7. WARNING: Emergency control or non-fire equipment cannot be connected on same circuitry as
fire alarm equipment.
Class A, Class B SW1 & SW2 Settings:
• For all Class B hookups SW1 and SW2 on the AL800LGK logic board must be turned OFF.
For all Class A hookups SW1 and SW2 on the AL800LGK logic board must be turned ON.
Function
Input to Output
Follower Mode
Temporal Code 3 Mode
Steady Mode
For the above modes DIP Switch 4 determines which Input controls the
corresponding output:
Switch 4 in the ON position causes output(s) to be controlled by Input 1.
Switch 4 in the OFF position causes output(s) to be controlled by Input 2.
Function
Amseco
Sync Mode*
®
Gentex
Sync Mode*
Gentex is a registered
trademark of
Gentex Corporation.
®
System Sensor
Sync Mode*
System Sensor is a
registered trademark
of Honeywell.
®
CooperWheelock
Sync Mode*
CooperWheelock is a
registered trademark
of
Cooper Wheelock.
*Note: AL802ULADAJ will only synchronize horns, horn/strobes and strobes that contain synchronization capabil-
ity. The same synchronization mode must be selected for all outputs
NOTE: It is required to control visual notification appliances (strobes) via Input 1 (IN1) and audible
notification appliances (horns) via Input 2 (IN2). This allows audible notification appliances (horns) and
visual notification appliances (strobes) to be silenced/ deactivated at same time.
AL802ULADAJ Installation Guide

Output Programming Selection Table:

Outputs must be programmed independently (OUT1 - OUT4)
Switch Positions
ON OFF
1 2, 3
3 1, 2
1, 2, 3

Sync Mode Selection Table:

Switch Positions
ON OFF
1, 3,
2
4
1, 2,
3, 4
1, 2, 4 3
2, 3, 4 1
Descriptions
Output follows signal it receives from the corresponding
input (i.e. FACP Sync module - maintains synchronization of
notification appliance circuit).
Enables Temporal Code 3 signal generation output.
This mode will accept a steady or a pulsing input.
A steady output signal will be generated.
This mode will accept steady or pulsing input.
Descriptions
This mode is designed to work with the Amseco series of horns, strobes,
and horn/strobes to provide a means of synchronizing the Temporal-
coded horns, synchronizing the flash timing of the strobe, and allowing
audible notification appliances (horns) and visual notification appliances
(strobes) to be silenced/ deactivated at the same time.
This mode is designed to work with the Gentex
strobes, and horn/strobes to provide a means of synchronizing the
Temporal-coded horns, synchronizing the flash timing of the strobe,
and allowing audible notification appliances (horns) and visual notifica-
tion appliances (strobes) to be silenced/ deactivated at the same time.
This mode is designed to work with the System Sensor
horns, strobes, and horn/strobes to provide a means of synchronizing
the Temporal-coded horns, synchronizing the one-second flash timing
of the strobe, and allowing audible notification appliances (horns) and
visual notification appliances (strobes) to be silenced/ deactivated at
the same time.
This mode is designed to work with the CooperWheelock series of
horns, strobes, and horn/strobes to provide a means of synchronizing
the Temporal-coded horns, synchronizing the one-second flash timing
of the strobe, and allowing audible notification appliances (horns) and
visual notification appliances (strobes) to be silenced/ deactivated at
the same time.
AL800LGK9E Board
Output DIP Switches
INPUT SELECT
TEMPORAL
STROBE SYNC
IN>OUT SYNC
®
series of horns,
®
series of
