  • Page 1 SEQUEL 20 6112 ® RETURN INSTRUCTION MANUAL LET’S GET STARTED. DESIGN MATTHEW WEATHERLY...
  • Page 3 Congratulations on the purchase of your Sequel 20 Return 6112 from BDI. Your return has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information that will ensure that you get the most out of your return.
  • Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for assembly of this product.
  • Page 5 HARDWARE AND COMPONENTS PART # PART # DESCRIPTION DESCRIPTION Leg Frame Top Frame QUANTITY QUANTITY PART # PART # DESCRIPTION DESCRIPTION Connector Plate Top Panel QUANTITY QUANTITY NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 5...
  • Page 6 Install (H4) Levelers into the bottom of (C1) Leg Frame. PART/DESCRIPTION H4-LEVELER ASSEMBLY STEP 2. INSTALL TOP FRAME Connect (C1) Leg Frame to (C2) Top Frame using 4 (H1) Screws and tighten with (T1) Hex Wrench. PART/DESCRIPTION T1-HEX WRENCH H1-SCREW 6 | BDIUSA.COM SEQUEL 20 6112...
  • Page 7 STEP 3. INSTALL CONNECTOR PLATE ASSEMBLY The return may be attached to either a desk or a cabinet. IF ATTACHING TO A DESK— PART/DESCRIPTION COMPATIBLE WITH 6101, 6102: Connect the (C3) Connector Plate to the T1-HEX WRENCH underside of (C2) Top Frame using 2 (H2) Flathead Screws and (T1) Hex Wrench.
  • Page 8 Partially thread 1 (H3) Screw into the middle insert leaving it extended out 1/4" H3-SCREW (6mm) to allow (C3) Connector Plate to slide into the space between the screw head and bottom of the desk. 1/4" (6mm) gap 8 | BDIUSA.COM SEQUEL 20 6112...
  • Page 9 STEP 5. ATTACH THE RETURN ASSEMBLY Slide the notch on (C3) Connector Plate onto PART/DESCRIPTION the partially threaded middle screw. Tighten the screw with (T1) Hex Wrench. T1-HEX WRENCH Insert (H2) Flathead Screws into the left and PART/DESCRIPTION right holes on the (C3) Connector Plate and tighten with (T1) Hex Wrench.
  • Page 10 (C4) Top T1-HEX WRENCH Panel. Make sure the gap between desk glass and return glass is even, then tighten with (T1) Hex Wrench. H3-SCREW 10 | BDIUSA.COM SEQUEL 20 6112...
  • Page 11 STEP 7. INSTALL TOP PANEL ASSEMBLY The return may be attached to the left or right PART/DESCRIPTION side of the following cabinets: 6114 3 Drawer File Pedestal T1-HEX WRENCH 6116 Lateral File 6117 Multi-Function Cabinet—shown below First, remove the glass top from the cabinet. H2-FLATHEAD SCREW Attach the (C3) Connector Plate to the cabinet using (H2) Flathead Screws going through the...
  • Page 12 (C4) Top T1-HEX WRENCH Panel. Make sure the gap between desk glass and return glass is even, then tighten with (T1) Hex Wrench. H3-SCREW 12 | BDIUSA.COM SEQUEL 20 6112...
  • Page 13: Care And Maintenance

    While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid positioning your BDI cabinet in any area with extensive direct sunlight.
  • Page 14: Warranty

    WARRANTY BDI warrants to the original purchaser that for the below stated warranty term, BDI will repair or replace any product, part, or component covered by this warranty which fails under normal use as a result of a defect in material or workmanship. BDI will repair or replace the aforementioned product, part or component with a comparable product, part or component.
  • Page 15 NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 15...
  • Page 16 These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Sequel & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2020, BDI | V.08.21.2020 Made in Vietnam.
