2.2 Notes

The symbols and notes below may appear in
Grundfos installation and operating instructions,
safety instructions and service instructions.
Observe these instructions for explosion-
proof products.
A blue or grey circle with a white graphical
symbol indicates that an action must be
taken.
A red or grey circle with a diagonal bar,
possibly with a black graphical symbol,
indicates that an action must not be taken
or must be stopped.
If these instructions are not observed, it
may result in malfunction or damage to
the equipment.
Tips and advice that make the work
easier.

2.3 Overview drawing

Outlet
port
Inlet
Fig. 1 Unilift AP B pump
4

3. Receiving the product

3.1 Inspecting the product

Check that the product received is in accordance
with the order.
Check that the voltage and frequency of the product
match the voltage and frequency of the installation
site.

3.2 Scope of delivery

The box contains the following items:
•
•
•
•

4. Installing the product

Handle
with clamp
Float
switch
CAUTION
Crushing of feet
Minor or moderate personal injury
- Wear safety shoes when handling
the product.
- Use the pump handle to move the
pump. Do not lift it by the power
cable.
pump
power cable
float switch, if included with this model
installation and operating instructions.
DANGER
Electric shock
Death or serious personal injury
- The installation, electrical
connection, and maintenance of
the product must be carried out by
an authorized electrician in
accordance with the National
Electrical Code and any state, local
governing codes and regulations.
DANGER
Electric shock
Death or serious personal injury
- Switch off the power supply before
starting any work on the product.
- Make sure that the power supply
cannot be accidentally switched
on.
DANGER
Electric shock
Death or serious personal injury
- Pump installation in a sump pit,
basin or tank must be carried out
by qualified, specially trained
persons in accordance with the
National Electrical Code and any
state, local governing codes and
regulations.
