Figure 53. DD9300 with DS60 shelves, DD Cloud Tier or HA and DD Cloud Tier

DD9300 with ERSO

Table 16. DD9300 with DS60 ERSO
String I/O - Port
(Loop)
1 I/O 7 - Port 0
1 I/O 2 - Port 0
2 I/O 7 - Port 1
Shelf Port
A controller port 0 of shelf V1.1
B controller port 0 of the highest number shelf in V1
A controller port 0 of shelf V2.1
Connect Cables and Power On
a
Length
2M
2M
2M
