BDI 8239 Assembly Instructions

NORA
8239
Component List
A - Phillips Screwdriver
B - 4mm Hex Wrench
C - Dowel Pin x 2
D - 1/4-20 x 1.75"
Machine Screw x 2
E - Center Leg x 1
F - Leg Assembly
G - Rail x 1
H - 1/4-20 x 3.25"
I - Assembled Cabinet
J - Adjustable Shelf
K - Back Panel x 2
Designed by Al Glass and Matthew Weatherly.
international patents, trade dress, and/or copyright laws.
BDI are trademarks of Becker Designed, Inc.
All Rights reserved. ©2011, BDI
Made in China. 3102412v3
8239-S
AND
Nora is engineered for easy assembly. Carefully follow this
procedure to prevent any damage.
x 1
NOTE: This instruction sheet is intended for the entire Nora
collection; model 8239 is shown for illustration.
x 1
Placement and Maintenance
Nora is designed for indoor use on level floors. Clean glass with
glass cleaner; steel parts and wood veneer with a moist cloth.
Step 1
Unpack and Identify
Unpack and identify the components at left. Note that some
components are shipped inside the cabinet. The assembly
workspace should be a non-marring surface such as carpet. For
missing hardware pieces, please contact BDI Customer Service
x 2 at customerservice@bdiusa.com. For all other concerns, please
contact your BDI Retailer.
Step 2
Remove Pre-Installed Adjustable Shelves (J)
Machine Screw x 10
x 1
x 2
