- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per PowerWalker VFI 1000 RMG PF1 o cerca il tuo prodotto tra le migliori offerte di Gruppi di Continuità PowerWalker VFI 1000-3000 RMG PF1 Uninterruptible Power Supply System Version: 1.3...
-
Page 2: Table Of Contents
Table of Contents 1. Important Safety Warning ................... 1 1-1. Transportation ....................1 1-2. Preparation ......................1 1-3. Installation ......................1 1-4. Operation ......................1 1-5. Maintenance, service and faults ................2 2. Installation and setup ..................4 2-1. Rear panel view ....................4 2-2. -
Page 3: Important Safety Warning
1. Important Safety Warning Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. -
Page 4: Maintenance, Service And Faults
1-5. Maintenance, service and faults The UPS system operates with hazardous voltages. Repairs may be carried out only by qualified maintenance personnel. Caution - risk of electric shock. Even after the unit is disconnected from the mains (building wiring outlet), components inside the UPS system are still connected to the battery and electrically live and dangerous. - Page 5 NPW45-12 12 V dc, 8.0 Ah Yuasa Battery (Guangdong) NPW45-12FR 12 V dc, 8.0 Ah Co Ltd (MH29616) For UPS with internally mounted battery Instructions shall carry sufficient information to enable the replacement of the battery with a suitable manufacturer and catalogue number. Safety instructions to allow access by Service Personnel shall be stated in the installation/service handbook.
-
Page 6: Installation And Setup
2. Installation and setup NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. 2-1. Rear panel view Tower Models IEC Type 1K/1.5K NEMA Type 1K/1.5K... -
Page 7: Operating Principle
RT Models IEC Type NEMA Type 1.5K 1. Programmable outlets: connect to non-critical loads. 2. Output receptacles: connect to mission-critical loads. 3. AC input 4. Network/Fax/Modem surge protection 5. USB communication port 6. RS-232 communication port 7. SNMP intelligent slot 8. -
Page 8: Install The Ups (Only For Rt Models)
2-3. Install the UPS (Only for RT Models) For safety consideration, the UPS is shipped out from factory without connecting battery wires. Before install the UPS, please follow below steps to re-connect battery wires first. Step 1 Step 2 Step 3 Remove front panel. - Page 9 2. Maintain an ambient temperature range of 0ºC to 45ºC for UPS optimal operation. For every 5ºC above 45ºC, the UPS will derate 12% of nominal capacity at full load. The highest working temperature requirement for UPS operation is 50ºC. 3.
-
Page 10: I Ntelligent Slot
Step 1: External battery connection Follow the right chart to make external battery connection. Step 2: UPS input connection Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords. For 200/208/220/230/240VAC models: The power cord is supplied in the UPS package. ... -
Page 11: Step 8: Install Software
Step 5: Network connection Netw ork/ Fax/ P hone surge port Connect a single modem/phone/fax line into surge-protected “IN” outlet on the back panel of the UPS unit. Connect from “OUT” outlet to the equipment with another modem/fax/phone line cable. Step 6: Disable and enable EPO function This UPS is equipped with EPO function. -
Page 12: Battery Replacement (Only For Rt Models)
2-5. Battery Replacement (Only for RT Models) NOTICE: This UPS is equipped with internal batteries and user can replace the batteries without shutting down the UPS or connected loads.(hot-swappable battery design) Replacement is a safe procedure, isolated from electrical hazards. CAUTION!! Consider all warnings, cautions, and notes before replacing batteries. -
Page 13: Battery Kit Assembly (Option For Rt Models)
2-6. Battery Kit Assembly (option for RT Models) NOTICE: Please assemble battery kit first before installing it inside of UPS. Please select correct battery kit procedure below to assemble it. 2-battery kit Step 1: Remove adhesive tapes. Step 2: Connect all battery terminals by following below chart. - Page 14 4-battery kit Step 1: Remove adhesive tapes. Step 2: Connect all battery terminals by following below chart. Tapes Tapes Step 3: Put assembled battery packs on Step 4: Cover the other side of plastic shell as one side of plastic shells. below chart.
-
Page 15: Operations
3. Operations 3-1. Button operation Button Function Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn on the UPS. Mute the alarm: After the UPS is turned on in battery mode, press and hold this button for at least 3 seconds to disable or enable the alarm ON/Mute system. - Page 16 Function Display Backup time information Indicates the estimated backup time. H: hours, M: minute, S: second. Configuration and fault information Indicates the configuration items, and the configuration items are listed in details in section 3-5. Indicates the warning and fault codes, and the codes are listed in details in section 3-7 and 3-8.
