- Page 1 EVOLUTION USER MANUAL Read all instruction carefully before use this product. Read all instruction carefully before use this product. Retain this owner’s manual for the future’s reference...
-
Page 2: Safety Precaution
SAFETY PRECAUTION Warning: Now here we suggest that you should consult with your physician or health professional before starting your workout, especially for the age up to 35 old or once-health problem people. We take no responsible for any troubles or hurts if you don’t following our specification. Treadmill will be carefully assembled and covered the motor shield, then connect to the power. -
Page 3: Fixing Tools
ASSEMBLY INSTRUCTIONS When you open the carton, and you will find the below parts in the carton ASSEMBLY INSTRUCTIONS When you open the carton, and you will find the below parts in the carton Parts list： DES. Specification Nos. NO. DES. - Page 4 STEP 1： 1.Open the carton, get out the above spare parts, and put the Main Frame onto the level ground. STEP 2： 1. Push up the Computer and L & R uprights as the arrow position. 2. Notice: When you pull them up, make sure the uprights will not press the wires inside;...
- Page 5 STEP 4 1. Use the 5# Allen wrench to fix the computer frame onto left and right uprights(3、4) with bolt M8*45(62) and Lock washer(86) NOTICE, PLEASE HOLD THE COMPUTER FRAME BEFORE YOU HAVE TIGHTEN THE BOLT TO IN VOILD FALLING DOWN AND ESCAPE ANY HURT.
- Page 6 ATTENTION：Please confirm complete assembly as the require above and lock all the bolt. Do the following operation after checking everything is OK. Before you use the treadmill, please read the instruction carefully. Pulling up： Hold and push up the base frame at position A, push harder until hear “Bi..”...
-
Page 7: Running Board
TECHNICAL PARAMETER BUILT UP SIZE(mm) 1880*772*1455mm POWER As per showed on the label Maximum output FOLDABLE IZE(mm) 1225*772*1525mm As per showed on the label power RUNNING BOARD 510*1400mm SPEED RANGE 1-18KM/H SIZE(mm) NET WEIGHT 92KG LED WINDOW Speed, Time, Distance, Calories, Pulse GROUNDING METHOD This product must be grounded. - Page 8 OPERATION GUIDE LED WINDOW DISPLAY: 1.Speed window show current speed values. 2.Time window show running time. 3. DIST/CAL window show the running distance or calorie consumption alternately. 4. INC/PUL window show the incline value or the heart beating value alternately. When runner hold the handpulse sensor, the window will show the heart beating value.
-
Page 9: Button Function
BUTTON FUNCTION: 1.”MODE”:press MODE under standby mode, the user can choose below function circlely, “0:00” manual operation mode, it’s default mode by the system. Default speed under manual operation mode is 1.0 KM/H. “15:00” Time counting down mode. “1.0” Distance counting down mode. “50”... -
Page 10: Manual Mode
5. Press “STOP” the mathine will slow donw until stop running. 6. Hold handle pulse for 6 seconds, the window will display the user’s hearbeat rate. MANUAL MODE 1.Under standby mode， press “START” botton， treadmill starts in speed 1.0km/h and in gradient zero; other windows count forward from zero, press“INCLINE+”、... - Page 11 Attachment： Time Settting time/20 = interval Program 1 2 3 4 9 10 11 12 13 14 15 16 17 18 19 20 SPEED 2 3 3 4 INCLINE 1 1 2 2 SPEED 2 4 4 5 INCLINE 1 2 2 2 SPEED 2 4 4 6 INCLINE...
-
Page 12: User Defined Program
USER DEFINED PROGRAM There are three program U1, U2, U3 for user defined. 1.User define program setting Press “PROGRAM” continuously under standby mode until window display U1-U3,press “MODE” to start setting first segment, setup speed and incline by pressing “SPEED+”“SPEED-”AND “INCLINE+”“INCLINE-”, press “MODE”... - Page 13 VALUE RANGE Set initial value Setup parameter Initial Set range Show range 15:00 TIME(Min.: Sec.) 0:00 5:00-99:00 0:00－99:59 INCLINE（SEGMENT） 0-15 0-15 SPEED（KM/H） 1.0-18.0 1.0-18.0 DISTANCE(KM) 0.5-99.9 0.00－99.9 CALORIE(Kcal) 10-999 0－999 SAFETY KEY FUNCTION The treadmill will stop emergently by pulling off the safety key in any situation， TIME window will display “―――”...
-
Page 14: Calorie Computational Formula
settle the problem, try to change a good transformer. 2.Display E01: Message failure. Probable reason: The wires from computer and bottom control board didn’t connect well, please check each wire. If the wire was destroyed, change a good one. 3.Display E02: Burst clash. Check the power is right, if not, use correct power to test; Check if the bottom control was burnt out, change a good one;... -
Page 15: Exercise Intensity
EXERCISE STAGE Learn how to adjust the speed and incline before using. Walk about 1 km at stable velocity and write down the time, it will take you about 15-25 minutes. If walk at 4.8 km/h, it will take you about 12 minutes in 1 km. - Page 16 Speed 9.0-12.0KM/H intermediate speed walking Speed 12.0-14.5M/H well experiences of running Speed 14.5-16.0KM/H excellent runner Attention: The speed of movement ≤6KM/H , the normal walking; The speed of movement ≥8.0KM/H ,the runner. WARM-UP INSTRUCTION Take warm-up exercise before workout 5-10mints.It’ easy start training...
-
Page 17: Running Belt Adjustment
RUNNING BELT ADJUSTMENT Warning: ALWAYS UNPLUG THE TREADMILL FROM THE ELECTRICAL OUTLET BEFORE CLEANING OR SERVICING THE UNIT. Clean: General cleaning or the unit will greatly prolong the treadmill. Keep treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails. - Page 18 CENTER THE RUNNING BELT ●Place treadmill on a level surface. Run Treadmill at approximately 6-8KM/H, checking running condition. If the belt has drifted to the right, pull out of the save clock and switch, turn the right adjusting bolt 1/4 turn clockwise, then start running until centering the belt.
-
Page 19: Exploded Drawing
EXPLODED DRAWING... -
Page 20: Parts List
PARTS LIST Description Specification Qty NO. Description Specification Qty Main frame Computer bottom wire Base frame Safety lock Right upright Group Light inductor Left upright Group Magnitic ring Handle frame Power switch Incline motor bracket Standard power wire DC motor bracket Overload protector Rotation Tube Plug AC single line... - Page 21 Description Specification Qty NO. Description Specification Qty Handle jacket Lock washer Speed adjustable botton Lock washer Incline adjustable botton I type hexagon nuts Incline motor bolt M8*25 DC motor Stiffened tube for running board EVA Pad Computer overlay Circuit board Computer cover Pulse holder Computer bottom cover...
- Page 22 THANK YOU FOR PREFERRING OUR PRODUCT This product you have already purchased in under the guarantee of the SPOR DÜNYASI. In case you have any problems with regard to installation or service, please do not hesitate to contact our technical service department by calling 0850 495 52 12.
