Summary of Contents for Advantech MIC-3612/3-BE
- Page 1 User Manual MIC-3612/3-BE...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
- Page 4 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
- Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 6 Don't touch any components on the CPU card or other cards while the PC is on. Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive elec- tronic components. MIC-3612/3-BE User Manual...
-
Page 7: Table Of Contents
Table 4.2: Interrupt Source And Priority Level......18 Table 4.3: Transmit and Receive FIFO Trigger Table And Level Selection..............19 Table 4.4: .................. 20 Table 4.5: .................. 20 Table 4.6: .................. 20 Table 4.7: .................. 20 Table 4.8: Parity Selection............20 MIC-3612/3-BE User Manual... - Page 8 MIC-3612/3-BE User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information... -
Page 10: Introduction
Operating temperature: 0 ° C ~ 70 ° C (referring to IEC68-2-1, 2) Operating Humidity: 5 ~ 95% Relative Humidity, non-condensing (referring to IEC 68-2-1, 2) Operating Humidity: 5 ~ 95% Relative Humidity, non-condensing (referring to IEC 68-2-3) Storage Temperature: -20 ~ 80 ° C MIC-3612/3-BE User Manual... -
Page 11: Chapter 2 Hardware Configuration
Chapter Hardware Configuration This chapter gives users a pack- age item checklist, proper instruc- tions about unpacking and step- by-step procedures for card installation. -
Page 12: Initial Inspection
Avoid touching the exposed circuit connectors. We also recommend that you use a grounded wrist strap and place the card on a static dissipative mat whenever you work with it. MIC-3612/3-BE User Manual... -
Page 13: Hardware Installation
6, the system can configure the card automatically, and the Blue LED is turned off when the system finished the device con- figuration. If the system power is off, you can install the card step by step without attending Blue LED’s state. MIC-3612/3-BE User Manual... -
Page 14: I/O Address
Once the system finished the device configuration, the Blue LED on the front panel will turn on. Now you can slide the card out. Note! Advantech MIC-3612’s “Hot-Swap”function complies with CPCI Hot Swap Specification PICMG 2.1 R2.0. Note! Because of the “Hot-Swap”, the above steps detail the card removal pro- cess while the system is on. -
Page 15: Board Layout: Dimensions
1 and 2 or 2 and 3. You may find a pair of needle-nose pliers for setting the jumpers. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes. Figure 2.2 Jumper setting example MIC-3612/3-BE User Manual... -
Page 16: Default Settings
For RS-485 operation mode, users will have to use the following list to set the jumpers. Jumper group CN4(CN5,CN6,CN7) for Port 1 (2,3,4) to the RS-422/485. Jumper JP10(JP11,JP12,JP13)for Port 1(2,3,4) to the RS-485. DIP switch SW1 have to switch to “AUTO” for RS-485 mode AUTO AUTO AUTO AUTO MIC-3612/3-BE User Manual... - Page 17 For RS-422 Slave mode, the RS-422 Tx signal will be auto-enabled to send the data. To set this mode, users will have to use the following list to set the jump- ers. Jumper group CN4(CN5,CN6,CN7) for Port 1 (2,3,4) to the RS-422/485. Jumper JP10(JP11,JP12,JP13) for Port 1(2,3,4) to the RS-422. MIC-3612/3-BE User Manual...
-
Page 18: Terminator Resistor Setup (Jp2~Jp9)
The 66MHZ_ENABLE pin indicates to a device whether the bus segment is operating at 66 or 33 MHz. However, MIC-3612 can only operate at 33MHz limited by FPGA model. By default, the jumper CN2 is closed, that indicates bus segments are limited to 33MHz. MIC-3612/3-BE User Manual... -
Page 19: Chapter 3 Pin Assignment & Wiring
Chapter Pin Assignment & Wiring... -
Page 20: Pin Assignments
Table 3.2: RS232 Mode DB9 Male Connector Description Signal Name Pin# Mode Ground Transmit Data Output Data Terminal Ready Output Request To Send Output Receive Data Input Data Set Ready Input Clear To Send Input Data Carrier Detect Input Ring Indicator Input MIC-3612/3-BE User Manual... -
Page 21: Rs-485 Mode
DATA0+ DATA0- DATA1+ DATA1- DATA2+ DATA2- DATA3+ DATA3- The Table 3-2 is the description of DB9P male connector. Table 3.4: RS-485 Mode DB9P Male Connector Description Signal Name Pin# Ground DATA- Transmit Data DATA+ Data Terminal Ready MIC-3612/3-BE User Manual... -
Page 22: Rs-422 Mode
Pin No. Signal Pin No. Signal TX0+ RTS0+ TX0- RTS0- RX0+ CTS0+ RX0- CTS0- TX1+ RTS1+ TX1- RTS1- RX1+ CTS1+ RX1- CTS1- TX2+ RTS2+ TX2- RTS2- RX2+ CTS2+ RX2- CTS2- TX3+ RTS3+ TX3- RTS3- RX3+ CTS3+ RX3- CTS3- MIC-3612/3-BE User Manual... - Page 23 Table 3.6: RS-422 Mode DB9 Male Connector Description Signal Name Pin# Ground Transmit Data+ Transmit Data- Receive Data+ Receive Data- RTS+ Request To Send+ RTS- Request To Send- CTS+ Clear To Send+ CTS- Clear To Send- Figure 3.3 MIC-3612 DB44 Connector RS-422 Mode MIC-3612/3-BE User Manual...
- Page 24 MIC-3612/3-BE User Manual...
-
Page 25: Chapter 4 Register Structure
Chapter Register Structure... -
Page 26: Register Structure
LSR (Receiver Line Status Register) 001100 RXRDY (Receive Data Time-out) 000100 RXRDY (Receive Data Ready) 000010 TXRDY (Transmit Ready) 000000 MSR (Modem Status Register) 010000 RXRDY (Received Xoff or Special character) 100000 CTS#, RTS# change of state 000001 None (default) MIC-3612/3-BE User Manual... - Page 27 01xx 10xx 11xx xx00 xx01 xx10 xx11 Table-B 00xx 01xx 10xx 11xx xx00 xx01 xx10 xx11 Table-C 00xx 01xx 10xx 11xx Programmable via TRG Programmable via TRG Table-D xxxx register. FCTR[7] = 0 register. FCTR[7] = 1 MIC-3612/3-BE User Manual...
- Page 28 Word Length Stop bit Length (Bit Time(s)) 5,6,7,8 1(default) 1-1/2 6,7,8 Table 4.8: Parity Selection Bit5 Bit4 Bit3 Word Length (bits) No Parity Odd Parity Even Parity Force parity to mark, “1” Force parity to space, “0” MIC-3612/3-BE User Manual...
- Page 29 Bit 0 Delta CTS Bit 1 Delta DSR Bit 2 Delta RI Bit 3 Delta CD Bit 4 CTS Bit 5 DSR Bit 6 RI Bit 7 CD BASE+7 SPR Temporary data register and indexed control Register offset value bits MIC-3612/3-BE User Manual...
- Page 30 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2017...
