THROTTLE AND CHOKE CONTROL CABLE
(optional part)
The throttle and choke control levers are provided with holes for
optional cable attachment. The following illustrations show
installation examples for a solid wire cable and for a braided wire
cable. If using a braided wire cable, add a return spring as shown.
It is necessary to loosen the throttle lever friction nut when
operating the throttle with a remote cable.
THROTTLE LEVER
FRICTION NUT
FLEXIBLE WIRE
CORE MOUNTING
SOLID WIRE
CORE MOUNTING
4 mm SCREW
WIRE
5 mm CIRCLIP
WIRE HOLDER
5 mm CIRCLIP
28
RETURN SPRING
WIRE HOLDER
THROTTLE LEVER
