PowerWalker VFI ICT IoT Series User Manual page 13

RT 3K/3KS
RT 36V EBM
RT 72V EBM
1 WLAN(HDMI)
4 RPO/Dry in/Dry out
7 Slot Card Box
Input Socket/
10
Input Terminal
Programmable
13
Output Socket
2 USB
5 EBM auto detection
8 EBM Connector
Output Socket/
11
Output Terminal
8
3 Ethernet (RJ45)
6 RS232
9 Input Breaker(optional)
12 Output Fuse (optional)
