  • Page 1 MIC-3451/MIC-3451H 6U-sized, 8-slot Backplane for CompactPCI ®...
  • Page 2 PCI Industrial Computers Manufacturers Group PXI is a trademark of National Instruments Corporation. All other product names or trademarks are properties of their respective owners. Part Number: 2003345100 1st Edition Printed in Taiwan April 1999 MIC-3451/MIC-3451H User's Manual...
  • Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period.
  • Page 4 Technical Support and Sales Assistance If you have any technical questions about the MIC-3451/MIC-3451H or any other Advantech products, please visit our support website at: • http://support.advantech.com.tw For more information about Advantech's products and sales informa- tion, please visit: •...

  • Page 5: Table Of Contents

    Contents 1 Introduction ................1 1.1 General Information ................2 1.2 Features ....................2 1.3 Specification ..................3 2 Hardware Configuration ............5 2.1 Connector Locations ................6 2.2 Slot Assignment .................. 9 2.3 IDE Interface (CN1 and CN3) ............13 2.4 Floppy Disk Interface (CN4) ..............
  • Page 6 Connector Pin Assignments of 1-P3 ......13 Table 2-6. CN2 Connector Pin Assignments ....... 14 Table 2-7. CN5 Connector Pin Assignments ....... 15 Table 2-8. Power Module Connector .......... 16 Table 2-9. External Power Supply Terminal ......19 MIC-3451/MIC-3451H User's Manual...

  • Page 7: Introduction

    Introduction...

  • Page 8: General Information

    IEC 603-2 (DIN 41612) connectors to accept two ATX power supplies or two 3U size plug-in power modules. The MIC-3451/MIC-3451H provides a 6-pin connector for connect- ing to up to 4 cooling fans. A 20-pin connector can be used for connecting an external alarm module (MIC-3920/MIC-3921) to detect system internal conditions, such as bus voltages and fan speed.

  • Page 9: Specification

    20-pin connector for MIC-3920/MIC-3921 alarm board signals Two IDE and one FDD connectors (routed to P3 connector, support- ing Advantech’s 6U processor module) Complies with CompactPCI Specification PICMG 2.0, Ver.2.1 Complies with CompactPCI Hot Swap Specification PICMG 2.1, Ver.1.0 (MIC-3451H)
  • Page 10 MIC-3451/MIC-3451H User's Manual...

  • Page 11: Hardware Configuration

    Hardware Configuration...

  • Page 12: Connector Locations

    P h ysica l S lo t N u m b e r S yste m S lo t P e rip h era l S lo t Figure 2-1. The connector locations on the front side MIC-3451/MIC-3451H User's Manual...
  • Page 13 C N 1 C N 3 JP 1 C N 11 C N 12 C N 10C N 5 C N 4 C N 2 ATX P W 2 ATX P W 1 Figure 2-2. The connector locations on the rear side Chapter 2 Hardware Configuration...

  • Page 14: Table 2-1. Connector Assignments

    Floppy Drive Interface Connector Fan Module Connector CN6~CN9 Plug-in Power Module Connectors CN10 Power Switch Connector CN11 and CN12 Peripheral Power Connectors V I/O Voltage Selection Jumper ATXPW1 and ATXPW2 ATX Power Connectors T1~T10 Power Inlet and Ground Screw Terminals MIC-3451/MIC-3451H User's Manual...

  • Page 15: Slot Assignment

    Table 2-2 shows the system slot to peripheral slot relationships on the MIC-3451/MIC-3451H. Physical slot 8 (system slot) has a logical number 1, physical slot 7 has a logical number 2, physical slot 6 has a logical number 3, ..., and physical slot 1 has a logical number 8.

  • Page 16: Table 2-2. System To Peripheral Slot Signal Assignment

    Peripheral Slot 1, (Logical slot 8) CLK4 P2:A3 P1:D6 AD25 P1:D8 IDSEL P1:B9 REQ6# P2:D17 REQ# P1:A6 GNT6# P2:E17 GNT# P1:E5 * MIC-3451H clock definitions and pin locations are in the parenthe- ses. Please refer to section 2-9 Clock Routing Configuration. MIC-3451/MIC-3451H User's Manual...

