Table 16. DD9300 with DS60 ERSO (continued)
String I/O - Port
(Loop)
2 I/O 2 - Port 1
3 I/O 7 - Port 2
3 I/O 2 - Port 2
4 I/O 7 - Port 3
4 I/O 2 - Port 3
Cable lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be used.
a.
Figure 54. DD9300 with DS60 shelves, ERSO
60 Connect Cables and Power On
Shelf Port
B controller port 0 of the highest number shelf in V2
A controller port 0 of shelf V3.1
B controller port 0 of the highest number shelf in V3
A controller port 0 of shelf V4.1
B controller port 0 of the highest number shelf in V4
a
Length
2M
2M
5M
5M
5M
