H-5526
ÉTAGÈRE
TOOLS NEEDED
Allen Wrench
Allen Wrench
(Included)
(Included)
Top Board
Frame Screw x 16
NOTE: Do not fully tighten screws until all screws
are aligned in place.
1. Attach top end of side frames to top board using
four washers and top screws and the enclosed Allen
wrench. (See Figure 1)
PAGE 1 OF 6
1-800-295-5510
uline.com
PARTS LIST
Bottom Board
Base Screw x 8
Top Screw x 4
ASSEMBLY
Figure 1
Pour le français, consulter les pages 5-6.
Shelf x 3
Washer x 12
2. Align holes at the bottom of the side frames with the
holes in the bottom of the bottom board. Attach side
frames to bottom board using two frame screws on
each side with the enclosed Allen wrench.
(See Figure 2)
Figure 2
Para Español, vea páginas 3-4.
Side Frame x 2
0521 IH-5526

Advertisement

loading

Related Manuals for U-Line H-5526

Summary of Contents for U-Line H-5526

  • Page 1 Para Español, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-5526 1-800-295-5510 uline.com ÉTAGÈRE TOOLS NEEDED Allen Wrench Allen Wrench (Included) (Included) PARTS LIST Shelf x 3 Top Board Bottom Board Frame Screw x 16 Base Screw x 8...
  • Page 2 ASSEMBLY CONTINUED 3. To secure assembled frame, attach two base screws 4. Stand unit upright and set each shelf at the and washers into each corner with the enclosed preferred height on top of the side frame bars. Align Allen wrench, as illustrated. (See Figure 3) holes on each shelf with holes in the side frame bars.

  • Page 3: Lista De Partes

    H-5526 800-295-5510 uline.mx ÉTAGÈRE HERRAMIENTAS NECESARIAS Llave Allen Llave Allen (Incluida) (Incluida) LISTA DE PARTES Tablero Superior Tablero Inferior 3 Repisas 2 Armazones 8 Tornillos de Base 12 Rondanas 16 Tornillos de Armazón 4 Tornillos Superiores ENSAMBLE NOTA: No apriete completamente los tornillos 2.
  • Page 4 CONTINUACIÓN DE ENSAMBLE 3. Asegure el armazón ensamblado, fijándolo como 4. Coloque la unidad en posición vertical y ponga se ilustra con dos tornillos de base y rondanas en cada repisa a la altura deseada sobre las barras cada esquina con la llave Allen que se incluye. de los armazones.

  • Page 5: Liste Des Pièces

    H-5526 1-800-295-5510 ÉTAGÈRE uline.ca OUTILS REQUIS Clé Allen Clé Allen (comprise) (comprise) LISTE DES PIÈCES Plateau supérieur Plateau inférieur Tablette x 3 Cadre latéral x 2 Vis de cadre x 16 Vis de base x 8 Vis pour plateau x 4 Rondelle x 12 MONTAGE REMARQUE : Ne serrez pas les vis 2.
  • Page 6 MONTAGE SUITE 3. Pour fixer l'ensemble du cadre, insérez deux vis de 4. Placez l’unité à la verticale et déposez chaque base et rondelles dans chaque coin et fixez-les à tablette sur les barres des cadres latéraux, à la l'aide de la clé Allen fournie, comme illustré. hauteur souhaitée.
