Over Armour Offroad TX-STAMP-4-TC01 Instructions For Installation And Care

Textron stampede 4 soft top cap

Over Armour Offroad

Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.

1. Be sure to read these instructions thoroughly before opening and installing the Textron

Stampede 4 Soft Top Cap. The installation is best done when the temperature is 70

degrees F. or warmer. The temperature affects the adhesive Velcro, if conditions prevent

installing in warmer weather it helps to store the adhesive Velcro at room temperature

prior to installation.

2. Carefully open the carton and remove the enclosure on a large flat surface that is clean

and free of dirt.

3. Check over the parts included in the carton with the parts list shown below:

Adhesive Velcro Hook Strips:

36" Webbing Straps w/ Loop

30" Webbing Straps w/ Velcro

2515 Bypass Rd. Flemingsburg, KY 41041

606-845-7439

Instructions for Installation and Care of

Textron Stampede 4

Soft Top Cap

TX-STAMP-4-TC01

4 each------------6"

4 each

Table of Contents

Need help?

Do you have a question about the TX-STAMP-4-TC01 and is the answer not in the manual?

Page 1 Over Armour Offroad 2515 Bypass Rd. Flemingsburg, KY 41041 606-845-7439 Instructions for Installation and Care of Textron Stampede 4 Soft Top Cap TX-STAMP-4-TC01 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
Page 2 Begin by wrapping the bar in front with a piece of 6” adhesive Velcro anywhere below the centerline. Then wrap the double-sided Velcro sewn to one end of the strap around the bar and Velcro as tight as you can making sure that the strap is pointed upwards.
Page 3 Next take the other two straps with a loop sewn on one end and wrap them around the roll cage in the rear just under the tab that the rear plastic panel is screwed to. It will help to raise the bed. See photo below Now place the top over the entire vehicle, the front of the top is identified by the sides not being as steeply curved, and begin by lacing the front straps through the ladder lock buckles sewn to the front corners of the top.
Page 4 Cleaning and Storage Recommendations: Before removing the Over Armour Cab for storage, make sure it is very clean in order to prevent scratching of the window panels. Clean with a soft rag or sponge using a mild liquid detergent soap and warm water solution. Never rub the windows with a dry cloth or rag! Let the Cab dry thoroughly before attempting to roll for storage.
