Placement and Maintenance
Your Duo Pedestal Desk is designed for indoor use on level floors.
Clean wood veneer and steel parts with a moist cloth and clean glass
with glass cleaner.
Duo is engineered for easy assembly. Carefully follow this procedure
to prevent any damage. Do not use power tools for assembly of this
product.
Step 1
Unpack and identify the parts listed below. The assembly workspace
should be a non-marring surface such as carpet. For missing hardware
pieces, contact BDI Customer Service at: customerservice@bdiusa.
com.
For all other concerns, please contact your BDI retailer.
C1 Leg Plate x 1
A1 Leg x 1
C2 Foot x 1
Designed by Matthew Weatherly.
These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws.
Duo & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2017, BDI
Made in China. 7.11.2017 V4
DUO
6241
TM
PEDESTAL DESK
C5 Back Panel x 1
bdiusa.com
customerservice@bdiusa.com
Tool Required:
Phillips screwdriver
Tool Provided:
T1 Hex Wrench x 1
H1 1/4-20 x 32 mm
Flat Head Machine Screw x 4
H2 1/4-20 x 25 mm
Flat Head Machine Screw x 2
H3 M6 x 20 mm
Machine Screw x 4
H4 1/4-20 x 13 mm Flat
Head Machine Screw x 12
H5 M4 x 38mm Machine
Screw x 6
C6 Glass Top x 1
A2 Desk Assembly x 1
C3 Cabinet Bracket x 1
A3 Cabinet x 1
C7 Drawer Pull x 3
C8 File Bar Clip x 2
C9 Small File Bar x 1
Advertisement
Table of Contents
Related Manuals for BDI DUO 6241
Summary of Contents for BDI DUO 6241
- Page 1 C5 Back Panel x 1 Designed by Matthew Weatherly. These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Duo & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2017, BDI Made in China. 7.11.2017 V4...
- Page 2 Carefully position the desk assembly A2 upside down. Remove the flat panel but keep the 6 screws for steps 4-5. Attach leg A1 into recessed square area using screws H3 (x4) and hex wrench. Remove this panel and keep the 6 screws for following steps. H3 x 4 bdiusa.com DUO 6241 customerservice@bdiusa.com PEDESTAL DESK...
- Page 3 Position front of cabinet towards "L" for left-hand orientation or "R" for right-hand orientation. 2 Person Task H4 x 6 Cabinet may also be positioned on the left side of desk. Right Hand Orientation Shown bdiusa.com DUO 6241 customerservice@bdiusa.com PEDESTAL DESK...
- Page 4 Install the back panel C5 by inserting the top edge into the upper groove, and inserting bottom edge into the lower groove. Power cords may be routed through the mouse holes on the top and bottom edge of back panel. Wire pass-through holes bdiusa.com DUO 6241 customerservice@bdiusa.com PEDESTAL DESK...
- Page 5 With the help of another person, carefully lower glass top C6 onto the desk assembly. Step 9 - Attach Drawer Pulls Open each drawer and install the drawer pulls C7 (x3) using screws H5 (x6) and a Phillips Screwdriver. bdiusa.com DUO 6241 customerservice@bdiusa.com PEDESTAL DESK...
- Page 6 For letter files facing sideways, attach file bar clip C8 to both ends of small file bar C9 as shown. Place the file bar assembly in the notches located on the left and right drawer side panels. For front facing letter files, skip this step altogether. Step 11 - Legal File Accommodation bdiusa.com DUO 6241 customerservice@bdiusa.com PEDESTAL DESK...
