Technical Specifications
5.8 Dimension Drawings
5.8

Dimension Drawings

Note
All dimensions are in millimeters, unless otherwise stated.
Note
Dimensional tolerances are in accordance with ISO 2768-mK, unless otherwise stat-
ed.
Figure 5.1
28
Overall Dimensions
438.15
Installation Manual, 01/2020, C79000-G8976-1343-06
RUGGEDCOM M2200F
