RECESSED INSTALLATIONS

As a base, create a reinforced concrete recess having
a thickness of at least 10 cm, perfectly flat and able to
support the weight of the minipool and the people using
it (the Manufacturer recommends a minimum load of
485 kg/m ). In any case contact a qualified construction
2
engineer to calculate the appropriate load for the
installation site.
Wedges or shims cannot be placed under the
minipool to level it.
Remember to ground the structural reinforcement
in accordance with electrical codes.
Prepare:
A A technical inspection
•
on all sides of the minipool. This will make future
maintenance or repairs easier.
B Drainage grating around the perimeter and in
•
the recess to help preserve the equipment and the
structure (even for indoor installations).
C A non-slip flooring around the minipool.
•
D Two Ø15 cm vents to ensure proper ventilation and
•
extraction of the heat and moisture from the technical
compartment.
FOR THE RECESSED OUTDOOR INSTALLATIONS, to
avoid damage due to freezing we recommend insulating
E the minipool recess. This procedure prevents
excessive condensation that over time cause odours and
damage to all major internal components. The choice of
D
2 Ø15 cm vents to ensure
proper ventilation of the
technical compartment
See the plumbing and
electrical preparations on
page 11 and 15.
A
Technical compartment for
maintenance of operational
components: plan for 50 cm
on all sides of the minipool
CONCRETE SLAB h. 10 cm minimum
port* at least 50 cm wide
EN
materials and thickness should be based on the minimum
temperatures reached in the country of installation.
For the preparation of the water and electrical
connections see the pertinent section on page
11 and 15.
*If it was not possible to provide a technical inspection port
on all sides of the minipool, a pneumatic lift is available
(optional - to be requested from the Manufacturer) in order to
simplify future maintenance operations. It is recommended to
provide a removable inspection hatch "A" positioned on the
side where the minipool components are situated. Regarding
the installation and use of the lifter, refer to its technical sheet
and manual.
After positioning the minipool in
its prepared space and after
having connected the
lift, test it.
10
Rest
minipool
E Insulation: prevents
damage from freezing and
condensation
C
Non-slip flooring
B
Internal drainage grates
(measurements
in cm)
