CASCADIA is designed for indoor use on level floors.
Component List
CASCADIA are engineered for easy assembly. Carefully follow this procedure to prevent any damage.
Unpack and identify the components. The assembly workspace should be a non-marring surface such as clean carpet.
For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com.
For all other concerns, please contact your BDI Retailer.
Designed by Matthew Weatherly
These distinctive product configurations are protected by US and international
patents, trade dress, and/or copyright laws.
BDI are trademarks of Becker Designed, Inc.
All Rights reserved. © 2016 BDI
6201 6202 Revision: 05-05-16
CASCADIA
6201 6202
CASCADIA 6201 Desk
A - 4mm Hex Driver x 1
B - 5/16-18 x 50mm Screws
4mm Socket Drive
6201 x 8
6202 x 6
C - 1/4-20 x 12mm Screws
4mm Socket Drive
x 4
D - Table Assembly x 1
E - Left Leg x 1
F - Right Leg x 1
G - Horizontal Bar x 1
BDIUSA.COM
CASCADIA 6202 Console
C
B
E
1
ASSEMBLY INSTRUCTIONS
CUSTOMERSERVICE@BDIUSA.COM
D
G
B
F
C
