- Page 1 TRAINER TREADMILL USER MANUAL PLEASE READ ALL INSTRUCTION IN THE OWNER'S MANUAL CAREFULLY .BEFORE ASSEMBLY AND USE THE TREADMILL.AND KEEP IT FOR FUTURE REFERENCE.
-
Page 2: Table Of Contents
CONTENTS CONTENT-----------------------------------------------------------------------------------------------1 I M P O RTA N T SA F ELY P R EC AU T I O N S - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 ASSEMB LY IN STRUCTION S ----------------------------------------------------------------- 3 -5 F O L D I N G &... -
Page 3: I M P O Rta N T Sa F Ely P R Ec Au T I O N S
IMPORTANT SAFETY PRECAUTIONS WARNING Before starting any exercise program, consult with your physician or health professional， especially the person who is above 35 years old people or has some health problems before. We take no responsibility for any troubles or hurts due to above reasons. -
Page 4: Assembly Instructions
ASSEMBLY INSTRUCTIONS When you open the carton, you will find the below spare parts. SPARE PARTS LIST DESCRIPTION REMARK DESCRIPTION REMARK MAIN FRAME BOLT M8*15 SAFETY KEY BOLT M6*25 ∮ 8.4*∮ 14.5 FRONT COVER WASHER *t0.8 FOOT PEDAL ALLEN WRENCH FOOT PEDAL PLUG SCREW DRIVER ALLEN WRENCH... - Page 5 STEP 1: Lift up the upright and computer as the picture shows. STEP 2: Use ALLEN WRENCH (89) and SCREW DRIVER (90) to lock the bolts to the parts.
- Page 6 STEP 3: Use ALLEN WRENCH (89) to lock the handrail to the upright (4L/R), then put the safety key and mp3 output wire. FOLDING INSTRUCTIONS ATTENTION: Must confirm complete assembly as the required above and lock all bolts. Do the following operation after checking everything is OK. Before you use the treadmill, please read the instruction carefully.
-
Page 7: F O L D I N G & U N F O L D I N G I N St R Uc T I O N S
UNFOLDING INSTRUCTIONS Push the deck slightly forward and kick lightly on the center of the Pneumatic cylinder. Allow the deck to fall to the floor slowly. INCLINE INSTRUCITONS PIC I PIC II INCLINE INSTRUCTIONS “INCLINE+/-”and “+/-”on left handrail is incline add and substract button. To adjust incline when treadmill running, the stepping is 1 level / times. -
Page 8: Groungding Met Hods
GROUNDING METHODS This product must be grounded. If it is should be malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 9: Operation Guide
OPERATION GUIDE WINDOWS DISPLAY 2.START Normal start after 5 seconds countdown. 3. PROGRAM 3 manual mode, 16 automatic programs. 4. SAFETY LOCK FUNCTION The window will show "---" when you take away the safety lock and the treadmill will stop quickly with "didi" alarm noise. - Page 10 5.1 START/STOP “START”--When the treadmill is not running, press this button to start, start speed is"1.0" “STOP”--when the treadmill is running, press this button to stop and set back to program default manual mode after stopped. 5.2. PROGRAM when the treadmill is not running, press PROGRAM button to circle and to choose and set up the exercise time and program from “1.0”...
- Page 11 8. PROGRAM EXERCISE CHART SETTING TIME / 10 = EVERY GRADE TIME TIME PROG SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED...
- Page 12 9. MODE PARAMETER SETTINGS Countdown initial setting 30:00 minutes,setting range 5:00--99:00 minutes,stepping 1:00. Countdown calorie initial setting 50 therm,setting range 20--990 therm,stepping 10. Countdown distance initial setting 1.0 km，setting range 1.0---99.0 km,steeping 1.0. Cycle switch order is: Manual, Time, Distance, Calories. 10.
-
Page 13: Getting Started Guide
GETTING STARTED GUIDE Press buttons to choose the music or adjust the volume as you like. “VOL+- “can adjust the volume when music is playing “Prev/next” can switch to the songs you are interested in when SD or or USB equipment is working. “MUTE”... -
Page 14: Safety Exercise
SAFETY EXERCISE EXERCISE Please stand on the side to learn how to operate, such as speed and incline, until you know it then can start do exercise. Walk 1 km by constant step need about 15-25 minutes, please record it in fact. - Page 15 Please consult professional staff before do exercise. He can help recommendation exercise rate/intension and time according to your age and health condition. When running, if you feel chest tightness or chest pain, irregular Heartbeats, short of breath, dizziness or other unwell, please stop immediately! And consult professional before you want continually to do exercise.
-
Page 16: Warm-Up Exercise
WARM-UP EXERCISE It is better to do some warm-up exercise. Warm the muscle easy stretch, so use 5-10 minutes to warm-up. Then stop and according below method to do stretch exercise for five times, and each foot do 10 seconds or more every time. -
Page 17: Maintan Ce In St Ruct I On
MAINTENANCE INSTRUCTIONS WARNING Please make sure pull out the treadmill's power plug before cleaning or maintaining the product. CLEANSING General cleaning or the unit will greatly prolong the treadmill's life. Keep treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails. -
Page 18: Belt Adjustment
BELT ADJUSTMENT Place treadmill on a level surface. Make treadmill run at approximately 6-8 km/h, observe the running belt deviate condition. If the belt has drifted to the right, unplug the safety lock and power switch, and turn the right adjusting bolt 1/4 turn clockwise, then insert the power switch and safety lock, make the treadmill running, observe the running belt deviate condition. -
Page 19: Exploded Drawings
EXPLODED DRAWING... -
Page 20: Parts List
PARTS LIST DESCRIPTION MARK DESCRIPTION MARK MAIN FRAME INNER PIPE MOVING WHEEL BASE FRAME PLUG INCLINE FRAME EDGING A 4L\R UPRIGHT EDGING B MOTOR BACKET FLAT FOOT PAD FRONT ROLLER CUSHION PAD REAR ROLLER RING PLUG COMPUTER BACKET FOOT PEDAL PLUG HANDRAIL PIPE CUSHION PAD SAFETY KEY... - Page 21 LITTLE COVER ALLEN WRENCH ADJUSTABLE WHEELS MP3 WIRE DESCRIPTION MARK Q’Y DESCRIPTION MARK Q’Y SINGLE LINE BOLT ST4*15 CONTROLLER BOLT ST3.0*23 HAND PULSE BOLT M5*10 SHORTCUT KEY BOLT M4*15 COMPUTER PANEL BOLT M6*25 BOLT M10*45 BOLT M6*45 BOLT M10*45 BOLT M5*30 BOLT M8*85...
-
Page 22: Error Code An D Sig N I Fi Can
ERROR CODE AND SIGNIFICANCE CODE DESCRIPTION REASONS & SOLUTIONS The computer shows fault code E1 Communication abnormal: The control and computer Possible reasons：Communication obstructed between has abnormal controller and computer, please check the wire and make sure communication after start the wire connect well and the wire without and danger.