-
Page 17: Audible Alarm
3-3. Audible Alarm Battery Mode Sounding every 5 seconds Low Battery Sounding every 2 seconds Overload Sounding every second Fault Continuously sounding Bypass Mode Sounding every 10 seconds 3-4. LCD display wordings index Abbreviation Display content Meaning Enable Disable Escape High loss Low loss Active open... -
Page 18: Ups Setting
3-5. UPS Setting There are three parameters to set up the UPS. Parameter 1: It’s for program alternatives. Parameter 1 Parameter 2 Refer to below table. Parameter 2 is the setting options or values for each program. 01: Output voltage setting ... - Page 19 04: ECO enable/disable Interface Setting Parameter 2: Enable or disable ECO function. You may choose the following two options: ENA: ECO mode enable DIS: ECO mode disable (Default) 05: ECO voltage range setting Interface Setting Parameter 2: Set the acceptable high voltage point and low voltage point for ECO mode by pressing Down key or Up key.
- Page 20 170Vac to 220Vac. (Default: 170Vac) For 100/110/115/120/127 VAC models: 85-115: setting the low voltage point in parameter 3 from 85Vac to 115Vac. (Default: 85Vac) 08: Bypass frequency range setting Interface Setting Parameter 2: Set the acceptable high frequency point and acceptable low frequency point for Bypass mode by pressing the Down key or Up key.
- Page 21 12: Battery total AH setting Interface Setting Parameter 2: Set up the battery total AH of the UPS. 7-999: setting the battery total capacity from 7-999 in AH. Please set the correct battery total capacity if external battery bank is connected. 13: Maximum charger current setting ...
- Page 22 16: EPO logic setting Interface Setting Parameter 2: Set up the EPO function control logic. AO: Active Open (Default). When AO is selected as EPO logic, it will activate EPO function with Pin 1 and Pin 2 in open status. AC: Active Close.
-
Page 23: Operating Mode Description
00: Exit setting Interface Setting Exit the setting mode. 3-6. Operating Mode Description Operating mode Description LCD display Online mode When the input voltage is within acceptable range, UPS will provide pure and stable AC power to output. The UPS will also charge the battery at online mode. -
Page 24: Faults Reference Code
3-7. Faults Reference Code Fault event Fault code Icon Fault event Fault code Icon Bus start fail Battery voltage too high Bus over Battery voltage too low Bus under Charger output short Inverter soft start fail Over temperature Inverter voltage high Overload Inverter voltage Low Charger failure... -
Page 25: Troubleshooting
4. Troubleshooting If the UPS system does not operate correctly, please solve the problem by using the table below. Symptom Possible cause Remedy No indication and alarm even The AC input power is not Check if input power cord though the mains is normal. connected well. -
Page 26: Storage And Maintenance
Symptom Possible cause Remedy Fault code is shown as 14 on LCD The UPS shut down Check output wiring and if display and alarm is continuously automatically because connected devices are in sounding. short circuit occurs on the short circuit status. UPS output. -
Page 27: Specifications
6. Specifications Tower Models MODEL 1K 2B 1K 3B 1.5K 2K 4B 2K 6B CAPACITY* 1000VA/1000W 1500VA/1500W 2000VA/2000W 3000VA / 3000W INPUT 160VAC/140VAC/120VAC/110VAC ± 5 % or 80VAC/70VAC/60VAC/55VAC ± 5 % Low Line Transfer ( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0) - Page 28 RT Models: MODEL 1K RT-2B 1K RT-3B 1.5K RT 2K RT-4B 2K RT-6B 3K RT 3000VA / CAPACITY* 1000VA/1000W 1500VA/1500W 2000VA/2000W 3000W INPUT 160VAC/140VAC/120VAC/110VAC ± 5 % or 80VAC/70VAC/60VAC/55VAC ± 5 % Low Line Transfer ( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0) Low Line Voltage 175VAC/155VAC/135VAC/125VAC ±...
-
Page 29: Battery Pack Specification
Output Power Rating Table (only for 100/110/115/120/127 VAC system) Model name Input rating Output rating 1K 2B, 1K 3B, 1K RT-2B, 1K RT-3B 110-127Vac, 50/60Hz, 100/110/115/120/125/127Vac, 50/60Hz, 12A, 1Ø 1000VA/1000W, 1Ø, 10A 1.5K, 1.5K RT 110-127Vac, 50/60Hz, 100/110/115/120/125/127Vac, 50/60Hz, 1Ø...
