumption of the total load.
Note: The UPS charges the battery as soon as it is connected to the AC-power source,
even if button is not pressed.
Once the UPS is connected to the AC-power source, 8 hours of charging are required
before the battery can supply the rated backup time.
1. Connect the UPS input socket
to the AC-power source using
the cable of the protected
equipment.
2. Connect the loads to the UPS
using the cables.
11
