6U-sized Rear Transition Board
for CompactPCI
The MIC-3302 is a CompactPCI 6U-sized rear transition board. It
provides access to the rear panel for the I/O function on
Advantech's CompactPCI CPU board. The MIC-3302 has two
versions, the MIC-3302 and MIC-3302F.
Optin
COM
Model
MIC-3302
1
MIC-3302F
2
Ethernet: Two LAN ports with RJ-45 connectors
VGA connector: One DB-15 VGA connector
Serial port: One/Two DB-9 RS-232 ports
USB interface: One/Two USB connectors
SCSI interface: Internal 68-pin SCSI connector and optional
external 68-pin SCSI connector
USB
External SCSI On-board HDD
1
-
2
Yes
Width
-
1-slot
Yes
2-slot
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Advantech MIC-3302
Summary of Contents for Advantech MIC-3302
- Page 1 6U-sized Rear Transition Board for CompactPCI The MIC-3302 is a CompactPCI 6U-sized rear transition board. It provides access to the rear panel for the I/O function on Advantech’s CompactPCI CPU board. The MIC-3302 has two versions, the MIC-3302 and MIC-3302F.
- Page 2 EIDE interface: Handles two on-board IDE channels, con- nects up to four IDE drives FDD interface: Supports one on-board floppy connector, connects up to two floppy disk drives CompactFlash™ interface: Supports one on-board CompactFlash™ socket Keyboard connector: One 6-pin mini-DIN connector on rear panel Mouse connector: One 6-pin mini-DIN connector on rear panel Board size: 233.35 x 80 mm (6U), one/two-slot (8TE) wide...
- Page 3 The MIC-3302 provides jumpers and connectors for users spe- cific applications. SCSI LAN1 LAN2 COM2 CN16 CN22 CN14 CN15 CN17 USB1 USB2 CN12 CN24 CN16 COM1 CN13 JP1:CompactFlash Selection CN21 1. : Master CN11 2. : Slave...
- Page 4 Number Function CompactFlash™ master/slave selection LAN 1 connector LAN 2 connector VGA connector On-board internal SCSI connector SCSI connector Floppy disk connector PS/2 mouse connector CN10 COM1 port CN11 44-pin primary IDE connector CN12 40-pin secondary IDE connector CN13 CompactFlash™ socket CN14 COM2 port CN15...
- Page 5 Note: CN11 and CN24 are all primary IDE channels but in different connector form factors. While connecting IDE drives on both (CN11 and CN24) connectors, please remember to set one as the master and the other one as the slave.
- Page 6 #HCS3 #HIOR HIRQ #HACK HDA2 #HIOW #HRST1 HRDY #HCS1 HDA0 HDA1 S66DET KDAT KCLK MDAT MCLK P66DET #DSKCHG #MOA #STEP #HEAD #TRAK0 #DSA #MOB #RWC #RDATA #WP #INDEX #DSB #DIR # : Low active Note: The MIC-3302 supports DMA/66 HDD.
- Page 7 Row A Row B Row C Row D Row E LANTX-2 LANTX- USBV1 USBV0 UD1+ LANTX+2 LANTX+ N/A UD1- UD0- UD0+ LANRX-2 LANRX- N/A COMDTR2 LANRX+2 LANRX+ N/A COMRTS2 COMCTS2 COMTX2 COMLSD2 COMDSR2 COMRI2 COMRX2 12-14 Key Area FFVFC PDDCCLK PDDCDAT PEDGE TX2+ TX2-...
- Page 8 Row A Row B Row C Row D Row E LANRX+ LANRX- LANTX+ LANTX- LANRX+2 LANTX+2 LANTX-2 LANRX-2 SDP+1 SD+12 SD+14 SD-14 SDP-1 SD-12 SD+13 SD-13 SD+15 SD-15 DIFS AUTO TPWEX SD+0 SD-0 SD-5 SD+5 SD+2 SD-1 SD+1 SD+6 SD-6 SD-2 SD+3 SD-3...