  • Page 17: Table 2-3. Connector Pin Assignments Of P1 And P2 (System Slot)

    Table 2-3. Connector Pin Assignments of P1 and P2 (System Slot) GND GA4 GND CLK6 GND CLK5 GND GND GND *PXI_TRIG3 *PXI_TRIG4 *PXI_TRIG5 *PXI_TRIG6 GND *PXI_TRIG2 PRST# REQ6# GNT6# GND *PXI_TRIG1 *PXI_TRIG0 DEG# *PXI_TRIG7 GND *PXI_BRSVA15 GND FAL# REQ5# GNT5# GND AD[35] AD[34] AD[33]...

  • Page 18: Table 2-4. Connector Pin Assignments Of P1 And P2 (Peripheral Slot)

    GND 5V -12V TRST# +12V = long pins = short pins = medium length pins ® *: Optional signals for PXI star trigger signals #: Low active Note: GA[4...0] shall be used for geographic addressing on the backplane MIC-3451/MIC-3451H User's Manual...

  • Page 19: Ide Interface (Cn1 And Cn3)

    The CN1 and CN3 connectors are routed to the 1-P3 connector for connection of IDE devices such as hard disk drives and CD-ROM drives. When using Advantech’s 6U-sized processor module, users can connect IDE devices to the backplane, instead of direct cabling to the processor board.

  • Page 20: Floppy Disk Interface (Cn4)

    2.4 Floppy Disk Interface (CN4) The CN4 connector is routed to the 1-P3 connector for connecting floppy disk drives. With Advantech’s 6U-sized processor module, users can connect floppy disk drives to the backplane, instead of direct cabling to the processor board. This shortens the MTTR for replacing the processor board.

  • Page 21: Fan Module Connector (Cn5)

    2.6 Fan Module Connector (CN5) The CN5 connector provides +12 V power for fan operation and accepts the tachometer output from the fans. It accepts up to four fan signals. Table 2-7. CN5 Connector Pin Assignments Pin Assignment +12V FAN1 FAN2 FAN3 FAN4...

  • Page 22: Table 2-8. Power Module Connector

    3.3V +12V -12V Column B 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V +12V -12V Column C DEG# Power Module Connector FAL# Pin Locations 3.3V 3.3V 3.3V +12V -12V Note: Pin numbers illustrated are of the female backplane connector MIC-3451/MIC-3451H User's Manual...
  • Page 23 2.7.5 V I/O Voltage Selection (JP1) This jumper is used to select the V I/O voltage. MIC-3451/ MIC-3451H allows V I/O to be set to either 5 V or 3.3 V. Connect the two pins labeled “+5 V” with a cap to set V I/O to 5 V , and connect the two pins labeled “+3.3 V”...
  • Page 24 2.7.7 Screw terminal for external power supply Along the upper and lower edges of the MIC-3451/MIC-3451H are 20 power pads providing external power supply I/O. Pads S1~S20 facilitate input or output of the different powers and grounds. Con- tact Advantech for installation help.

  • Page 25: Table 2-9. External Power Supply Terminal

    Table 2-9. External Power Supply Terminal Name CHS_GND +3.3V -12V +12V CHS_GND +3.3V +3.3V Chapter 2 Hardware Configuration...

  • Page 26: Ground Configuration

    2.8 Ground Configuration Along the top and bottom of the MIC-3451/MIC-3451H are 24 mounting holes. The holes are arranged in an alternating pattern of chassis (frame) grounded pads and logic grounded pads. The square pad holes are connected to chassis ground, and the round pad holes are connected to logic ground.

  • Page 27: Clock Routing Configuration

    0 Ω resistors, the clock routing can be reconfigured to comply with the earlier CompactPCI Specification, PICMG 2.0, version 2.1. Reconfiguring the backplane to comply with this earlier specifica- tion allows the MIC-3451 to be backward compatible with CPUs using shared clocks. Individual Clock CPUs (MIC-3451H)
  • Page 28 R 11 R 1 0 Figure 2-5. Configuration Resistors Locations MIC-3451/MIC-3451H User's Manual...
